Sega SpongeBob SQUAREPANTS Manuale utente
1ST PRINTING DECEMBER ‘04
MANUAL NO. 999-2186
Owner’s Manual
SEGA AMUSEMENTS USA, INC.
Redemption Version
®
www.sauservice.com
GAME CODE: SBR
VISIT OUR WEBSITE!
Now with a new look to make your experience
that much easier.
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain the safety:
To ensure the safe usage of the product, be sure to read the following before using the product. The
following instructions are intended for the users, operators and the personnel in charge of the opera-
tion of the product. After carefully reading and sufficiently understanding the warning displays and
cautions, handle the product appropriately. Be sure to keep this manual nearby the product or else-
where convenient for referring to it when necessary.
Herein, explanations which require special attention are enclosed with dual lines. Depending on the
potentially hazardous degrees, the terms of WARNING, CAUTION, etc. are used. Be sure to under-
stand the contents of the displays before reading the text.
Indicates that mishandling the prod-
uct by disregarding this warning
will cause a potentially hazardous
situation which can result in death
or serious injury.
Indicates that mishandling the product
by disregarding this caution will cause
a slight hazardous situation which can
result in personal injury and or material
damage.
For the safe usage of the product, the following pictographs are used:
Indicates “HANDLE WITH CARE.” In order to protect the human body an equipment,
this display is attached to places where the Owner’s Manual and or Service Manual should
be referred to.
Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention. Failing to
perform work as per the instructions can cause accidents. In the case where only those who have tech-
nical expertise should perform the work to avoid hazardous situation, the instructions herein state that the
serviceman should perform such work.
Be sure to turn off power before working on the machine.
To prevent electric shock, be sure to turn off power before starting the work in which the worker touches
the interior of the product. If the work is to be performed in the power-on status, the Instruction Manual
herein always states to that effect.
Be sure to ground the Earth Terminal (this, however, is not required in the case where a power cord
with earth is used).
This product is equipped with the Earth Terminal. When installing the product, Connect the Earth Ter-
minal to the “accurately grounded indoor earth terminal” by using an earth wire. Unless the product is
grounded appropriately, the user can be subject to electric shock. After performing repair, etc. for the
Control equipment, ensure that the Earth Wire is firmly connected to the Control equipment.
Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is not
equipped with the Earth Leakage Breaker can cause a fire when earth leakage occurs.
Be sure to use fuses which meet the specified rating. (only for the machines which use fuses).
Using fuses exceeding the specified rating can cause a fire and electric shock.
WARNING! CAUTION!
Specification changes (removal of equipment, conversion and addition) not designated by SEGA
are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc. It is
very hazardous to operate the product by removing parts and or modifying the circuits. Should doors,
lids and protective parts be damaged or lost, refrain from operating the product, and contact where the
product was purchased from or the office herein stated. SEGA shall not be held responsible for any
accidents, compensation for damage to a third party, resulting from the specifications not designated by
SEGA.
Ensure that the product meets the requirements of appropriate Electrical Specifications.
Before installing the product, check for Electrical Specifications. SEGA products have a nameplate
on which Electrical Specifications are described. Ensure that the product is compatible with the power
supply voltage and frequency requirements of the location. Using any Electrical Specifications different
from the designated Specifications can cause a fire and electric shock.
Install and operate the product in places where appropriate lighting is available, allowing warning
labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially hazardous situ-
ation are applied to places where accidents can be caused. Ensure that where the product is operated
has sufficient lighting allowing the warnings to be read. If any label is peeled off, apply it again imme-
diately. Please place an order with where the product was purchased from or the office herein stated.
When handling the Monitor, be very careful. (Applies only to the product w/monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after running off power, some
portions are still subject to high tension voltage sometimes. Monitor repair and replacement should be
performed only be those technical personnel who have knowledge of electricity and technical expertise.
Be sure to adjust the monitor (projector) properly. (Applies only to the product w/monitor.)
Do not operate the product leaving on-screen flickering or blurring as it is. Using the product with the
monitor not properly adjusted may cause dizziness or a headache to an operator, a player, or the cus-
tomers.
When transporting or reselling this product, be sure to attach this manual to the product.
In the case where commercially available monitors and printers are used in this product, only the con-
tents relating to this product are explained herein. Some commercially available equipment has func-
tions and reactions not stated in this manual. Read this manual together with the specific Instruction
Manual of such equipment.
Descriptions herein contained may be subject to improvement changes without notice.
The contents described herein are fully prepared with due care. However, should any question arise or
errors be found, please contact SEGA.
•
•
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION.
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately after
transporting to the location. Nevertheless, an irregular situation may occur during transportation. Before
turning on power, check the following points to ensure that the product has been transported in a satis-
factory status.
Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
Are Casters and Adjusters, damaged?
Do the power supply voltage and frequency requirements meet with those of the location?
Are all wiring connectors correctly and securely connected? Unless connected in the correct direction,
connector connections can not be made accurately. Do not insert connectors forcibly.
Do power cords have cuts and dents?
Do the fuses used meet specified rating? Is the Circuit Protector in an energized status?
Are all accessories available?
Can all Doors and Lids be opened with the Accessory keys? Can Doors and Lids be firmly closed?
TABLE OF CONTENTS
BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
TABLE OF CONTENTS
INTRODUCTION OF THE OWNER’S MANUAL
1. HANDLING PRECAUTIONS ..........................................................................................
2. PRECAUTIONS CONCERNING INSTALLATION LOCATION ...................................
3. OPERATION ......................................................................................................................
4. ASSEMBLING AND INSTALLATION ............................................................................
5. PRECAUTIONS WHEN MOVING THE MACHINE ......................................................
6. NAME OF PARTS ..............................................................................................................
7. GAME DESCRIPTION ......................................................................................................
8. HOW TO PLAY ..................................................................................................................
9. PRIZE SETTINGS EXPLAINED .......................................................................................
10. SELF TEST EXPLAINED ..................................................................................................
11. GAMEBOARD CONFIG SETTINGS ................................................................................
12. CONVEYOR ASSEMBLY ..................................................................................................
13. COIN SELECTOR ...............................................................................................................
14. TICKET DOOR AND TICKET DISPENSER .....................................................................
15. TROUBLESHOOTING AND BELT SYSTEM INFORMATION ......................................
16. DESIGN RELATED PARTS ................................................................................................
17. PARTS ...................................................................................................................................
18. WIRE COLOR CODE TABLE .............................................................................................
19. WIRE PINOUT TABLES .....................................................................................................
1 - 2
3 - 4
5 - 6
7 - 8
9
10
11
12
13
13
14
15
16
17 - 21
22 - 23
24
25 - 29
30
XXX
SPECIFICATIONS
INTRODUCTION OF THE OWNERS MANUAL
This Owner's Manual is intended to provide detailed descriptions together with all the
necessary information covering the general operation of electronic assemblies, electrome-
chanicals, servicing control, spare parts, etc. as regards the product,
SPONGEBOB SQUAREPANTS MECHANICAL TYPE REDEMPTION GAME .
This manual is intended for the owners, personnel and managers in charge of operation
of the product. Operate the product after carefully reading and sufficiently understand-
ing the instructions. If the product fails to function satisfactorily, non-technical personnel
should under no circumstances touch the internal system. Please contact where the prod-
uct was purchased from.
SEGA AMUSEMENTS USA, INC. / CUSTOMER SERVICE
45133 Industrial Drive, Fremont, California 94538, U.S.A.
Phone : (415) 701-6580
Fax : (415) 701-6594
Use of this product is unlikely to cause physical injuries or damages to property. However,
where special attention is required this is indicated by a thick line, the word "IMPORTANT"
and its sign in this manual.
Indicates that mishandling the product by disregarding this display can cause the
product's intrinsic performance not to be obtained, resulting in malfunctioning.
Installation Space : 27.25 inches width X 38 inches depth
Height : 71.5 inches
Width : 25.25 inches
Length : 30 inches
Weight : 315 lbs
Power, maximum current : 270 W 2.25 A (AC 120V 60 Hz AREA)
MONITOR : No Video Display
STOP
IMPORTANT!
● PRODUCTION DATE ●
This SEGA product was produced in the year of:
2004
This signifies that this work was disclosed in 2004.
DEFINITION OF LOCATION MAINTENANCE MAN AND SERVICEMAN
Non-technical personnel who do not have technical knowledge and expertise should
refrain from performing such work that this manual requires the location's main-
tenance man or a serviceman to carry out, or work which is not explained in this
manual. Failing to comply with this instruction can cause a severe accident such
as electric shock.
Ensure that parts replacement, servicing & inspections, and troubleshooting are performed by the
location's maintenance man or the serviceman. It is instructed herein that particularly hazardous work
should be performed by the serviceman who has technical expertise and knowledge.
The location's maintenance man and serviceman are herein defined as follows:
"Location's Maintenance Man" :
Those who have experience in the maintenance of amusement equipment and vending machines, etc.,
and also participate in the servicing and control of the equipment through such routine work as equip-
ment assembly and installation, servicing and inspections, replacement of units and consumables, etc.
within the Amusement Facilities and or locations under the management of the Owner and Owner's
Operators of the product.
Activities of Location's Maintenance Man :
Assembly & installation, servicing & inspections, and replacement of units & consumables as regards
amusement equipment, vending machines, etc.
Serviceman :
Those who participate in the designing, manufacturing, inspections and maintenance service of the
equipment at an amusement equipment manufacturer.
Those who have technical expertise equivalent to that of technical high school graduates as regards
electricity, electronics and or mechanical engineering, and daily take part in the servicing & control
and repair of amusement equipment.
Serviceman's Activities :
Assembly & installation and repair & adjustments of electrical, electronic and mechanical parts of
amusement equipment and vending machines.
WARNING!
Notes:
1www.seuservice.com
1. HANDLING PRECAUTIONS
When installing or inspecting the machine, be very careful of the following points and pay attention to
ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the cautionary
matters herein stated can cause personal injury or damage to the machine.
● Before performing work, be sure to turn power off. Performing the work without
turning power off can cause an electric shock or short circuit. In the case work
should be performed in the status of power on, this manual always states to that ef-
fect.
● To avoid electric shock or short circuit, do not plug in or unplug quickly.
● To avoid electric shock, do not plug in or unplug with a wet hand.
● Do not expose Power Cords and Earth Wires on the surface, (floor, passage, etc.).
If exposed, the Power Cords and Earth Wires are susceptible to damage. Damaged
cords and wires can cause electric shock or short circuit.
● To avoid causing a fire or electric shock, do not put things on or damage Power
Cords.
● When or after installing the product, do not unnecessarily pull the power cord. If
damaged, the power cord can cause a fire or electric shock.
● In case the power cord is damaged, ask for replacement through where the product
was purchased from or the office herein stated. Using the cord as is damaged can
cause fire, electric shock or leakage.
● Be sure to perform grounding appropriately. Inappropriate grounding can cause an
electric shock.
● Be sure to use fuses meeting specified rating. Using fuses exceeding the specified
rating can cause a fire or electric shock.
● Completely make connector connections for IC BD and others. Insufficient insertion
can cause an electric shock.
● Specification changes, removal of equipment, conversion and/or addition, not desig-
nated by SEGA are not permitted.
• Failure to observe this may cause a fire or an electric shock. Non-compliance with
this instruction can have a bad influence upon physical conditions of the players or
the lookers-on, or result in injury during play.
• SEGA shall not be held responsible for damage, compensation for damage to a third
party, caused by specification changes not designated by SEGA.
● Be sure to perform periodic maintenance inspections herein stated.
WARNING!
2
www.seuservice.com
● For the IC board circuit inspections, only the logic tester is allowed. The use of a
multiple-purpose tester is not permitted, so be careful in this regard.
● Static electricity from your body may damage some electronics devices on the IC
board. Before handling the IC board, touch a grounded metallic surface so that the
static electricity can be discharged.
● Some parts are the ones designed and manufactured not specifically for this game
machine. The manufacturers may discontinue, or change the specifications of, such
general-purpose parts. If this is the case, Sega cannot repair or replace a failed game
machine whether or not a warranty period has expired.
STOP
IMPORTANT!
● PRODUCTION DATE ●
This SEGA product was produced in the year of:
2004
This signifies that this work was disclosed in 2004.
Indice
Altri manuali Sega Macchina per videogiochi arcade
Sega
Sega HOUSE OF THE DEAD 4 SUPER DELUXE Manuale utente
Sega
Sega Luigi's Mansion Arcade Guida all'applicazione
Sega
Sega World Club Champion Football European Clubs... Manuale utente
Sega
Sega MINI DELUXE THE HOUSE OF THE DEAD 4 Manuale utente
Sega
Sega Sonic & Sega All-Stars Racing Arcade Manuale utente
Sega
Sega AFTER BURNER CLIMAX Manuale utente
Sega
Sega MISSION: IMPOSSIBLE Manuale utente
Sega
Sega DRONE RACING GENESIS Manuale utente
Sega
Sega The House Of The Dead 4 29"STD Manuale utente
Sega
Sega VIRTUA COP Manuale utente
Sega
Sega Snakes & Ladders Manuale utente
Sega
Sega 2SPICY Manuale utente
Sega
Sega PRIMEVAL HUNT Manuale utente
Sega
Sega Let's Go ISLAND! Manuale utente
Sega
Sega BEJEWELED Manuale utente
Sega
Sega OUTRUN 2 SPECIAL TOURS SDX Manuale utente
Sega
Sega NAOMI 2 Manuale utente
Sega
Sega ATV Slam Manuale utente
Sega
Sega MARIO & SONIC AT THE RIO 2016 OLYMPIC GAMES Guida all'applicazione
Sega
Sega THE HOUSE OF THE DEAD III DELUXE Manuale utente
Manuali Macchina per videogiochi arcade popolari di altre marche
Universal Space
Universal Space COCONUT BASH Manuale utente
Bay-Tek
Bay-Tek EVOLVE Manuale utente
Global VR
Global VR America's Army Istruzioni per l'installazione e il funzionamento
Atronic
Atronic Cashline Manuale utente
Universal Space
Universal Space Checky Monkey Manuale utente
Bay-Tek
Bay-Tek Skee Ball 1908 Alley Manuale utente
Aristocrat Technologies
Aristocrat Technologies Mars X Upright Manuale utente
Family Fun Companies
Family Fun Companies Reactor Guida rapida
Universal Space
Universal Space FRUIT MANIA Extreme Manuale utente
falgas
falgas CARRUSEL FIESTA Manuale utente
Konami
Konami DanceDanceRevolution Manuale utente
Bay-Tek
Bay-Tek quik drop Manuale utente
Bandai Namco
Bandai Namco PAC-MAN BATTLE ROYALE CHOMPIONSHIP DELUXE Manuale utente
Adrenaline
Adrenaline Flying Tickets Istruzioni per l'installazione e il funzionamento
Swinks
Swinks Stern Pinball Ghostbusters Manuale utente
Innovative Concepts in Entertainment
Innovative Concepts in Entertainment MONOPOLY ROLL-N-GO Manuale utente
jakar
jakar SPEED CARS Manuale utente
Carmelli
Carmelli HAT TRICK NG1015H Manuale utente
