2 Port Serial PCIe Card

RC-301EU

User Manual

2 Port Serial PCIe Card RC-301EU User Manual

1

Features and Benefits

Compliant with PCI Express Base spec 1.1

Compliant with PCI Power Management 1.2

Supports 2 x UART serial port

Built-in 16C950 compatible UART

128-byte deep transmit/receive FIFOs

Serial data transfer rate up to 230400bps

Bus：PCI-Express x1

Connectors：2 x DB9 male serial connectors

System Requirements

Windows® 2000, XP/2003 32/64 bit, Vista 32/64 bit

PCI Express-enabled system with an available PCI Express slot

Package Contents

1 x RC-301EU

1 x User Manual

1 x CD Driver

2 x Low-Profile Brackets

2 Port Serial PCIe Card RC-301EU User Manual

2

Hardware Installation

General instructions for installing the card are provided below. Since the

design of system may vary, refer to your system’s reference manual for

further information, if needed.

Insert the Card into the PCIe slot of your system. Make sure it is inserted

all the way in for a solid connection.

Driver Installation

For Windows®2000

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, click Next.

3. Select Search for a suitable driver for my device (recommended),

and click Next.

4. Check CD-ROM drives, uncheck the other boxes, then click Next.

5. Click Next.

6. Click Finish.

7. Repeat steps 1-5 one more time.

2 Port Serial PCIe Card RC-301EU User Manual

3

For Windows®XP/Server 2003

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, select Install the software

automatically (Recommended), then click Next.

3. Accept the default entry, then click Next.

4. Click Finish to complete the driver installation.

For Windows®XP-x64/Server 2003-x64

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, select Install the software

automatically (Recommended), then click Next.

3. Click Finish to complete the driver installation.

For Windows®Vista/Vista-x64

1. Insert the Driver CD into the CD-ROM drive.

2. At the Found New Hardware Wizard, select Locate and install driver

software (recommended).

3. Click Next to continue to setup.

4. Click Close to complete the driver installation.

2 Port Serial PCIe Card RC-301EU User Manual

4

To Verify Windows®Driver Installation

Click on the Device Manager tab in System Properties, which you

access from the Windows Control Panel. You should see two PCI

Express UART Port … installed under Ports (COM & LPT) item, and one

PCI Express Multiport Serial Adapter installed under Multi-port serial

adapters item.

Thank you for purchasing a quality Rosewill Product.

Please register your product at :

www.rosewill.com for complete warranty information and future support for your product.
