Mini DVI Extender

Quick Installation Guide

Introducing the Mini DVI Extender

The Mini DVI Extender extends your DVI transmission

distance up to 30 meters (100ft) thru one CAT-5/5e/6

cable.

Features and Benefits

• DVI 1.1 compliant

• Extendstransmissiondistanceupto30meters(100ft)

from the source at XGA

• Extends transmission distance up to 10 meters (50ft)

from the source at UXGA

• Compact size

• Activity LEDs

Technical Specifications

• Video bandwidth: 1.65Gbps

• Input TMDS signal: 1.2V (peak to peak)

• Input DDC signal: 5V (peak to peak)

• DVI-D connector

• RJ-45 connector

• Dimensions: 50mm (L) x 40mm (W) x 20mm (H)

• Weight: 20g

PackageContents

•Mini DVI Extender (1 transmitter + 1 receiver)

• Quick Installation Guide

04-0494A

Hardware Installation

1. Connect the transmitting Mini DVI Extender to

your PC source.

2. Connect the receiving Mini DVI Extender to your

DVI equipped monitor.

3. Connect your CAT-5/5e/6 cable, make sure it is

securely connected with no loose wires.

Notes

1. All transmissions distances are measured with

CAT-5e 125MHz cable.

2. To reduce interferance use shielded CAT-5/5e/6

cables to improve EMI over longer distances.

3. For resolutions greater than 1280 x 1024, CAT-6

cable is recommended.

Safety Precautions

Like all electronic equipment the Mini DVI Extender

should be used with care. Please read and follow the

safetyprecautions to protectyourself from possibleinjury

and minimize the risk of damage to the unit.

• Follow all instructions and warnings marked on the

unit

• Provide proper ventilation and air circulation, do

not use near water

• Keep objects that might damage the device at a safe

distance and assure that the placement of this unit is

on a stable surface

• Do not use liquid or aerosol cleaners to clean this

units.

• Use only the accessories that came with the unit

Technical Support and Warranty

QUESTIONS? SIIG’sOnline Support hasanswers! Simply visitour

web site at www.siig.com and click Support. Our online support

database is updated daily with new drivers and solutions. Answers

toyour questionscould bejust a fewclicks away. Youcan alsosubmit

questions online and a technical support analysts will promptly

respond.

SIIGoffers a 2-year manufacturer warranty with this product. Please

see our web site for more warranty details. If you encounter any

problems with this product, please follow the procedures below.

A) If it is within the store's return policy period, please return the

product to the store where you purchased from.

B) Ifyour purchasehas passedthe store'sreturn policy period, please

follow these steps to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a

request to SIIG RMA. If the product is determined to be

defective, an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

•Properly pack the product for shipping. All software, cable(s)

and any other accessories that came with the original package

must be included.

•Clearly write your RMA number on the top of the returned

package. SIIG will refuse to accept any shipping package, and

will not be responsible for a product returned without an

RMA number posted on the outside of the shipping carton.

•You are responsible for the cost of shipping. Ship the product

to the following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

•SIIG will ship the repaired or replaced product via Ground

in the U.S. and International Economy outside of the U.S. at

no cost to the customer.

MiniDVIExtenderisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregisteredtrademarksofSIIG,

Inc. Other names used in this publication are for identification only and may be trademarks of their

respectivecompanies.

About SIIG, Inc.

Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer

of I/O connectivity products, including PCIe, PCI & ISA serial and

parallel ports, USB, Serial ATA & UltraATA controllers, FireWire

(1394a/b),networking,sound cards,andother accessories. SIIG isthe

premier one-stop source of upgrades.

SIIGproductsoffer comprehensive usermanuals,many user-friendly

features, and are backed by an extensive manufacturer warranty.

High-quality control standards are evident by the overall ease of

installation and compatibility of our products, as well as one of the

lowest defective return rates in the industry. SIIG products can be

found in computer retail stores, mail order catalogs, through major

distributors, system integrators, and VARs in the Americas and the

UK, and through e-commerce sites.

PRODUCT NAME

Mini DVI Extender

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS

B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCCCOMPLIANCESTATEMENT:

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

Ph: 510-657-8688
