Rocket Fish RF-WHD200 Manuale utente

4-Port WirelessHD Kit

RF-WHD200

User Guide

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 1 Thursday, November 18, 2010 1:47 PM

Rocketfish RF-WHD200

4-Port WirelessHD Kit

Contents

Safety information .......................................................... 3

Features............................................................................... 4

Setting up the transmitter and receiver.................. 8

Specifications..................................................................15

Troubleshooting ............................................................18

Legal notices ...................................................................19

Warranty ...........................................................................21

Introduction

Congratulations on your purchase of this high-quality Rocketfish

system, which represents the state of the art in 60 GHz wireless

transceiver design, and gives you complete freedom while enjoying

your music or movies without the limitations of cables.

The system has a non line-of-sight transmission range of up to 33 feet

(10 m), and can be used with your HDMI-compatible home theater

components, gaming systems, or computer.

This User Guide explains how to correctly install, operate, and get the

best performance from your WirelessHD kit. Read this guide carefully

before installing your system, and then keep it handy for quick

reference.

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 2 Thursday, November 18, 2010 1:47 PM

3RF-WHD200

Safety information

Warning: To reduce the risk of fire or electric shock, do not expose the included

devices to rain or moisture.

Caution: To reduce the risk of electric shock, do not disassemble any component of the

kit. There are no user-serviceable parts inside. Refer servicing to qualified service

personnel.

• Read these instructions.

• Keep these instructions.

•Heedallwarnings.

• Follow all instructions.

• Do not use the included devices near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type

plug. A polarized plug has two blades with one wider than the other. A

grounding type plug has two blades and a third grounding prong. The

wide blade or the third prong is provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for replacement

of the obsolete outlet.

• Protect the power cord from being walked on or pinched particularly at

plugs, convenience receptacles, and the point where they exit from the

apparatus.

The lightning flash with arrowhead symbol, within an

equilateral triangle is intended to alert the user to the

presence of uninsulated dangerous voltage within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 3 Thursday, November 18, 2010 1:47 PM

• Only use attachments or accessories specified by the manufacturer.

• Unplug the included devices during lightning storms or when unused

for long periods of time.

• Refer all servicing to qualified service personnel. Servicing is required

when a component of the kit has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus has been exposed to rain or

moisture, does not operate normally, or has been dropped.

• The included devices shall not be exposed to dripping or splashing and

no objects with liquids such as vases, shall be placed on the apparatus.

• The AC power adapter is used as the disconnect device. This disconnect

device shall remain readily operable.

• Read the rating labels on the bottom of the base station and wireless

speaker for power input and other safety information.

Features

Package contents

The box should contain:

• 60 GHz WirelessHD transmitter (1)

• 60 GHz WirelessHD receiver (1)

• Mounting bracket for receiver (1)

•HDMIcables(2)

• AC power adapter (2)

•Remotecontrol(1)

•QuickSetupGuide

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 4 Thursday, November 18, 2010 1:47 PM

5RF-WHD200

Transmitter front/top panel

Receiver front/top panel

Item Description

1 Power and link status indicator (green)

Blinking—The power is connected and the transmitter is turned on.

On—The transmitter and receiver are linked.

Off—The power is off.

2HDMI 4—When the indicator is on (green) the HDMI port is in use.

3 HDMI 3—When the indicator is on (green) the HDMI port is in use.

4HDMI 2—When the indicator is on (green) the HDMI port is in use.

5 HDMI 1—When the indicator is on (green) the HDMI port is in use.

Item Description

1 Power and link status indicator (green)

Blinking—The power is connected and the receiver is turned on.

On—The transmitter and receiver are linked.

Off—The power is off.

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 5 Thursday, November 18, 2010 1:47 PM

Transmitter back panel

Receiver back and side panels

Item Description

1 DC IN jack—Connect the power adapter to this jack.

2Power switch—Turns the transmitter on or off.

3 HDMI/WVAN switch— A quick press (<1 second) toggles the HDMI switch input to select the next HDMI input.

A long press (>3 seconds) toggles WirelessHD output between one or more WirelessHD receivers in the same

room. See “Setting up a Wireless Video Area Network (WVAN)” on page 11.

4HDMI 1 jack—Connect one end of an HDMI cable to this jack and the other end to your HDMI signal source.

5 HDMI 2 jack—Connect one end of an HDMI cable to this jack and the other end to your HDMI signal source.

6HDMI 3 jack—Connect one end of an HDMI cable to this jack and the other end to your HDMI signal source.

7 HDMI 4 jack—Connect one end of an HDMI cable to this jack and the other end to your HDMI signal source.

Item Description

1 HDMI jack—Connect one end of an HDMI cable to this jack and the other end to your TV or projector.

2DC IN jack—Connect the power adapter to this jack.

3 Power switch—Turns the receiver on or off.

4Cable routing clips - Insert HDMI cable into these clips for receiver placement stability.

Right side view Back view Left side view

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 6 Thursday, November 18, 2010 1:47 PM

7RF-WHD200

Remote control

Note: Remove the plastic film from the remote control before using it for the first time.

Make sure you point the remote control at the WirelessHD transmitter.

Item Description

1 SLEEP button - Press to turn the transmitter and receiver on or off.

2-5 HDMI 1-4 - Press to select the HDMI port for the signal source of your choice.

Wireless HD Transceiver

HDMI 1

HDMI 4HDMI 3

HDMI 2

SLEEP

Wireless HD Transceiver

HDMI 1

HDMI 4HDMI 3

HDMI 2

SLEEP

Plastic film

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 7 Thursday, November 18, 2010 1:47 PM

Setting up the transmitter and receiver

Mounting the receiver on a wall

(optional - can also be placed on a flat, shelf-like surface)

To mount the receiver on a wall:

1Drill holes through the mounting bracket into the wall where you want

to mount your receiver.

2Use a screwdriver to secure the mounting bracket to the wall.

Note: Drywall installations may require drywall anchors (not included) for a secure

mounting.

3Mount the receiver onto the mounting bracket.

Mounting slot

Mounting bracket

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 8 Thursday, November 18, 2010 1:47 PM

9RF-WHD200

Connecting the transmitter and receiver

To connect the transmitter and receiver:

1Set up the transmitter and receiver. Refer to the following setup

diagrams to arrange your transmitter and receiver. We recommend that

the transmitter and receiver face each other for the best performance.

Top view

Side view

Receiver

Transmitter

Floor

82°

47°

16.4 ft. (5 m)

32.8 ft. (10 m)

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 9 Thursday, November 18, 2010 1:47 PM

2Connect the media sources, such as a Blu-ray/DVD player, cable/satellite

box, or gaming console to the transmitter with HDMI cables.

3Connect the display device, such as a TV or projector, to the receiver with

an HDMI cable.

Transmitter

Computer

HDMI cable

Game console

Receiver

Display devices

HDMI cable

10-0766 RF-WHD200_MAN_ENG_V1.fm Page 10 Thursday, November 18, 2010 1:47 PM
