Roku 3 Scheda tecnica

Hi!

Let’s get started.

What’s in the box

Roku player

Remote control with

in-ear headphone jack

2 x AA Alkaline

batteries

In-ear headphones Power adapter

Get to know your Roku

Front view

Back view

Ethernet port – Connects your Roku player to a wired network with an

Ethernet cable (not included).

HDMI port – Connects your Roku player to an HDTV with an HDMI cable

(not included).

Reset button – Resets your Roku player to its original factory settings

when pressed and held for 10 seconds (a feature you’ll rarely, if ever, use).

Status light – Flashes slowly when the Roku player starts up. Glows when

it’s on. Flashes once with each press of the remote control.

Storage expansion slot – Lets you increase your storage capacity for

Roku channels and games with a microSD card (optional, not included).

Power port – Connects your Roku player to a 120V AC power source with

the included power adapter.

USB port – Plays your home videos, movies, music and photos from

supported USB drives. For supported ﬁle types, visit roku.com/usb.

Did you notice? Your Roku player has no on/o switch. It’s simpler that way

and draws very little power—less than a nightlight! Keep it plugged in so that

it can download the latest software updates automatically.

What you need

Roku player

HDTV

High-speed Internet connection

(DSL or cable modem)

Router

HDMI cable

(sold separately)

Pssst! Your router can be wireless (any Wi-Fi) or wired. For wired networks,

you’ll also need an Ethernet cable (not included).

What to do Step 1

Ready for the step-by-step? We’ve only got four…

Connect your player

Use an HDMI cable (not included) to make the connection depicted in the

diagram below:

Did you know? Because HDMI outputs digital video and audio, you don’t

need a separate audio cable. HDMI also supports up to 7.1 surround sound

(where available). Got a receiver? You can also use HDMI to route video and

audio directly through your receiver if it supports HDMI video pass-through.

•Connect one end to the HDMI port on the back of your Roku player.

•Connect the other end to an open HDMI port on your TV.

What to do Step 2

Power up key components

In this step, we’ll make sure all systems are GO!

First, power your Roku remote by inserting the included batteries:

•Turn the remote control over and locate the rectangular battery door on the

rear of the unit.

•Press the latch at the top of the battery door down while simultaneously

removing the battery door.

•Insert each battery negative (-) side ﬁrst, pushing it into the coil and then into

the compartment. Do NOT insert batteries positive (+) side ﬁrst. Place the

battery door back over the compartment and press it gently down until the

latch snaps securely into place.

Power tip! Always replace dead batteries with two brand-new batteries from

the same manufacturer. Never use damaged batteries. If your remote gets

warm/hot during use, discontinue use and contact Roku Customer Support

immediately at support.roku.com

What to do Step 2 (continued)

Next, power on your Roku player by connecting it to a wall outlet using the

included power adapter, like this:

Finally, power on your TV and look for a Roku message to ﬁll the screen.

Blank screen? If your TV does not display a Roku screen, make sure your TV

input matches the physical connection used to connect your Roku player. Press

the Input button (sometimes called Source) on your TV or TV remote to cycle

through the various video inputs available until you see a Roku screen.

What to do Step 3

Conﬁgure your network

Step 3 establishes your network connection and brings out your inner geek. You

can do it! Just choose either wireless or wired and read on for instructions:

Wireless: If you use a wireless network, you can grab that Roku remote and jump

right into Guided Setup. When prompted, select “Wireless” as your network

connection and have your network name and password ready. Then:

•Select your network from the list of available networks.

•Enter your network password, if you use one. Remember, network passwords

are case sensitive.

Dos and don’ts on where to place your Roku player:

•DO place your player within range of your wireless network.

•DON’T place your player in an enclosed cabinet; it may interfere with

the wireless signal.

•DON’T place your player beneath anything; it may cause the player to

overheat. Eeeeks.
