Rossmax CalPro Manuale utente
Instruction Manual
Model: CalPro
Mobile Calibration System
for Blood Pressure Monitor
2 3
Table of Contents:
Introduction ...................................................................................... 3
Preliminary Remarks........................................................................... 3
Cautionary Notes............................................................................... 3
Name/Function of Each Part............................................................ 4,5
LCD Display Explanations ................................................................... 6
Using the AC Adapter........................................................................ 7
Connect Methods........................................................................... 7,8
Operation Procedures
1. Data link status operation ........................................................... 9
2. Readout Mode .......................................................................... 10
3. Auto Calibration Mode ............................................................. 18
4. Measurement Count Display Mode ........................................... 20
5. Measurement Count Clearance Mode ....................................... 21
6. Calibration Reminder Setting Mode .......................................... 22
7. Pressure Gauge Mode .......................................................... 23-25
Change "mmHg" to "kPa" ............................................................. 26
Error Messages ................................................................................ 27
Specications................................................................................... 28
Safety Certications......................................................................... 29
USA FCC Class B ............................................................................. 29
Maintenance of ROSSMAX Calibrator.............................................. 29
Introduction
The calibration system developed by Rossmax Reasearch and Develop-
ment is equipped with the following features :
● Automatic device pressure checking
● Automatic device pressure calibration
● Measurement count check and reset
● Digital manometer
Which helps our partners to offer on-site and prompt calibration service
to end users as well as signicantly enhance customer satisfaction!
Preliminary Remarks
The quality of the device has been veried and conforms to the provi-
sions of the Electromagnetic Compatibility EMC Directive 2014/30/EU;
Low Voltage Directive (LVD) 2014/35/EU and EN/IEC 61010-1 :2010 Safe-
ty requirements for electrical equipment for measurement, control, and
laboratory use - Part 1: General requirements.
Cautionary Notes
1. The unit contains high-precision assemblies. Therefore, avoid extreme
temperatures, humidity, and direct sunlight. Avoid dropping or strong-
ly shocking the main unit, and protect it from dust.
2. The unit should not be operated by children so to avoid hazardous
situations.
3. If the unit is stored near freezing, allow it to acclimate at room tem-
perature before use.
4. This unit is not eld serviceable. You should not use any tool to open
the device nor should you attempt to adjust anything inside the de-
vice. If you have any problems, please contact the store or the doctor
from whom you purchased this unit or please contact Rossmax Inter-
national Ltd.
5. Dispose of device, batteries, components and accessories according to
local regulations.
6. Data link can only be connected with Rossmax blood pressure monitor
and calibrator. It cannot be used for any other purpose.
7. Clean the device carefully with a slightly damp, soft cloth.
4 5
Name/Function of Each Part
kPa mmHg
ReadoutAuto calibrationPressure gauge
Check
count
Clear
count
Set
count
LCD Display
Number
Entry key
Clear key
ON/OFF key
Readout key
Auto Calibration
key
Zero key
Deate key
Inate key
Check Count key
Clear Count key
Set Count key
Air tube socket
Data Link Port
AC Adapter Jack
Data Link Cable
Air Tube and Connector
for Wrist Monitors
Air Tube and Connector
for Upper Arm Monitors
Carrying Bag
AC Adapter
Output: 600mA
(Ø3.8/Ø1.3)
Name/Function of Each Part
6 7
1
2
3
5
6
4
kPa mmHg
ReadoutAuto calibrationPressure gauge
Check
count
Clear
count
Set
count
LCD Display Explanations Using the AC Adapter
1. Connect the AC adapter with the AC adapter jack in the back of the
calibrator.
2. Plug the AC adapter into the socket. Use the compatible AC adapters.
(AC adapters with required voltage and current indicated near the AC
adapter jack.)
• Do not plug or unplug the AC adapter into the electrical
outlet with wet hands.
• Unplug the AC adapter from the electrical outlet after using
the device.
Connection Methods
Upper Arm Blood Pressure Monitor:
1. Connect the tube between the calibrator and the monitor to the air
tube socket.
2. Then connect the data link cable between the calibrator and the moni-
tor to the data link port.
Data Link Cable
Air Tube Date Link Port
Air Tube Socket
1
2
3
5
6
4
Readout Mode: Automatic device pressure checking
1
2
3
5
6
4
Auto Calibration Mode: Automatic device pressure calibration
1
2
3
5
6
4
Pressure Gauge Mode: Digital Manometer feature
1
2
3
5
6
4
Measurement Count Display Mode: Check number of uses
1
2
3
5
6
4
Measurement Count Clearance Mode: Zero setting of uses
1
2
3
5
6
4
Calibration Reminder Setting Mode: Re-set number of use cali-
bration reminder
8 9
Cuff Screw
Connection Methods
Wrist Blood Pressure Monitor:
1. Loosen the screw that secures the cuff to the monitor.
2. Remove the cuff from the monitor.
a. Push cuff to the screw direction.
b. Slightly pull cuff to remove the cuff from the monitor.
3. Connect the tube between the calibrator and the monitor to the air
outlet.
4. Connect the data link cable between the calibrator and the monitors
data link port.
kPa mmHg
ReadoutAuto calibrationPressure gauge
Check
count
Clear
count
Set
count
Operation Procedures
1. Data link status operation
Before operation, make sure the air tube and the data link cable are
securely connected to the calibrator and the blood pressure monitor.
Press the ON/OFF key of the calibrator, then press the M key of the
blood pressure monitor.
Note: If there is no M key on the blood pressure monitor, please press
the ON/OFF key instead.
A loop will appear on the LCD display of the Blood Pressure Monitor,
indicating the data link status.
Data Link Cable
Air Tube
Date Link Port
Air Tube Socket
Calibrator Blood Pressure Monitor
Calibrator Screen Blood Pressure
Monitor Screen
Wrist Cuff
Wrist Cuff
10 11
check point on
Calibrator
check point from Blood
Pressure Monitor
2. Readout Mode
This feature checks monitor pressure, if you would like to ignore
pressure checking , skip to "Auto Calibration Mode"(page 18) directly.
Press “Readout” to start. “RUN” will appear on LCD and pressure is
checked at 0/295/270/240 mmHg points. If the pressure difference
at 0/295/270/240 mmHg is within ± 3mmHg, the calibrator will rapid
exhaust to 0 mmHg, then go on checking 2nd points. If "FAIL" appears
, the faulty pressure points will be shown (both the default pressure
check point and the actual pressure measured will appear alternatively.).
If "FAIL" appears, press the "Auto calibration" key for re-calibration.
After this process is complete, press the "Readout" key to verify
calibration was successful.
Calibrator
Screen
Blood
Pressure
Monitor
Screen
If deviation under ±3mmHg If deviation over ±3mmHg
Check First Pressure Points (295/270/240 mmHg)
Automatic Check 2nd
Pressure Points
Link Code
(Reference Only)
Calibrator Screen Blood Pressure
Monitor Screen
Calibrator Screen Blood Pressure
Monitor Screen
Press Auto Calibration Mode
(follow instructions on Page 18)
Calibrator Screen
Blood Pressure
Monitor Screen
12 13
To check the second pressure levels. “RUN” will appear on LCD and
pressure is checked at 0/210/180/150 mmHg points. If the pressure
difference at 0/210/180/150 mmHg is within ± 3mmHg, the calibrator
will rapid exhaust to 0 mmHg, then go on checking 3rd points. if "FAIL"
appears, the faulty pressure points will be shown (both the default
pressure check point and the actual pressure measured will appear
alternatively.).
If "FAIL" happens, press the "Auto calibration" key for re-calibration.
After this process is complete, press the "Readout" key for double
check.
Checking the pressures between calibrator and
monitor. If the deviation of First Pressure Points is
under ±3mmHg, the calibrator will automatically
check Second Pressure Points (210/180/150 mmHg)
check point on
Calibrator
check point from Blood
Pressure Monitor
If deviation under ±3mmHg If deviation over ±3mmHg
Automatic Check 3rd
Pressure Points
Calibrator Screen Blood Pressure
Monitor Screen
Calibrator Screen Blood Pressure
Monitor Screen
Press Auto Calibration Mode
(follow instructions on Page 18)
Calibrator Screen
Blood Pressure
Monitor Screen
First
Pressure
Points
If deviation between calibrator and
monitor is under ±3mmHg
Second
Pressure
Points
14 15
To check the third pressure levels. “RUN” will appear on LCD and
pressures is checked at 0/120/90/60 mmHg points. If the pressure
difference at 0/120/90/60 mmHg is within ± 3mmHg, the calibrator will
rapid exhaust to 0 mmHg, then go on checking 3rd points. If "FAIL"
appears, the faulty pressure points will be shown (both the default
pressure check point and the actual pressure measured will appear
alternatively.).
If "FAIL" happens, press the "Auto calibration" key for re-calibration.
After this process is complete, press the "Readout" key for double
check.
check point on
Calibrator
check point from Blood
Pressure Monitor
If deviation under ±3mmHg If deviation over ±3mmHg
Automatic Check 4th
Pressure Points
Calibrator Screen Blood Pressure
Monitor Screen
Calibrator Screen Blood Pressure
Monitor Screen
Press Auto Calibration Mode
(follow instructions on Page 18)
Calibrator Screen
Blood Pressure
Monitor Screen
Checking the pressures between calibrator and
monitor. If the deviation of Second Pressure Points
is under ±3mmHg, the calibrator would
automatic check Third Pressure Points
(120/90/60 mmHg)
Second
Pressure
Points
If deviation between calibrator and
monitor is under ±3mmHg
Third
Pressure
Points
16 17
The forth step of checking leves. “RUN” will appear on LCD and
pressures are checked at 0/30 mmHg. If the pressure difference at 0/30
mmHg is within ± 3mmHg, the calibrator shows "PASS". If "FAIL"
appears, the faulty pressure points will be shown (both the default
pressure check point and the actual pressure measured will appear
alternatively.).
If "FAIL" happens, press the "Auto calibration" key for re-calibration.
After this process is complete, press the "Readout" key for double
check.
check point on
Calibrator
check point from Blood
Pressure Monitor
If deviation under ±3mmHg If deviation over ±3mmHg
Readout Check is OK
Calibrator Screen Blood Pressure
Monitor Screen
Calibrator Screen Blood Pressure
Monitor Screen
Press Auto Calibration Mode
(follow instructions on Page 18)
Calibrator Screen
Blood Pressure
Monitor Screen
Checking the pressures between calibrator and
monitor. If the deviation of Third Pressure Points
is under ±3mmHg, the calibrator would
automatic check Forth Pressure Points
(0/30 mmHg)
Third
Pressure
Points
If deviation between calibrator and
monitor is under ±3mmHg
Forth
Pressure
Points
18 19
3. Auto Calibration Mode
If "Readout Mode" result is FAIL, Press “Auto calibration” key to
start. “RUN” appears on LCD, and pressure values are programmed at
0/300/200/100 mmHg. If the programming is successful, “PASS” will
appear. Otherwise “FAIL” will appear. If "FAIL" continues to appear,
return the monitor to the manufacturer for service.
mmHg
Auto calibration
mmHg
Auto calibration
mmHg
Auto calibration
mmHg
Auto calibration
or
Auto Calibration Mode
Calibrator Screen Blood Pressure Monitor Screen
Link Code
(Reference Only)
Link Code
(Reference Only)
Calibrator Screen Blood Pressure
Monitor Screen
Indice
Altri manuali Rossmax Apparecchiature di prova
Manuali Apparecchiature di prova popolari di altre marche
SMART
SMART KANAAD SBT XTREME 3G Series Manuale utente
Agilent Technologies
Agilent Technologies BERT Serial Manuale utente
Agilent Technologies
Agilent Technologies N3280A Manuale utente
Vernier
Vernier Go Direct Voltage Manuale utente
Lifeloc
Lifeloc R.A.D.A.R. Manuale utente
Fluke
Fluke T5-600 Istruzioni per l'uso e l'installazione
