Section
CONTENTS
Page
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
SPECIFICATIONS .......................................................................... 1
PERFORMANCE CURVES ...............................................................
2
2-1 AC Output .............................................................................. 2
2-2 DC Output .............................................................................. 3
FEATURES .................................................................................. 4
GENERAL DESCRIPTION OF THE GENERATOR .................................. 5
4-1 External View ofGenerator ........................................................... 5
4-2 Location of Serial Number and Specification Number ............................... 6
CONSTRUCTlON AND FUNCTION ..................................................... 7
5-1 Construction ........................................................................... 7
5-2 Function ................................................................................ 7
5-3 Description of Generator Operation ................................................ 10
SAFETY PRECAUTIONS ................................................................ 12
RANGE OF APPLICATIONS ............................................................ 13
MEASURING PROCEDURES
.......................................................... 17
8-1 Measuring Instruments ............................................................... 17
8-2 AC Output Measuring ................................................................ 20
8-3 DC Output Measuring ............................................................... 20
8-4 Measuring Insulation resistance ..................................................... 21
CHECKING FUNCTIONAL MEMBERS ............................................... 23
9-1 Control panel.. ........................................................................ 23
9-2 Stator .................................................................................. 24
9-3 Rotor .................................................................................. 25
9-4 Condenser ............................................................................ 26
9-5 Diode Rectifier ........................................................................
26
DISASSEMBLY AND ASSEMBLY .................................................... 2 7
10-1
Preparation and Precautions ........................................................ 27
10-2 Disassembly Procedures ............................................................. 28
10-3 Assembly procedures ................................................................ 38
TROUBLE SHOOTING .................................................................. 44
11-1 NoACOutput. ....................................................................... 44
11-2
ACvoltage istoo high ortoolow ...................................................
46
WIRING DIAGRAM ...................................................................... 47
