Ritetemp 8025 Manuale utente

PG 2

PG 1

1 Configure

2 Set Temp

3 Operate

.Set HEAT/COOL mode switch to HEAT or COOL. The unit will display the ambient  

 temperature. Set the Fan switch to automatic.

.Turn the Control Knob to increase or decrease the TARGET TEMP. The TARGET TEMP

will be displayed when your are adjusting the temp. (The display will return to show the

current ROOM TEMP in a few seconds).

.Your thermostat is now in operation.

In thewinter, set the HEAT-COOL Mode switch to HEAT to control your heating system.

In thesummer, set the HEAT-COOL Mode switch COOL to control your air conditioner.

In springandfall or when windows are open, you can set the HEAT/COOL Mode switch

to OFF.

Setting the FAN Mode switch to AUTO automatically runs yoursystem's fan during heating

and cooling.

Setting the FAN Mode switch to ON runs your system's fan continuously even without

heating or cooling.

HEAT

ROOM TEMP

Temperature

Display

HEAT/COOL

Mode Switch

Control Knob

Fan Mode

Switch

Operation 8025

Statement of use: The 8025 can be used with: most 24 volt

gas, oil or electric heating and air conditioning systems,

single-stage heat pumps or gas millivolt heating systems.It

cannot be used with 120 volt heating systems or

multistage heat pumps.

Inside of Unit

OFF

RESET

GAS

ELEC

SHORT C

OPEN F

4 Special Features

PG 3

PG4

Celsius/Fahrenheit

(C/F) jumper

Reset Button

Gas/Electric

jumper

C/F Select

Centigrade / Fahrenheit selection. The C/F jumper is on theback of the

thermostat control unit it determines which temperature system is displayed on the

LCD display.

.To change the

oF / oC jumper. Separate the control unit from the wall mounted 

 terminals.

.Locate the

oF / oC jumper.

.Select the desired display mode.

.Press the internal RESET button and replace the control uniton the wall.

When the batteries are low, the battery icon will come on and flash.The

two AA Batteries in the unit need to be replaced. In some installations,

your heater system will stop functioning when the thermostst loses power. Replace

Batteries as soon as you see this warning. The thermostat setting will remain for 30

seconds while the batteries are removed and replaced.

Customer Support: 888-515-2585

Visit our website www.ritetemp-thermostats.com

Rear View of Unit

Low Battery

1-403-019
