RG-AP680-O(V3)

Wi-Fi 6 Dual-radio Access Point

-1-

Product Pictures

Product Overview

The RG-AP680-O(V3) is a Wi-Fi 6 wireless access point that delivers dual radios, high performance, and enterprise-

grade encryption. Its hybrid cloud management mode and high-density access design allow the RG-AP680-O(V3) to

be exibly deployed in high-quality outdoor network scenarios, including outdoor hotspots such as parks and streets

in smart cities, sports eld scenarios in the education industry, and scenarios related to energy and rail transportation

industry.

-2-

Product Highlights

Ultra-High

Performance

Flexible

Networking

High Security

and Reliability

Ultra-High Performance

● Dual-band design (2.4 GHz + 5 GHz), four spatial streams,

1024-Quadrature Amplitude Modulation (QAM) high-

speed access, up to 2.976 Gbps peak data rate, and built-

in intelligent omnidirectional antenna, realizing high-speed

wireless access experience

● Orthogonal Frequency-Division Multiple Access (OFDMA),

Multi-User Multiple-Input Multiple-Output (MU-MIMO), and

Wi-Fi Multimedia (WMM), increasing the average rate per

user in high-density deployment environments

● RF power adjustment and intelligent channel allocation to

solve the problems such as co-channel interference and

adjacent channel interference, thereby improving network

transmission efciency and stability

● Packet-based power control technology and high-

performance power design, saving energy while providing

high-speed wireless access service

Flexible Networking

● Local and cloud management modes, and intelligent

wireless network optimization, reducing TCO and

maximizing ROI

● Access through optical and Ethernet cables for flexible

networking and high-speed backhaul over 2.5 Gbps optical

links

● IEEE 802.11k/v/r support and roaming stickiness

optimization, achieving seamless user roaming

● Rich IoT features: Bluetooth 5.1, and wireless locating

High Security and Reliability

● IP68 rated housing, adapting to harsh outdoor

environments

● Encryption and authentication technologies including Wi-

Fi Protected Access 3 (WPA3), enhanced open security,

802.1X, and Private Pre-shared Key (PPSK), enhancing

data security

● Dynamic Frequency Selection (DFS), optimizing the

use of available RF spectrum to prevent radar channel

interference

● Cyclic Delay/Shift Diversity (CDD/CSD), Maximum Ratio

Combining (MRC), Space-Time Block Coding (STBC), and

Low-Density Parity Check (LDPC), improving the signal

quality, signal receiving, and reliability and performance of

data transmission

● Transmit beam-forming (TxBF) expands the signal

coverage and enhances the reliability of specic devices,

thereby improving the data rate

● Intelligent identification and monitoring, multicast-to-

unicast conversion, and other features, enhancing network

security and reliability

-3-

Applicable Scenarios

Smart City

Parks

With Wi-Fi deployed in parks, people can enjoy high-speed

mobile internet access anytime, anywhere. They can exibly

and easily enjoy Internet services, including browsing the web,

watching videos, and engaging in voice and video chats with

friends.

Higher Education

Sports Field

You can cheer and show support for sports events on the

spots eld, and share moments in real time on social media.

High-speed mobile Wi-Fi allows you to leave real-time

memories.

Product Features

Multi-scenario Adaptability

The RG-AP680-O(V3) is a dual-band outdoor wireless

access point designed for outdoor scenarios such as smart

cities, higher education, general education, energy, and rail

transportation. It can be deployed in various scenarios to meet

diverse service requirements.

High-speed Access and Compatibility

The RG-AP680-O(V3) supports various wireless protocols,

such as 802.11ax, 802.11ac Wave2, 802.11ac Wave1, and

802.11n. It features a hardware-independent dual-band

design to deliver a data rate of up to 2.976 Gbps, effectively

eliminating wireless performance bottlenecks. Additionally,

it is compatible with an extensive array of devices,

promoting seamless interconnectivity among employees

and customers.

Security and Scalability

The RG-AP680-O(V3) stands out with its exceptional wireless

network security, RF control, mobile access, QoS guarantee,

and seamless roaming. With Ruijie's wireless access controller

(AC), it enables wireless user data forwarding, security, and

access control to cope with diverse service needs.

Flexible Deployment and Power Supply

The RG-AP680-O(V3) supports both local power supply and

Power over Ethernet (PoE), providing you with the exibility to

choose the power supply mode. In addition, the RG-AP680-

O(V3) can be mounted against a wall or pole, making space

deployment and environmental requirements less challenging.

This makes the RG-AP680-O(V3) particularly suitable for

scenarios such as parks, sports elds, and rail transportation

scenarios.

-4-

Solution Scalability Capabilities

Ruijie WIS Cloud Management Network Solution (WIS for

short) provides full-lifecycle cloud management network

services covering network procurement, planning, deployment,

acceptance, and O&M. When the AP connects to WIS, it can

meet various needs in multiple scenarios including planning,

deployment, acceptance, and operation through cloud

management, cloud O&M, cloud authentication, and other

value-added services provided by WIS.

Network-wide Cloud Management

WIS supports integrated management and control of various

types of devices including APs, ACs, switches, gateways, and

routers. It supports remote O&M management operations

such as adding or batch importing of multi-branch network

devices, online status monitoring, configuration delivery,

upgrade, restart, configuration backup, and restoration. It

supports network-wide topology auto-discovery and topology

status monitoring.

Wireless Network Visualization

The overview function module of WIS provides a

comprehensive view of the network running status from the

perspective of overview, experience, users, devices, and

environment. The network running information includes the

Intelligent Network Diagnosis

With WIS, wireless network diagnosis and health index

assessment can be completed in just one click, providing

test results for each item. The health index provided by WIS

enables you to rapidly assess the state of your live network.

WIS can locate faulty areas, APs, and STAs, and provides

potential risks and corresponding optimization suggestions.

following items:

● Network basic information: device stability, device health,

user stability, network signal coverage, and network

association.

● User usage: user activity (network dependency), and user

online experience and analysis

● Network saturation: network capacity usage and channel

usage

-5-

Product Specications

Hardware Specications

Hardware Specications RG-AP680-O(V3)

802.11n

Four spatial streams

● Radio 1 – 2.4 GHz: 2x2 MIMO, two spatial streams

● Radio 2 – 5 GHz: 2x2 MIMO, two spatial streams

Channels:

● Radio 1 – 2.4 GHz: 20 MHz and 40 MHz

● Radio 2 – 5 GHz: 20 MHz and 40 MHz

Combined peak data rate: 600Mbps

● Radio 1 – 2.4 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15 )

● Radio 2 – 5 GHz: 6.5 Mbps to 300 Mbps (MCS0 to MCS15)

Radio technologies: Orthogonal Frequency-Division Multiplexing (OFDM)

Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM

Packet aggregation:

● Aggregate MAC Protocol Data Unit (A-MPDU)

● Aggregate MAC Service Data Unit (A-MSDU)

Dynamic Frequency Selection (DFS)

Cyclic Delay/Shift Diversity (CDD/CSD)

Maximum Ratio Combining (MRC)

Space-Time Block Coding (STBC)

Low-Density Parity Check (LDPC)

Transmit beam-forming (TxBF)

802.11ac

Two spatial streams

● Radio 2 – 5 GHz: 2x2 MIMO, two spatial streams

Channels:

● Radio 2 – 5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz

Combined peak data rate: 1.732 Gbps

● Radio 2 – 5 GHz: 6.5 Mbps to 1.732 Gbps (MCS0 to MCS9)

Radio technologies: Orthogonal Frequency-Division Multiplexing (OFDM)

Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM

Packet aggregation:

● Aggregate MAC Protocol Data Unit (A-MPDU)

● Aggregate MAC Service Data Unit (A-MSDU)

Dynamic Frequency Selection (DFS)

Cyclic Delay/Shift Diversity (CDD/CSD)

Maximum Ratio Combining (MRC)

Space-Time Block Coding (STBC)

Low-Density Parity Check (LDPC)

Transmit beam-forming (TxBF)

802.11ax

Four spatial streams

● Radio 1 – 2.4 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams

● Radio 2 – 5 GHz: 2x2 uplink/downlink MU-MIMO, two spatial streams

Channels:

● Radio 1 – 2.4 GHz: 20 MHz and 40 MHz

● Radio 2 – 5 GHz: 20 MHz, 40 MHz, 80 MHz, and 160 MHz

Combined peak data rate: 2.976 Gbps

● Radio 1 – 2.4 GHz: 8.6 Mbps to 0.574 Gbps (MCS0 to MCS11)

● Radio 2 – 5 GHz: 8.6 Mbps to 2.402 Gbps (MCS0 to MCS11)

-6-

Hardware Specications RG-AP680-O(V3)

802.11ax

Radio technologies: uplink/downlink Orthogonal Frequency-Division Multiple Access (OFDMA)

Modulation types: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM

Packet aggregation:

● Aggregate MAC Protocol Data Unit (A-MPDU)

● Aggregate MAC Service Data Unit (A-MSDU)

Dynamic Frequency Selection (DFS)

Cyclic Delay/Shift Diversity (CDD/CSD)

Maximum Ratio Combining (MRC)

Space-Time Block Coding (STBC)

Low-Density Parity Check (LDPC)

Transmit beam-forming (TxBF)

WPA3

Antenna

Wi-Fi

● 2.4 GHz: two built-in omnidirectional antennas, the max. antenna gain is 4 dBi.

● 5 GHz: two built-in omnidirectional antennas, the max. antenna gain is 6 dBi.

Bluetooth

● One integrated vertically polarized omnidirectional antenna, the max. antenna gain is 5 dBi.

Port

1 x 100/1000Base-T RJ45 Ethernet port with auto-negotiation

1 x 2.5GE combo SFP port

1 x RJ45 console port (serial console port)

1 x Bluetooth 5.0

Status LED

1 x multi-color system status LED

● AP power-on status

● Software initialization status and upgrade status

● Uplink service interface status

● Wireless user online status

● CAPWAP tunnel timeout

● Specic AP locating

Three single-color signal strength LEDs:

● Whether bridging is enabled

● Whether bridging is successful

● Wireless signal strength after successful bridging

Button

1 x Reset button

● Press the button for shorter than 2 seconds. Then the device restarts.

● Press the button for longer than 5 seconds. Then the device restores to factory settings.

Dimensions (W x D x H) Main unit: 251 mm x 168 mm x 64 mm (9.88 in. x 6.61 in. x 2.52 in.)

Shipping: 405 mm x 232 mm x 325 mm (15.94 in. x 9.13 in. x 12.80 in.)

Weight

Main unit: 1.0 kg (2.2 lbs)

Mounting bracket: 0.9 kg (1.98 lbs)

Shipping: 3.15 kg (6.94 lbs)

Mounting Wall or Pole-mounting (a mounting bracket is delivered with the main unit)

Input power supply

The AP supports the following two power supply modes:

● 48 V DC/0.35 A power input over DC connector: The DC connector accepts the center-positive

circular plug with the inner diameter of 2.0 mm (0.08 in.) or outer diameter of 6.3 mm (0.25 in.) and

the length of 9.8 mm (0.39 in.). A DC power supply needs to be purchased independently.

● PoE input over ETH/PoE: The power source equipment (PSE) complies with IEEE 802.3af/at

standard (PoE/PoE+).

Note: If both DC power and PoE are available, DC power is preferred.

-7-

Hardware Specications RG-AP680-O(V3)

Power consumption

Maximum power consumption: 12.95 W

● DC power: 12.95 W

● 802.3at (PoE+): 12.95 W

● 802.3af (PoE): 12.95 W

● Idle mode: 6.0 W

Environment

Storage temperature: –40°C to +85°C (–40°F to +185°F)

Storage humidity: 0% RH to 100% RH (non-condensing)

Storage altitude: < 5,000 m (16,404.20 ft.) at 25°C (77°F)

Operating temperature: –40°C to +65°C (-40°F to +149°F)

Operating humidity: 0% RH to 100% RH (non-condensing)

Operating altitude: < 5,000 m (16,404.20 ft.) at 55°C (131°F)

At an altitude between 3,000 m (9,842.52 ft.) and 5,000 m (16,404.20 ft.), every time the altitude

increases by 166 m (546 ft.), the maximum temperature decreases by 1°C (1.8°F).

IP Rating IP68

Mean Time

Between Failure (MTBF) 200,000 hours (22 years) at the operating temperature of 25°C (77°F)

System memory 512 MB DRAM, 128 MB ash

Transmit power

2.4 GHz

● Max. transmit power: 28 dBm (630.96 mW)

● Minimum transmit power: 10 dBm (10 mW)

5 GHz

● Max. transmit power: 28 dBm (630.96 mW)

● Minimum transmit power: 10 dBm (10 mW)

Note: The transmit power adjusted in percentage. The transmit power is limited by local regulatory

requirements.

The following table lists the radio frequency performance of Wi-Fi including different frequency bands, protocols, and date rates.

It is country-specic, and Ruijie Networks reserves the right of interpretation.

Radio Frequency Performance RG-AP680-O(V3)

Frequency Band and Protocol Data Rate Max. Transmit Power per

Transmit Chain

Max. Receive Sensitivity

per Receive Chain

2.4 GHz, 802.11b

1 Mbps 25 dBm –92 dBm

2 Mbps 25 dBm –82 dBm

5.5 Mbps 25 dBm –84 dBm

11 Mbps 25 dBm –78 dBm

2.4 GHz, 802.11g

6 Mbps 25 dBm –84 dBm

24 Mbps 23 dBm –74 dBm

36 Mbps 23 dBm –72 dBm

-8-

Radio Frequency Performance RG-AP680-O(V3)

Frequency Band and Protocol Data Rate Max. Transmit Power per

Transmit Chain

Max. Receive Sensitivity

per Receive Chain

2.4 GHz, 802.11g 54 Mbps 20 dBm –67 dBm

2.4 GHz, 802.11n (HT20)

MCS0 25 dBm –84 dBm

MCS7 20 dBm –66 dBm

2.4 GHz, 802.11n (HT40)

MCS0 25 dBm –79 dBm

MCS7 20 dBm –63 dBm

2.4 GHz, 802.11ax (HE20)

MCS0 25 dBm –84dBm

MCS11 18 dBm –54 dBm

2.4 GHz, 802.11ax (HE40)

MCS0 25 dBm –80 dBm

MCS11 18 dBm –51 dBm

5 GHz, 802.11a

6 Mbps 25 dBm –84 dBm

24 Mbps 23 dBm –74 dBm

36 Mbps 23 dBm –72 dBm

54 Mbps 20 dBm –67 dBm

5 GHz, 802.11n (HT20)

MCS0 25 dBm –84 dBm

MCS7 20 dBm –66 dBm

5 GHz, 802.11n (HT40)

MCS0 25 dBm –81 dBm

MCS7 20 dBm –63 dBm

5 GHz, 802.11ac (VHT20)

MCS0 25dBm –84 dBm

MCS9 19 dBm –61 dBm

5 GHz, 802.11ac (VHT40)

MCS0 25 dBm –81 dBm

MCS9 19 dBm –56 dBm

5 GHz, 802.11ac (VHT80)

MCS0 25 dBm –78 dBm

MCS9 19 dBm –53 dBm

-9-

Radio Frequency Performance RG-AP680-O(V3)

Frequency Band and Protocol Data Rate Max. Transmit Power per

Transmit Chain

Max. Receive Sensitivity

per Receive Chain

5 GHz, 802.11ax (HE20)

MCS0 25 dBm –84 dBm

MCS11 18 dBm –54 dBm

5 GHz, 802.11ax (HE40)

MCS0 25 dBm –81 dBm

MCS11 18 dBm –51 dBm

5 GHz, 802.11ax (HE80)

MCS0 25 dBm –78 dBm

MCS11 18 dBm –48 dBm

5 GHz, 802.11ax (HE160)

MCS0 25 dBm –73 dBm

MCS11 18 dBm –43 dBm

Software Specications

Software Specications RG-AP680-O(V3)

Basic Functions

Applicable software version RGOS11.9(6)W2B4 or higher

WLAN

Max. number of associated

STAs 1,024 (up to 512 STAs per radio)

Max. number of BSSIDs 32 (up to 16 BSSIDs per radio)

Max. number of WLAN IDs 16

STA management

SSID hiding

Each SSID can be configured with the authentication mode, encryption mechanism, and VLAN

attributes independently.

Remote Intelligent Perception Technology (RIPT)

Intelligent STA identication

Intelligent load balancing based on the STA quantity or trafc

STA limiting SSID-based STA limiting

Radio-based STA limiting

Bandwidth limiting STA/SSID/AP-based rate limiting

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Ruijie Punto di accesso wireless

Ruijie

Ruijie RG-AP630 Directional Manuale utente

Ruijie

Ruijie RG-WLAN Series Manuale utente

Ruijie

Ruijie RG-MAP852-SF-U Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RG-RAP2260 Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP820-I Manuale di installazione e funzionamento

Ruijie

Ruijie HA3515-DG Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP840-I (V2) Manuale di installazione e funzionamento

Ruijie

Ruijie RG-SAP825-SP Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP680 CD Series Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP520 Series Manuale di installazione e funzionamento

Ruijie

Ruijie RG-MAP852-SF-S Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RG-RAP1201 Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RG-RAP6202(G) Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RG-RAP52-OD Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RAP6260-D Manuale di installazione e funzionamento

Ruijie

Ruijie RG-RAP1200 Series Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP840-I Series Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee Series Dimensioni

Ruijie

Ruijie RG-AP180-I Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP680-CD Manuale di installazione e funzionamento

Ruijie

Ruijie Reyee RG-RAP1260 Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP740-I Series Manuale di installazione e funzionamento

Ruijie

Ruijie RG-SAP750-SP Manuale di installazione e funzionamento

Ruijie

Ruijie RG-AP850-I-V2 Series Manuale di installazione e funzionamento

Manuali Punto di accesso wireless popolari di altre marche

D-Link

D-Link DWL-2100AP - AirPlus Xtreme G Manuale utente

Ubiquiti

Ubiquiti NanoStation NSM2 Manuale utente

Cisco

Cisco Aironet 1550 Series Manuale utente

Aruba

Aruba IAP-335 Manuale utente

Advantek Networks

Advantek Networks AWN-AP-54MR Manuale utente

IP-COM

IP-COM AP355 Manuale utente

Buffalo

Buffalo AirStation WLA-L11G Manuale utente

EnGenius

EnGenius EnStationACv2 Manuale utente

D-Link

D-Link DAP-3662 Manuale utente

xG Technology

xG Technology xMax CN1300 Manuale utente

Widelink

Widelink ezWave WAP-1100 Series Manuale utente

Edimax

Edimax CAP1200 Manuale utente

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuale utente

Aruba

Aruba AP-203R Manuale utente

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuale utente

CreatComm

CreatComm TB5F Manuale utente

SineDigital

SineDigital MW-1500AP(H) Manuale utente

TP-Link

TP-Link AP9650 V1 Manuale utente
