HMEC 460

Ear pads and headband in leatherette design

Highest wearing comfort

Superior audio quality

Noise-compensated boom microphone for superior speech transmission

Control unit provides the following features: Volume control, audio in,

cell phone in, switch for NoiseGard™ on/off, switch mono/stereo, switch

boom left/right, 2-coloured status-LED

NoiseGard™ supply can be used either from 2 x AA batteries (operating

time approx. 30 hours) or from aircraft by XLR-3 connector

Can be used as conventional headphones when supply voltage for

NoiseGard™ is switched off

10 year warranty

Delivery includes: 1 HMEC 460, 1 carrying case for headset and

accessories, 1 cable clip MZQ 2002-1, 1 windshield

MZW 45, 1 audio cable with 2 x 2.5 mm stereo jacks,

1 audio cable with 2 x 3.5 mm stereo jacks

The HMEC 460 is a pilot’s head-

set with closed ear protector

headphones and NoiseGard™

active noise compensation for

use in propeller and turbo prop

aircraft. Its silber brushed sur-

face gives it an exclusive and

premium-class look. The new

closed ear protector headset not

only has an extra generously

padded headband and ex-

tremely soft ear pads, it also

features 7.0 N contact pressure,

30 % less than its predecessor.

The HMEC 460 even includes

sockets for multimedia appli-

cations: an extra 3.5 mm Audio-

In-socket for those who want

to connect their MP3-player

directly to the headset, and a

2.5 mm Cell-Phone-In-socket

for the mobile phone.

Pilot‘s

Headsets

Headphone HMEC 460

Transducer principle dynamic

Ear coupling circumaural, closed

Frequency response 20 – 20,000 Hz

Nominal impedance (active/passive) 300  mono, 600 per system, stereo

Attenuation (active/passive) > 25 – 40 dB

Contact pressure aprox. 7 N

Weight (without cable) 370 g

Microphone Typ MKE 45-1 bipolar

Transducer principle condenser capsule, noise-compensated

Frequency response 300 – 5,000 Hz

Max. SPL 120 dB

Output voltage 400 mV ± 3dB at 114 dB/SPL (as per RTCA/DO 214)

Terminating impedance 150 

Operating voltage Typ. 16 VDC (8 – 16 VDC, 8 – 25 mA as per RTCA/DO 214)

General Data

Connection cable single-sided round cable, length 1.5 m

Connetors Headphone: 1/4˝ stereo jack

Mircrophone: PJ-068 Ø 5.25 mm

NoiseGard™ supply XLR-3 connector

Packaging

Packaging dimensions (W x H x D in mm) 249 x 282 x 123

Carton dimensions (W x H x D in mm) 285 x 375 x 260

Units per carton 6

Languages German, English, French, Spanish, Italian, Dutch

515395 07/06 Printed in Germany Sennheiser is a registered trademark of Sennheiser electronic GmbH & Co.KG. www.sennheiser.com

Recommended Accessories

Beschreibung Product Cat. No.

Cigarette lighter adaptor cable ACX-1

Cigarette lighter adaptor cable ACX-2

Cigarette lighter adaptor cable ACX-11*

Cigarette lighter adaptor cable ACX-22 *

Windshield MZW 45 075823

Cable clip MZQ 2002-1 044740

GOP GEL ear pads 092807

Ear pads, soft 517607

Speciﬁcations
