RKI Instruments 65-2443SS Manuale utente

RKI Instruments, Inc.

www.rkiinstruments.com

65-2443SS

PPM Hydrogen Transmitter

Operator’s Manual

Part Number: 71-0549

Revision: P1

Released: 3/4/21

2 • 65-2443SS PPM Hydrogen Transmitter

WARNING

Read and understand this instruction manual before operating detec-

tor. Improper use of the detector could result in bodily harm or death.

Periodic calibration and maintenance of the detector is essential for

proper operation and correct readings. Please calibrate and maintain

this detector regularly! Frequency of calibration depends upon the

type of use you have and the sensor types. Typical calibration frequen-

cies for most applications are between 6 and 12 months, but can be

required more often or less often based on your usage.

65-2443SS PPM Hydrogen Transmitter • 3

Product Warranty

RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in materials,

workmanship, and performance for a period of one year* from the date of shipment from RKI

Instruments, Inc. Any parts found defective within that period will be repaired or replaced, at our

option, free of charge. Parts must be returned to RKI Instruments, Inc. for repair or replacement. This

warranty does not apply to those items which by their nature are subject to deterioration or

consumption in normal service, and which must be cleaned, repaired or replaced on a routine basis.

Examples of such items are:

Warranty is voided by abuse including mechanical damage, alteration, rough handling, or repair

procedures not in accordance with instruction manual. This warranty indicates the full extend of our

liability, and we are not responsible for removal or replacement costs, local repair costs, transportation

costs, or contingent expenses incurred without our prior approval.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER WARRANTIES

AND REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL OTHER

OBLIGATIONS OR LIABILITIES ON THE PART OF RKI INSTRUMENTS, INC.

INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL RKI INSTRUMENTS,

INC. BE LIABLE FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL LOSS OR

DAMAGE OF ANY KIND CONNECTED WITH THE USE OF ITS PRODUCTS OR

FAILURE OF ITS PRODUCTS TO FUNCTION OR OPERATE PROPERLY.

This warranty covers instruments and parts sold to users only by authorized distributors, dealers and

representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for any accident or damage caused by the operation of this gas

monitor and our warranty is limited to the replacement of parts or our complete goods. Warranty

covers parts and labor performed at RKI Instruments, Inc. only, and does not cover field labor or

shipment of parts back to RKI.

a) Pump diaphragms and valves c) Batteries

b) Fuses d) Filter elements

4 • 65-2443SS PPM Hydrogen Transmitter

Table of Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

PPM Hydrogen Detector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Junction Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Mounting the PPM Hydrogen Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Wiring the PPM Hydrogen Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Transmitter Burn-In Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting the Zero Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Replacing Components of the PPM Hydrogen Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Calibration Kit Humidifier Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Preparing for Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the Zero Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the Span Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Setting the Linearization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Returning to Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

65-2443SS PPM Hydrogen Transmitter • 5

Overview

This manual describes the 65-2443SS ppm hydrogen transmitter. This manual also describes how to

install, start up, configure, maintain, and calibrate the transmitter when it is used with a gas monitoring

controller. A parts list at the end of this manual lists replacement parts and accessories for the

transmitter.

Specifications

Table 1 lists specifications for the ppm hydrogen transmitter.

WARNING: When using the 65-2443SS, you must follow the instructions and warnings in this

manual to assure proper and safe operation of the 65-2443SS and to minimize the risk

of personal injury. Be sure to maintain and periodically calibrate the 65-2443SS as

described in this manual.

Table 1:Specifications

Target Gas Hydrogen (H2)

Detection Range 0 - 2,000 ppm

Area Classification Explosionproof for Class I, Groups B, C, and D

Sampling Method Diffusion

Input Power 10 - 30 VDC

Signal Output 4 to 20 mA with impedance maximums listed below:

• 12 VDC input: 500 Ohms

• 24 VDC input: 1000 Ohms

Response Time 90% in 45 seconds

6 • 65-2443SS PPM Hydrogen Transmitter

Description

This section describes the ppm hydrogen transmitter’s components. It is a 4 to 20 mA type detector

head. It consists of the ppm hydrogen detector, amplifier, and junction box.

Figure 1: Component Location

PPM Hydrogen Detector

The ppm hydrogen detector is a MOS type (metal oxide semiconductor) detector packaged in a 1/2

NPT nipple with a sintered metal flame arrestor on one end allowing ambient air to diffuse into the

detector. The flame arrestor also contains any sparks which may occur within the detector. The 1/2

NPT mounting threads at the top of the detector allow you to mount it into the bottom conduit hub of

the junction box. A rainshield screws onto the bottom of the detector (flame arrestor end). The

rainshield helps protect the detector from rain and debris in the monitoring environment. Three color-

coded leads extend from the top of the detector. The leads allow you to connect the detector to the

amplifier.

The detector has a built in molecular sieve that only allows hydrogen to diffuse into the detector. The

output of the detector is non-linear and is linearized by the amplifier (see below).

J-Box

SPAN

DETECTOR

RB PW R / SIG

Reducing Bushing,

3/4 NPT to 1/2 NPT

Amplifier

Hydrogen Detector

Locking Set Screw

LINEAR

65-2443SS PPM Hydrogen Transmitter • 7

Amplifier

The amplifier converts the non-linear electrical output from the detector to a linear 4 to 20 mA signal

that corresponds to the detection range and transmits the signal to a gas monitoring controller. The

amplifier includes the terminal strips, span pot, linearizing pot, and test points.

Figure 2: Amplifier Component Location

Controller Terminal Strip

The controller terminal strip is a three position plug-in style terminal strip located near the top of the

amplifier. Use the controller terminal strip to wire the transmitter to a controller.

Detector Terminal Strip

The detector terminal strip is a three position plug-in style terminal strip located below the controller

terminal strip. Use the detector terminal strip to connect the detector to the amplifier.

NOTE: The detector is factory-wired to the detector terminal strip. See page 10 for all wiring

procedures related to the transmitter.

Span Pot

The span pot is located to the left of the detector terminal strip (see Figure 2). Use a small flat blade

screwdriver to turn the span pot’s adjustment screw and adjust the amplifier’s full scale response

output during the calibration procedure.

Linearizing Pot

The linearizing pot (labeled LINEAR) is located in the bottom left corner of the amplifier (see

Figure 2). Use a small flat blade screwdriver to turn the linearizing pot’s adjustment screw while

applying mid-scale gas to linearize the transmitter’s output during the calibration procedure.

+ Test Point, Red

RBW

DETECTOR

- Test Point, Black

Mounting Screw

w/ flat and lock washer

SPAN

PWR / SIG

LINEAR

Factory Use Jumpers

Detector Terminal Strip

Span Pot

Controller Terminal Strip

Linearizing Pot

8 • 65-2443SS PPM Hydrogen Transmitter

Test Points

The test points are on the right side of the amplifier (see Figure 2). The test points produce a 100 to 500

mV output that corresponds to the transmitter’s 4 to 20 mA output. Use the test points and a voltmeter

to measure the amplifier’s output during the start-up and calibration procedures. The black test point

on the bottom is the negative (-) test point and the red test point on the top is the positive (+) test point.

Junction Box

The stainless steel, corrosion resistant junction box allows you to install the detector at a mounting site

that is remote from a controller, and it protects the detector wiring connections. Two conduit hubs

allow you to mount the detector to the junction box and connect the wiring from the detector to a

controller. An O-ring seals the interface between the junction box cover and the junction box base.

Use the cover on the front of the junction box to access the interior of the junction box. The detector

and amplifier are factory installed in the junction box. A locking set screw on the junction box cover

allows you to secure the junction box cover and prevent it from being removed.

65-2443SS PPM Hydrogen Transmitter • 9

Installation

This section describes procedures to mount the ppm hydrogen transmitter in the monitoring

environment and wire the transmitter to a controller.

Mounting the PPM Hydrogen Transmitter

Figure 3: Mounting the PPM Hydrogen Transmitter

1. Select a mounting site that is representative of the monitoring environment. Consider the

following when you select the mounting site.

• Select a site where the transmitter is not likely to be bumped or disturbed. Make sure there is

sufficient room to perform start-up, maintenance, and calibration procedures.

• Select a site where the target gas is likely to be found first. For hydrogen, which is lighter than

air, mount the transmitter near the ceiling or where hydrogen is most likely to accumulate.

2. At the monitoring site you select, hang or mount the junction box with the detector facing down

(see Figure 3).

J-Box

.75

3/4 NPT

Female,

3.66

3.15

2.40

.20 Dia. x .45

Slot, 2X

3.34

7.40 MAX

Hydrogen Detector

3/4 x 1/2 Reducing Bushing

10 • 65-2443SS PPM Hydrogen Transmitter

Wiring the PPM Hydrogen Transmitter

WARNING: Always verify that the power to the controller is off before you make wiring

connections.

1. Turn off power to the controller.

2. Place the controller’s power switch in the OFF position.

3. Remove the junction box cover.

4. The detector leads are factory wired. Verify that the detector leads are wired to the amplifier’s

detector terminal strip as shown in Figure 4.

5. To gain access to a plug-in terminal strip for wiring, pull it out of its socket by grasping the

terminal strip and pulling. The detector strip is keyed so that the controller and detector terminal

strips cannot be reversed inadvertently.

6. Guide a three-conductor, shielded cable or three wires in conduit through the top conduit hub of

the junction box.

7. Pull out the controller terminal strip, and connect the three wires to the terminal strip as follows

(see Figure 4).

• Connect the positive wire to the PWR/SIG “+” terminal.

• Connect the signal wire to the PWR/SIG “S” terminal.

• Connect the negative wire to the PWR/SIG “-” terminal.

CAUTION: If shielded cable is used, leave the cable shield’s drain wire disconnected and insulated at

the transmitter. You will connect the opposite end of the cable’s drain wire to the

controller’s chassis (earth) ground.

8. Reinstall the controller terminal strip into its socket.

9. Secure the junction box cover to the junction box.

10. Route the cable or wires leading from the ppm hydrogen transmitter through one of the conduit

hubs at the controller housing.

CAUTION: Do not route power and transmitter wiring through the same controller conduit hub. The

power cable may disrupt the transmission of the transmitter signal to the controller.

Indice

Altri manuali RKI Instruments Trasmettitore

RKI Instruments

RKI Instruments 65-2658XL-CH4-4 Manuale utente

RKI Instruments

RKI Instruments 65-2451RK Manuale utente

RKI Instruments

RKI Instruments 65-2396RK Manuale utente

RKI Instruments

RKI Instruments 65-2451RK-05 Manuale utente

RKI Instruments

RKI Instruments 65-2649RK-HC-04 Manuale utente

RKI Instruments

RKI Instruments 65-2650RK-04 Manuale utente

RKI Instruments

RKI Instruments 65-2645-05SS-04 Manuale utente

RKI Instruments

RKI Instruments 65-2397RK Manuale utente

RKI Instruments

RKI Instruments 65-2643-05SS-4S Manuale utente

RKI Instruments

RKI Instruments 65-2396RKSS Series Manuale utente

RKI Instruments

RKI Instruments 65-2330RKSS Manuale utente

RKI Instruments

RKI Instruments 65-2646RK-05-04 Manuale utente

RKI Instruments

RKI Instruments 65-2658RK-CH4-4 Manuale utente

RKI Instruments

RKI Instruments 65-2645XL-05-04 Manuale utente

RKI Instruments

RKI Instruments 65-2434RK Manuale utente

RKI Instruments

RKI Instruments 65-2405RK-05-04 Manuale utente

RKI Instruments

RKI Instruments 65-2670-CL2-04 Manuale utente

RKI Instruments

RKI Instruments 65-2462RK Manuale utente

RKI Instruments

RKI Instruments 65-2405RK-05 Manuale utente

RKI Instruments

RKI Instruments 65-2662XL-04 Manuale utente

RKI Instruments

RKI Instruments M2 Manuale utente

RKI Instruments

RKI Instruments 65-2422RK-05 Manuale utente

RKI Instruments

RKI Instruments 65-2405RK-04 Manuale utente

RKI Instruments

RKI Instruments 65-2649XLCH44SS Manuale utente

Manuali Trasmettitore popolari di altre marche

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuale del proprietario

Honeywell

Honeywell 5816WMBR Manuale utente

Kamstrup

Kamstrup READy MTU Istruzioni operative

Omega

Omega ZW Series Manuale utente

ABB

ABB Field 264H Guida

Alinco

Alinco DJ-V17T Manuale utente

Dejero

Dejero EnGo 3x Manuale utente

Rosemount

Rosemount 4600 Manuale utente

Speaka Professional

Speaka Professional 2342740 Manuale utente

trubomat

trubomat GAB 1000 Manuale utente

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuale utente

Rondish

Rondish UT-11 Manuale utente

MG 10JRE Manuale utente

Burkert

Burkert 8177 Manuale utente

Firetide

Firetide HotPort 3203 Manuale

Tele Radio

Tele Radio T9-02 Manuale utente

Rotronic

Rotronic HygroFlex HF3 Series Manuale utente

Jamara

Jamara FCX6 Pro Tel Manuale utente
