Samsung AD68-04851A Manuale di istruzioni

ENG / SPA / FRE

Quick Start Manual

Guide de prise en main repide

WP10

Health and safety informationContents

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach of

small children and animals. Small parts may cause choking

or serious injury if swallowed. Moving parts and accessories

may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/3 ft) to

people or animals. Using the ﬂash too close to your subject’s

eyes can cause temporary or permanent damage.

Health and safety

information…………………… 2

Camera layout ……………… 4

Setting up your camera …… 5

Unpacking ……………………… 5

Inserting the battery and

memory card …………………… 6

Charging the battery …………… 6

Turning on your camera………… 7

Selecting options ……………… 7

Waterproof management

…… 8

Capturing photos or videos

…10

Playing ﬁles ………………… 11

Transferring ﬁles to a PC

(Windows) …………………… 12

Speciﬁcations ……………… 13

English

Exercise caution when connecting cables or adapters•

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

Do not insert foreign objects into any of your camera’s•

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very•

cold or very hot temperatures (below 0° C/32° F or

above 40° C/104° F). Extreme temperatures can

reduce the charging capacity of your batteries and

can cause memory cards to malfunction.

Prevent memory cards from making contact with•

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting

in your camera.

It is advisable to replace waterproof components

once a year to maintain the waterproof performance.

Contact your nearest Samsung service center for the•

replacement of waterproof components.

Handle and dispose of batteries and chargers with

care

Use only Samsung-approved batteries and chargers.•

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never place batteries or cameras on or in heating•

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

Do not open the battery cover or the USB cover in the

sea, a lake or in similar underwater conditions. Do not

open the battery cover or the USB cover with a wet

hand either.

It may cause electric shock or camera malfunction.•

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can•

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,•

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

Camera layout

Shutter button

Flash

POWER button

Speaker

Lens

AF-assist light/timer lamp

Microphone

Strap eyelet

USB / AV / DC terminal

Status lamp

Zoom button

MODE button

Navigation button/OK button

Fn / Delete button

Battery chamber cover

Playback button

MENU button

Tripod mount

LCD monitor

English

Setting up your camera

Please check that you have the correct contents before using this product. The contents can vary depending on the sales region.

To buy the optional equipment, contact your nearest Samsung dealer or Samsung service centre.

Unpacking

Camera Rechargeable Battery AC adapter/

USB cable

Camera strap Quick Start Manual Software CD-ROM

(User manual included)

Memory cards Camera case

A/V cable Battery charger

Optional accessories

Setting up your camera

Inserting the battery and memory card Charging the battery

Before using the camera for the ﬁrst time, you must

charge the battery.

Push gently until the card

disengages from the camera

and then pull it out of the slot.

▼

Removing the memroy card

▼

Removing the battery

With the Samsung

logo facing up

With the gold-colored

contacts facing down

Indicator light

Red▪: Charging

Green▪: Fully charged

English

In Shooting mode, press [

Use the navigation buttons to scroll to an

option or menu.

Back

Photo Size

Move

To move left or right, press [▪] or [ ].

To move up or down, press [▪] or [ ].

Press [

] to conﬁrm the highlighted option or

menu.

Press [▪] again to go back to the previous

menu.

Selecting options

Press [

POWER].

The intial setup screen appears.▪

Exit Change

Language

Time Zone

Date & Time

: English

: London

: 2010/03/01

Press [

] to select Language.

Press [

] or [ ] to select a language and

press [ ].

Press [

] or [ ] to select Time Zone and

press [ ].

Press [

] or [ ] to select a time zone and press

[].

Press [

] or [ ] to select Date & Time and

press [ ].

Press [

] or [ ] to select an item.

Press [

] or [ ] to change the number or

select another date format and press [ ].

Turning on your camera

Waterproof management

The camera requires the appropriate care for

waterproof management before and after using the

camera.

•Theaccessoriesthatcamewiththecameraarenot

waterproof.

•Refertotheusermanualformoreinformation.

Before using the waterproof function

Check the camera before using the waterproof

function.

Make sure that there are no foreign objects

or moisture on the battery chamber cover or

the USB cover. If there are foreign objects or

moisture on the battery chamber cover or the

USB cover, wipe them with a smooth, lint free

cloth. Also check if there are any scratches on

the waterproof seal.

USB cover Battery chamber cover

Make sure that the battery chamber cover and

the USB cover make a clicking sound when

closing them, so that they are ﬁrmly shut.

English

After using the waterproof function

Wash the camera after using the waterproof

function.

First, close the battery chamber cover and the

USB cover after using the camera, and wash

the sand, salt or other foreign objects off by

submerging the camera into clean water for 2

to 3 minutes.

Waterproof management

If the foreign objects are not removed by

shaking the camera in the water, wash the

camera directly under a strong ﬂow of water.

There may be some water drops inside the

battery chamber cover and the USB cover

after opening them. Remove the water drops

before storing the camera.

1110

Taking a photo

Press [

] to select ( ).

Align your subject in the frame.

Press [

Shutter] halfway down to focus

automatically.

A green frame means the subject in focus.▪

Press [

Shutter] all the way down to take the

photo.

Recording a video

Press [

] to select ( ).

Align your subject in the frame.

Press [

Shutter].

Press [

Shutter] again to stop the recording.

Note

Number of photos by resolution (for 1 GB SD)

Resolution Super ﬁne Fine Normal

4000 x 3000 134 220 329

3984 x 2656 152 249 371

3968 x 2232 181 296 438

3264 x 2448 200 328 487

2592 x 1944 313 510 751

2048 x 1536 494 789 1,154

1024 x 768 1,731 2,597 3,463

These ﬁgures are measured under Samsung’s standard

conditions and may vary depending on shooting conditions

and camera settings.

Capturing photos or videos
