Sage Barista Touch SES880BTR Manuale utente

the Barista Touch™

SES880

• Before using the rst time ensure

your electricity supply is the

same as shown on the label on

the underside of the appliance.

• Remove and safely discard

any packaging materials before

rst use.

• To eliminate a choking hazard

for young children, safely discard

the protective cover tted to the

power plug.

• This appliance is for household

use only. Do not use the

appliance for anything other

than its intended use. Do not

use in moving vehicles or

boats. Do not use outdoors.

Misuse may cause injury.

• Fully unwind the power cord

before operating.

• Position the appliance on

a stable, heat resistant, level,

dry surface away from the edge

and do not operate on or near

a heat source such as a hot

plate, oven or gas hob.

• Do not let the power cord

hang over the edge of a bench

or table, touch hot surfaces

or become knotted.

• Do not leave the appliance

unattended when in use.

• Always ensure the appliance

is turned OFF, unplugged at

the power outlet and has been

2 Important Safeguards

5 Components

7 Functions

13 Care & Cleaning

17 Troubleshooting

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage®we are very safety

conscious. We design and

manufacture consumer

products with the safety of

you, our valued customer,

foremost in mind. In addition

we ask that you exercise a

degree of care when using

any electrical appliance

and adhere to the following

precautions.

IMPORTANT

SAFEGUARDS

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE FOR

FUTURE REFERENCE

• The full information

book is available at

sageappliances.com

Contents

allowed to cool before cleaning,

attempting to move or storing.

• Always turn the appliance to

the o position, switch o at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Do not use the appliance if the

power cord, plug, or appliance

becomes damaged in any way.

If damaged or maintenance

other than cleaning is

required, please contact Sage

Customer Service or go to

sageappliances.com

• Any maintenance other than

cleaning should be performed

by an authorised Sage

service centre

• Children should not play with

the appliance.

• Cleaning of the appliance

should not be carried out by

children unless they are 8 year

or older and supervised

• The appliance and it’s cord

should be kept out of reach

of children aged 8 years

and younger

• The installation of a residual

current safety switch is

recommended to provide

additional safety when using

all electrical appliances.

Safety switches with a rated

operating current not more

than 30mA are recommended.

Consult an electrician for

professional advice

• Do not use attachments

other than those provided

with the appliances.

• Do not attempt to operate

the appliance by any method

other than those described

in this booklet.

• Do not move the appliance

whilst in operation

• Do not touch hot surfaces.

Allow the appliance to cool

down before moving or

cleaning any parts.

• This appliance shall not be

used by children. Keep the

appliance and its cord out

of reach of children.

• This appliance can be used

by persons with reduced

physical, sensory or mental

capabilities or a lack of

experience and knowledge,

only if they have been given

supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved.

• Do not operate the grinder

without the hopper lid in position.

Keep ngers, hands, hair,

clothing and utensils away from

the hopper during operation.

SPECIFIC

INSTRUCTIONS

FOR WATER

FILTER

• Filter cartridge should be kept

out of reach of children.

• Stores lter cartridges in a dry

place in the original packaging.

• Protect cartridges from heat and

direct sunlight.

• Do not use damaged

lter cartridges.

• Do not open lter cartridges.

• If you are absent for a prolonged

period of time, empty the water

tank and replace the cartridge.

The symbol shown

indicates that this appliance

should not be disposed of

in normal household waste.

It should be taken to a local

authority waste collection centre

designated for this purpose or

to a dealer providing this service.

For more information, please

contact your local council oce.

To protect against electric

shock do not immerse the

power plug, cord or appliance

in water or any liquid.

• Use only tap water in the water

tank. Do not use any other liquid.

• Never use the appliance without

water in the water tank.

• Ensure the portalter is rmly

inserted and secured into the

brewing head before using

the machine.

• Never remove the portalter

during the brewing operation as

the machine is under pressure.

• Do not place anything, other

than cups for warming, on top

of the appliance.

• Heating element surface is

subject to residual heat

after use.

SAVE THESE

INSTRUCTIONS

Components

A. 250g bean hopper

B. Integrated conical burr grinder

C. Touch screen control panel

D. GRIND SIZE selector

E. POWER button

F. Integrated removable 54mm tamper

G. Grind outlet

H. Hands free grinding cradle

I. 54mm stainless steel portalter

J. Removable wet & dry coee separator

drip tray

K. 2L removable water tank

L. Group Head

M. Dedicated hot water outlet

N. Extra-tall cup clearance for tall mugs

O. Easy clean steam wand

P. Milk temperature sensor

Q. Storage tray (located behind drip tray)

Rating Information

220–240V~ 50–60Hz 1380–1650W

ACCESSORIES

1. Stainless steel milk jug

2. Cleaning disc

3. Cleaning tablets

4. Dual Wall lter baskets (1 cup & 2 cup)

Use with pre-ground coee.

5. Single Wall lter baskets (1 cup & 2 cup)

Use when grinding fresh whole coee beans.

6. Water lter and holder

7. Cleaning brush

8. The Razor™ precision dose trimming tool

9. Allen key

To disassemble shower screen

10.Steam wand cleaning tool

11.Water hardness test strip

All parts of the Barista Touch™

that come into contact with coee,

water and milk are BPA Free.

7 8 9

4 5

Functions

INSTALLING THE WATER FILTER

• Remove the water lter and water lter holder

from the plastic bag.

• Soak the lter in cold water for 5 minutes.

• Wash the lter holder with cold water.

• Set the reminder for next month of replacement.

We recommend to replace the lter after

3 months.

• Insert the lter into the two parts of the

lter holder.

• To install the assembled lter holder into the

water tank, align the base of the lter holder

with the adapter inside the water tank.

Push down to lock into place.

• Fill the water tank with cold water before sliding

back into position at the back of the machine and

locking into place.

FIRST USE

1. Press POWER button to turn the machine on.

2. Follow the instructions on screen to guide you

through rst use setup.

3. After completing setup, the machine will tell that

it is ready to use.

The machine is now in STANDBY mode.

GuideExit

Your Barista Touch is now ready

Select the guide to find out more about your Barista Touch

or exit to proceed to your drink selection

4. Touch "Guide" and the machine will guide you

step by step to make your rst coee. Touch the

and go to the Drinks Menu or <to repeat the

Setup. To repeat the Guide at any time, go to

Settings Menu.

NOTE

If your water hardness is either 4 or 5 when tested,

we strongly recommend you change to an alternate

water source.

GRINDING OPERATION

Insert bean hopper into position on-top of the

machine. Turn dial to lock into place. Fill hopper

with fresh beans.

DRINK SELECTION

To enter Drinks Menu screen, touch the Home icon . Swipe & select your drink.

Touch the ‘Help & Tip’ icon to see Barista Touch™Guide.

Select your drink

Espresso

Long Black Latte Flat White

Cappuccino

NOTE

Please keep the touch screen dry and clean to ensure that the machine functions properly.

DRINK SCREEN

Grind duration

(single / double /

custom) Milk froth level

Drink chosen

Milk temperature

‘Setting’ icon

Brew setting: touch this button to scroll

Espresso – single shot / double shot / custom extraction time

Long Black – small / medium / large

Grind size

‘Home’ icon

Brew

Cappuccino

Double

Grind Milk

65º

15s

Hot Water

SETTING GRIND SIZE

Selecting Your Filter Basket

Single Wall Filter Baskets

Use Single Wall lter baskets if grinding fresh

whole coee beans.

1 CUP 2 CUP

Dual Wall Filter Baskets

Use Dual Wall lter baskets if using

pre-ground coee.

1 CUP 2 CUP

Selecting Grind Size

In the touchscreen, select the chosen lter

basket by touching the toggle option under the

‘Grind’ button.

Automatic Dosing

• Touch the ‘Grind’ button once, or push and

release the portalter to engage the grinding

activation switch. Then allow fresh ground coee

to ll the portalter.

• Grinding will automatically stop, however if

you wish to stop grinding before the cycle has

nished, push and release the portalter.

Manual Dosing

• If you prefer to manually dose, with the portalter

inserted in the grinding cradle, push and hold

the portalter to engage the grinding activation

switch. Continue holding until the desired amount

of ground coee has been dosed.

• To stop grinding, release the portalter.

This will release the grinding activation switch

and stop the grinding function.

Tamping the Ground Coee

• Once grinding is complete, Tamp down rmly.

• As a guide to dose, the top edge of the metal cap

on the tamper should be level with the top of the

lter basket AFTER the coee has been tamped.

Trimming the Dose

The Razor™ precision dose trimming tool

allows you to trim the puck to the right level

for a consistent extraction.

• Insert the Razor™ dose trimming tool into the lter

basket until the shoulders of the tool rest on the

rim of the basket.

• Rotate the Razor™ dose trimming tool back and

forth while holding the portalter on an angle over

a knock box to trim o excess coee grinds

• Wipe excess coee from the rim of the lter

basket to ensure a proper seal is achieved in the

group head.

Purging the Group Head

Before placing the portalter into the group head,

run a short ow of water through the group head by

touching the ‘Hot Water’ button. This will stabilise

the temperature prior to extraction.

Inserting the Portalter

Insert the portalter into the group head and rotate

the handle towards the centre until resistance is felt.

LOCK TIGHT

ESPRESSO EXTRACTION

Touch the ‘Brew’ button on the display to start

extraction. You can switch between single shot,

double shot or Custom by touching the ‘Single’,

‘Double’ or Custom button. The duration times

are preset, but can be customised.

Brew

Double

Brew

Single

Brew

Custom

22s

MANUAL OVERRIDE

Press and hold the ‘Brew’ button (approx 2 secs)

to enter manual extraction mode. Touch the Brew

button to start the extraction, touch the Brew button

to stop the extraction.

TEXTURING MILK

MIN

MAX

MILK MUST

COVER THIS

RING

NOTE

Use the indicator on the screen for the correct milk

jug position.

Under the ‘Milk’ button, temperature level and

froth level are displayed. They are preset based

on the drink you’ve chosen but you can customise

by touching those options.

To start, touch the ‘Milk’ button. The screen will

display the temperature of the milk as it heats.

Milk texturing will stop automatically when the

selected milk temperature is reached. Lift steam

wand to remove milk jug. Wipe the wand & tip with

a clean damp cloth. Lower steam wand to the down

position and the wand will automatically purge.

NOTE

Prior to texturing milk, it is recommended to

momentarily purge the steam wand by rst

touching the ‘Milk’ button. Touching the button

again will stop steam delivery.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Sage Macchina per il caffè

Sage

Sage Smart Grinder Pro BCG820 Manuale utente

Sage

Sage Barista Express BES870 Manuale utente

Sage

Sage the Oracle Touch BES990 Manuale utente

Sage

Sage Barista Touch SES880BSS Manuale utente

Sage

Sage Dual Boiler SES920 Manuale utente

Sage

Sage Barista Touch SES880 Manuale utente

Sage

Sage Bambino Plus SES500 Manuale utente

Sage

Sage the Barista Pro SES878 Manuale utente

Sage

Sage BES810 Manuale utente

Sage

Sage Oracle Touch SES990 Manuale utente

Sage

Sage Barista Express Impress SES876 Manuale utente

Sage

Sage Barista Touch SES880 Manuale utente

Sage

Sage Oracle Touch SES990BST Manuale utente

Sage

Sage BTC410 Manuale utente

Sage

Sage Nespresso Vertuo Creatista SVE850 Manuale utente

Sage

Sage Precision Brewer Manuale utente

Sage

Sage Oracle Touch Manuale utente

Sage

Sage Duo-Temp Pro BES810 Manuale utente

Sage

Sage the Bambino SES450BSS4GUK1 Manuale utente

Sage

Sage Barista Touch SES880 Manuale utente

Sage

Sage The Oracle BES980 Manuale utente

Sage

Sage Barista Express SES875UK Manuale utente

Sage

Sage Milk Cafe BMF600 Manuale utente

Sage

Sage Barista Express SES870 Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente
