Sena 30K Manuale utente
MOTORCYCLE BLUETOOTH®
COMMUNICATION SYSTEM
WITH MESH INTERCOM™
2.0.2
30K
RIDE CONNECTED
The 30K features Sena’s Mesh Intercom
technology allowing your group to seamlessly
communicate, even if a rider falls out of range.
With more connections and Mesh Intercom™
technology, the 30K is the next generation of
communication.
Mesh Intercom™
up to 2 km
(1.2 miles)*
Bluetooth
®
4.1
Audio
Multitasking™
Multi-Way
Intercom
Intercom up to
2 km (1.2 miles)*
Advanced Noise
Control™
Group Intercom Remote Control
FM Radio
* in open terrain
GETTING STARTED
1. This product comes with a Quick Start
Guide, which is a basic version of the User’s
Guide. A FULL VERSION OF THE USER’S
GUIDE CAN BE DOWNLOADED AT
SENA.COM.
2. Update this product for free with the latest
firmware to fully enjoy the new advanced
features built into this product. Visit
sena.com to see how to update your
product.
3. Users can follow Sena on Facebook,
YouTube, Twitter and Instagram to
receive the most up to date information
on products, helpful tips and all other
announcements regarding Sena products.
GETTING STARTED
SENA Technologies, Inc.
sena.com
Customer Support: support.sena.com
30K
GETTING STARTED
How to Use This Guide
The legend and callouts are here to help you read the
illustrations. New technology can be confusing, but we’ve
created a simple way to perform actions using illustrations.
P1s
HOLD
Function = Button(s) to Tap or Hold
=
Buttons
Ambient Mode Button
Mesh Intercom Button
Phone Button
Jog Dial
M
P
A
GETTING STARTED
10s
HOLD
1x
TAP
ROTATE
L
ROTATE
L
ROTATE
R
ROTATE
R
ROTATE
ROTATE
Tap button/Jog Dial
the specified number
of times
Rotate Jog Dial clockwise (right) or
counterclockwise (left).
Rotate while Pressing Jog Dial
clockwise (right) or counterclockwise (left).
Icon Legend
Press and Hold button/
Jog Dial for the specified
amount of time
Audible prompt from
the Bluetooth Module
“Hello”
Product Details
Mesh Intercom Antenna Mesh Intercom Button
Status LED
Bluetooth
Antenna
Ambient Mode Button
Phone Button
Jog Dial
DC Power Charging &
Firmware Upgrade Port
QUICK START GUIDE
QUICK START GUIDE
30K
Installation
1
3
2
4
Mesh Intercom Antenna
Pull the Mesh Intercom
Antenna outwards slightly to
unfold it.
QUICK START GUIDE
1
2
Sena 30K Utility App
By simply pairing your phone with your headset, you can
use the Sena 30K Utility App for quicker and easier set
up and management.
• App Features
- Mesh Intercom, Bluetooth Intercom, Music, FM Radio,
Device settings, Quick Start Guide, and User’s Guide.
• Download
- Android: Google Play Store > ‘Sena 30K Utility’
- iOS: App Store > ‘Sena 30K Utility’
Sena Device Manager
The Sena Device Manager allows you to upgrade the
firmware and configure its settings directly from your PC
or Apple computer. Download the Sena Device Manager
from sena.com.
QUICK START GUIDE
Basic Operations
PP
ROTATE
L
ROTATE
R
1x
TAP
1s
HOLD
Powering On Powering Off
==
POWER
ON
POWER
OFF
Volume Up Volume Down
= =
VOLUME
UP
VOLUME
DOWN
Checking the Battery Level
Instruction is for when powering the headset on.
P1s
HOLD
Visual Method
=
VISUAL
METHOD
=
HIGH
=
MED
=
LOW
QUICK START GUIDE
QUICK START GUIDE
Pairing When the 30K is
Turned Off
Press and hold the Phone
Button and Jog Dial for
10 seconds when the 30K
is turned off.
=P10s
HOLD
“Phone pairing”
=
Alternating blue
and red flashing
lights indicate
device is now
discoverable.
LED
STATUS
=
PIN
NUMBER
Pairing When the 30K is
Turned On
Press and hold the Phone
Button for 5 seconds
when the 30K is turned on.
=P5s
HOLD
“Phone pairing”
=
Alternating blue
and red flashing
lights indicate
device is now
discoverable.
LED
STATUS
=
PIN
NUMBER
Phone Pairing
There are two ways to pair the phone.
