Seiko Epson S5U1C17F57T Manuale utente

S5U1C17F57T Manual Seiko Epson Corporation i

(Rev.0.9)

CMOS 16-BIT SINGLE CHIP MICROCONTROLLER

S5U1C17F57T Manual

(Software Evaluation Tool for S1C17F57)

ii Seiko Epson Corporation S5U1C17F57T Manual

(Rev.0.9)

NOTICE

No part of this material may be reproduced or duplicated in any form or by any means without the written

permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice.

Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material

or due to its application or use in any product or circuit and, further, there is no representation that this material is

applicable to products requiring high level reliability, such as, medical products. Moreover, no license to any

intellectual property rights is granted by implication or otherwise, and there is no representation or warranty that

anything made in accordance with this material will be free from any patent or copyright infringement of a third

party. This material or portions thereof may contain technology or the subject relating to strategic products

under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license

from the Ministry of Economy, Trade and Industry or other approval from another government agency.

All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective

companies.

S5U1C17F57T Manual Seiko Epson Corporation iii

(Rev.0.9)

Configuration of product number





Devices

S1 C17xxx F 00E1 00

Development tools

S5U1 C 17000 Y2 1 00

Packing specifications

[00 : standard packing]

Version

[1 : Version 1]

Tool type

Hx : ICE

Dx : Evaluation board

Ex : ROM emulation board

Mx : Emulation memory for external ROM

Tx : A socket for mounting

Cx : Compiler package

Sx : Middleware package

Corresponding model number

[17xxx : for S1C17xxx]

Tool classification

[C : microcomputer use]

Product classification

[S5U1 : development tool for semiconductor

products］

Packing specifications

00 : Besides tape & reel

0A : TCP BL 2 directions

0B : Tape & reel BACK

0C : TCP BR 2 directions

0D : TCP BT 2 directions

0E : TCP BD 2 directions

0F : Tape & reel FRONT

0G : TCP BT 4 directions

0H : TCP BD 4 directions

0J : TCP SL 2 directions

0K : TCP SR 2 directions

0L : Tape & reel LEFT

0M : TCP ST 2 directions

0N : TCP SD 2 directions

0P : TCP ST 4 directions

0Q : TCP SD 4 directions

0R : Tape & reel RIGHT

99 : Specs not fixed

Specification

Package

[D : die form; F : QFP, B : BGA]

Model number

Model name

[C : microcomputer, digital products]

Product classification

[S1 : semiconductor]

iv Seiko Epson Corporation S5U1C17F57T Manual

(Rev.0.9)

Table of Contents

1.1.

OVERVIEW

OVERVIEWOVERVIEW

OVERVIEW................................

................................................................

........................................

................

........1

2.2.

NAME AND FUNCTION OF

NAME AND FUNCTION OFNAME AND FUNCTION OF

NAME AND FUNCTION OF INDIVIDUAL COMPONEN

INDIVIDUAL COMPONENINDIVIDUAL COMPONEN

INDIVIDUAL COMPONENT

T ................................

................................................................

............................................................

........................................................

............................4

2.1

AME OF

NDIVIDUAL

OMPONENT

...................................................................................................4

2.2

UNCTIONS OF

NDIVIDUAL

OMPONENT

..........................................................................................8

2.2.1

Jumper switch functions..........................................................................................................8

2.2.2

Functions of Each Portion......................................................................................................10

3.3.

BLOCK DIAGRAM

BLOCK DIAGRAMBLOCK DIAGRAM

BLOCK DIAGRAM................................

................................................................

...........................................................

......................................................

...........................12

1212

4.4.

CONNECTOR

CONNECTORCONNECTOR

CONNECTOR................................

................................................................

......................................

............

......13

1313

4.1

CPU

OARD

ONNECTOR

................................................................................................................13

4.1.1

CPU Board interface Connector (CN1-1~CN1-4) .................................................................13

4.1.2

Debug Interface Connector (CN2-1~CN2-2).........................................................................15

4.1.3

Power Connector (CN3)..........................................................................................................15

4.1.4

USB Connector (CN4).............................................................................................................15

4.2

ERIPHERAL

OARD

ONNECTOR

....................................................................................................15

4.2.1

Power Connector (CN5)..........................................................................................................15

4.2.2

General CPU Interface Connector (CN6)..............................................................................16

4.2.2

EPD Panel Interface Connector (CN7-1)...............................................................................16

4.2.3

EPD Panel Interface Connector (CN7-2)...............................................................................18

4.2.4

EPD Panel Interface Connector pad (CN8-1~3)...................................................................19

4.2.5

EPD Panel Inerdface Connector Pad (CN9-1) ......................................................................20

4.2.6

EPD Panel Interface Connector Pad (CN9-2).......................................................................21

4.2.7

EPD Module Interface Connector Pad (CN10) .....................................................................22

REVISION HISTORY

REVISION HISTORYREVISION HISTORY

REVISION HISTORY................................

................................................................

..............................................................

............................................................

..............................23

2323

1. Overview

S5U1C17F57T Manual Seiko Epson Corporation 1

(Rev.0.9)

1. Overview

S5U1C17F57T1 and S5U1C17F57T2 (SVT17F57: Software eValuation Tool for S1C17F57) are the evaluation

and development support board for S1C17F57 single chip microcontroller made by Seiko Epson.

It is composed of CPU board and peripheral board, the CPU board has built-in IC socket, the extension

connectors, and the debugging connectors, etc. for S1C17F57, the peripheral board has built-in EPD

(Electrophoretic Display), EPD connection connectors, pads, enhancing EPD driver (S1D14F51), the buzzer,

and the key switch, etc. in S5U1C17F57T1. As a result, the EPD drive display, buzzer drive, and the switch

can be input.

As for S5U1C17F57T2, it is composed only of CPU board used for S5U1C17F57T1, and various applications

are possible with extension connectors.

1) CPU S1C17F57 (QFP15-128)

2) Input power voltage External power supply (DC3.0V)

Coin battery (CR2032 : 3.0V)

3)CPU clock OSC1 : 32.768kHz crystal oscillator

OSC3 : 4.000MHz crystal oscillator

4) Built-in devices

CPU board :

IC socket for S1C17F57 (Built-in S1C17F57)

Crystal oscillator

Reset switch

Extension connector

Pilot LED

USB interface connector

Function switching jumpers

Peripheral board :

Enhancing EPD driver (S1D14F51)

EPD connection connectors, connectors pads

Key switches

Buzzer

Power switch

Function switching jumpers

SVT17F57 is a generic name of S5U1C17F57T1 and S5U1C17F57T2. It becomes another sale, and confirms

the model name, please when you buy it respectively.

S5U1C17F57T1 is a package where CPU board and peripheral board make a set. Moreover, S5U1C17F57T2 is

a package only of CPU board.

Because the coin battery folder is mounted on the peripheral board, the coin battery cannot be used with

S5U1C17F57T2.

S1D14F51 is not mounted in prototype board.

1. Overview

2 Seiko Epson Corporation S5U1C17F57T Manual

(Rev.0.9)

1.1 Usage Method

The software debugging and the evaluation environment of S1C17F57 can be constructed with the following

procedures.

- Single CPU board or CPU board is connected with the peripheral board and use it

(1)CPU board connector CN2-1(J5) and CN2-2(J6) of SVT17F57 are connected with for target connection 4 pin

connector and the Flash writing power supply 4pin connector for emulator respectively by using the cable

bundled to S5U1C17001 H2 (emulator).

(2)VDD power supply selection jumper switch (JP14) of CPU board is installed in the “EXT” side.

(3)VPP power supply selection jumper switch (JP12) of CPU board is installed in the “ICD” side.

(4)Jumper switch JP1, JP2, JP3, and JP17 of CPU board are short, and JP13, JP18, and JP19 open. Moreover,

JP23 of the peripheral board opens when the peripheral board is connected.

(5)Supply the power by the stabilized power supply device to CPU board power supply connector CN3 (J8) or

the emulator is supplied. Please make the power supply voltage within the range of S1C17F57 of the operation

power supply voltage.

(6)The emulator is connected with PC by using the USB cable bundled to the emulator.

Please set to become a voltage input from the target the selection of the DSIO signal level of the emulator (dip

switch SW4 and 5).

(1)VDD power supply selection jumper switch (JP14) of CPU board is installed in the “EXT” side.

(2)Jumper switch JP1, JP2, JP3, and JP17 of CPU board are short, and JP13, JP18, and JP19 open. Moreover,

JP23 of the board in the peripheral board opens when the peripheral board is connected.

(3)It supplies power to CPU board power supply connector CN3 (J8) by using the stabilizing supply device.

Please make the power supply voltage within the range of S1C17F57 of the operation power supply.

(1)VDD power supply selection jumper switch (JP14) of CPU board is completely detached.

(2)Jumper switch JP1, JP2, and JP3 of CPU board are short, JP13, JP17, JP18, and JP19 open, and JP23 of the

peripheral board is connected with the “BATT” side.

(3)The coin battery is installed in the battery folder mounted on the peripheral board.

(4)Power on/off switch (SW2) of the peripheral board is turning on.

(1)VDD power supply selection jumper switch (JP14) of CPU board is installed in the “USB” side.

(2)Jumper switch JP1, JP2, and JP3 of CPU board are short, and JP13, JP17, JP18, and JP19 open. Moreover,

JP23 of the peripheral board opens when the peripheral board is connected.

(3)CPU board is connected with PC by using the USB cable (mini plug).

Moreover, the operation power supply

voltage of S1C17F57 is fixed by 3.3V.

(4)Please install the USB driver of Silicon Laboratories for CP2102 according to the direction of PC.

Please prepare the USB cable by the customer.

1. Overview

S5U1C17F57T Manual Seiko Epson Corporation 3

(Rev.0.9)

Table 1.1 Jumper setting list in each mode

Board Number of

jumper

switch

Software

debugging Free run by

external

power

Free run by

coin battery Free run by

USB bus

Power

JP1-JP3 ON ON ON ON

JP4-JP11 - - - -

JP12 ICD - - -

JP13 OPEN OPEN OPEN OPEN

JP14 EXTEXT OPEN USB

JP15-16 - - - -

JP17 ON ON OPEN OPEN

CPU

JP18-19 OPEN OPEN OPEN OPEN

JP1-22 - - - -

JP23 OPEN OPEN BATT OPEN

Peripheral

JP24-29 - - - -

ON: Connect jumper switch, OPEN: remove jumper switch, SHORT: Short by solder,

- : No care, OTHERS: The jumper switch is connected with this name side.



2. Name and Function of Individual Component

4 Seiko Epson Corporation S5U1C17F57T Manual

(Rev.0.9)

2. Name and Function of Individual Component

2.1 Name of Individual Component

The function and the name of each part are as follows.



Figure 2.1 Name of S5U1C17F57T1 CPU board surface each part

USB connetor

CN4 (J7)

Reset switch

(SW1)

Solder jumper switch

for RFC

(JP4-7, 8-11)

Component

terminals for RFC

VPP power selection

jumper switch (JP12)

Jmper switch

for VPP (JP3)

VPP monitor pin when

USB

ower

(

TP1

)

USB VPP voltage

adjusting resistor

(

R12

)

Jumper switch for

USB VPP voltage

control

(

JP13

)

Jumper switch

for VDD power

supply (JP17)

VDD power

selection jumper

(JP14)

VDD monitor

terminal (TP2)

Power connecotor

CN3

(

)

IC socket for

S1C17F57

(

)

Function switching

jumpers (JP1-2,

18-19)

USB interface

solder jumper

(JP15-16)

2. Name and Function of Individual Component

S5U1C17F57T Manual Seiko Epson Corporation 5

(Rev.0.9)

Figure2.2 Name of the S5U1C17F57T1 CPU board back each part

Debug connectors

CN2-1-2(J5, J6)

Crystal oscillator

(X2)

Crystal oscillator

(X1)

Extension

connector(CN

1-1, J4)

Extension connector

(CN1-2,J3)

Extension connector

(CN1-3, J1)

Extension

connector(

CN1-4,J2)

2. Name and Function of Individual Component

6 Seiko Epson Corporation S5U1C17F57T Manual

(Rev.0.9)

Figure 2.3 Name of S5U1C17F57T1 Peripheral board surface each part

EPD connection

Pad (0.5mm)

CN8-3(J11)

EPD connection

pad (0.4mm)

CN8-2(J9)

EPD connection

pad (0.3mm)

CN8-1(J8)

EPD connetor

pad (0.2mm)

CN9-1(J7)

EPD conector

pad (0.4mm)

CN9-2

(

)

External EPD

module

connection

pad (0.5mm)

Power switch

(

SW2

)

External power

connector

CN5 (J14)

External CPU

interface

CN6 (J13)

Reset switch

(SW2)

Key switch

(SW3〜6)

REGMON pin

(TP5)

Piezo buzzer

(BZ1)

EPD connetor

S1C17F57+

S1D14F51

CN7-2(J1)

EPD connector

S1C17F57

CN7-1(J2)

VDD monitor

pin (TP2)

GND terminal

(TP3)

EPD connection

pad CN11 (J10)

Extension connector

(CN1-1, J5)

Extension connector

(CN1-2, J3)

Extension connector

(CN1-3, J15)

Extension

connector (CN1-4,

J4)

Indice

Altri manuali Seiko Epson Microcontrollore

Seiko Epson

Seiko Epson S5U1C17W23T Manuale utente

Seiko Epson

Seiko Epson S1C17153 Manuale utente

Manuali Microcontrollore popolari di altre marche

AMS

AMS AS7261 Demo Kit Manuale utente

Novatek

Novatek NT6861 Manuale utente

Espressif Systems

Espressif Systems ESP8266 SDK Guida all'installazione

Nuvoton

Nuvoton ISD61S00 ChipCorder Guida

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuale utente

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuale utente

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuale utente

NEC

NEC 78GK0S/K 1+ Series Istruzioni per l'installazione e il funzionamento

Mikroe

Mikroe SEMITECH N-PLC Click Istruzioni per l'installazione e il funzionamento

Intel

Intel Agilex Manuale utente

Cypress

Cypress CY4607 HX2VL Manuale utente

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuale utente

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuale utente

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuale utente

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuale utente

Espressif Systems

Espressif Systems ESP8266EX Istruzioni operative

Abov

Abov AC33M8128L Manuale utente

Laird

Laird BL654PA Manuale utente
