RSA Lighting QCT2075 Manuale utente

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

A...Trimless Fixture

Round adjustable truncated cone

trimless ﬁxture. Includes bullet plunger

retainers for smooth snap-in action

during installation and removal of trim for

relamping. Helps guard against plaster

cracking.

B ...Lamp

For use with 12V MR16 lamp 71W max.

or CMH MR16 20W or 39W. Lamp not

included. 12V MR16 ﬁxture includes clear

protective glass lens and can accept up

to three (3) optical accessories total.

C ...Socket

Posi-Grip bi-pin socket for 12V MR16.

GX10 for metal halide lamps. (Included

with Quiet Ceiling Housing sold

separately)

D...Reﬂector

Etched aluminum reﬂector is cut at a 35˚

angle.

E ...Finish

Trim face is powder coated in white,

black, industrial silver, stainless

steel or primer ﬁnish for painting in

existing ceiling color. All other internal

components are ﬂat black.

F....Safety

Steel safety cable provided. Attaches

to tab inside housing to prevent falling

during maintenance or as a result of

accidental dislodging of the trim.

QUIET CEILING

TRIMLESS

QCT2075

4” Round Trimless

Recessed Truncated

Cone Fixture

FOR 12V MR16 71W max.

CMH MR16 20W or 39W

Compatible Housings:

QCT900 / QCT900MH

QCT902IC / QCT902ICMH

QCT904RM / QCT904RMMH

QCT906SP / QCT906SPMH

ORDERING INFORMATION

Fixture

QCT2075 =

4” Round Trimless

Adjustable Truncated Cone

Fixture for 12V MR16 or CMH

MR16

4” round recessed trimless adjustable truncated cone ﬁxture. For use

with 12V MR16 lamp 71W max. or CMHMR16 20W or 39W.

For use in downlighting / accent applications.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

Finish

WH =White

BK =Black

S =Industrial Silver

SS =Stainless Steel (painted)

PM =Primer

QCT2075

Ceiling mudding compound is applied

right to the edge of the ﬁxture.

rev 030108

• 12V MR16 71W max.

• CMH MR16 20W or 39W

+/- 15º

4.00"

DIA.

3.00"

DIA.
