Simons Voss SmartCD.G2 Manuale utente
SmartCD.G2
Manual
22.05.2019
Contents
1 Intended use ................................................................................................................................................ 3
2 Safety instructions ....................................................................................................................................4
3 Scope of supply..........................................................................................................................................6
4 Connection to a PC/laptop..................................................................................................................... 7
5 Charging the batteries..............................................................................................................................8
6 Initial operation...........................................................................................................................................9
7 Configuring the Bluetooth connection.............................................................................................. 10
7.1 Initial installation ............................................................................................................................................10
7.2 Changing the connection ........................................................................................................................... 10
8 Programming with Smart CD.................................................................................................................11
8.1 Programming with a PC or laptop...........................................................................................................11
8.2 Programming with a netbook ....................................................................................................................11
8.3 Programming with a PDA ............................................................................................................................11
9 Antenna alignment...................................................................................................................................12
10 Replacing the batteries...........................................................................................................................13
11 Signals ......................................................................................................................................................... 14
12 Technical specifications .........................................................................................................................15
13 Declaration of conformity ..................................................................................................................... 16
14 Help and other information ...................................................................................................................17
SmartCD.G2 (Manual) Contents
2 / 19
1 Intended use
The SmartCD.G2 is a programming device which has been specially
developed to run on a PC, netbook or laptop or in conjunction with a
Windows Mobile 5.x / 6.x PDA. It is a very convenient way for you to
programme and read all digital components in SimonsVoss System 3060
(locking cylinders, transponders, SmartHandles and SmartRelays).
You require the SmartCD MP programming device to programme
SimonsVoss passive digital products (MP versions).
SmartCD.G2 (Manual) 1. Intended use
3 / 19
2 Safety instructions
WARNING
The lithium batteries fitted to this programming device may pose a fire or
burn hazard if handled incorrectly. Do not open or burn them, or heat them
to over 70°C.
CAUTION
Do not remove or replace batteries. SimonsVoss Technologies GmbH can
replace used batteries for a fee.
CAUTION
Ensure that the device does not fall onto the floor and is not exposed to
any other type of impact.
CAUTION
Avoid placing in direct sunlight.
CAUTION
Keep away from sources of magnetic interference.
CAUTION
You must not alter or open the programming device housing.
IMPORTANT
Charge the integrated batteries at least 3 hours before using the device for
the first time.
SmartCD.G2 (Manual) 2. Safety instructions
4 / 19
IMPORTANT
We can only guarantee error-free functioning during programming with a
Windows Mobile 5.x PDA if you use devices approved by SimonsVoss.
IMPORTANT
The manufacturer reserves the right to make technical changes at any
time.
IMPORTANT
In the event of doubt, the original German language manual applies.
IMPORTANT
You must not modify the programming device.
IMPORTANT
The programming device may only be operated with the original cable en-
closed.
IMPORTANT
The programming device may only be used for its intended purpose, that is,
reading and programming SimonsVoss products.
IMPORTANT
You mustn't dispose the SmartCD.G2 in the household waste!
SmartCD.G2 (Manual) 2. Safety instructions
5 / 19
3 Scope of supply
SmartCD.G2 programming device, including permanently built-in
batteries
Cable to connect to a USB port
You need the SimonsVoss software LDB or LSM to use the SmartCD.G2.
You also need the LSMmobile software on your mobile device to
programme components in situ.
This software is not included in the scope of supply, so it must be ordered
separately.
Please read the PDA manufacturer's manual before initial operation.
You can also find the latest version of the driver under Informative
Material/Software Downloads/Drivers in the Support section on the
SimonsVoss website (
www.simons-voss.com/en
).
SmartCD.G2 (Manual) 3. Scope of supply
6 / 19
4 Connection to a PC/laptop
SmartCD.G2 can be directly connected to a PC or laptop by plugging the
supplied cable into an unassigned USB port.
All digital locking devices and all active transponders/transponder media in
SimonsVoss System 3060 can be programmed using a SmartCD.G2 in
conjunction with a PC, netbook or laptop.
IMPORTANT
If you programme with a PDA and SmartCD, you will need to unplug the
cable connecting the SmartCD.G2 to the PC or laptop again. It is not pos-
sible to use Bluetooth to communicate between SmartCD.G2 and a PC or
laptop.
IMPORTANT
You must ensure that the Bluetooth connection is not active before con-
necting SmartCD.G2 to the USB port. The Bluetooth function switches off
automatically after 15 minutes. It can also be switched off manually by
pressing a button on the programming device. If this is not the case, com-
munication cannot be established via the USB port.
Transponders can only be programmed if the SmartCD.G2 is directly
connected to a PC, netbook or laptop using the USB cable and the LSM
software program is installed.
SmartCD.G2 (Manual) 4. Connection to a PC/laptop
7 / 19
5 Charging the batteries
Connect SmartCD.G2 to the PC, netbook or laptop using the USB cable to
charge the batteries. The SmartCD.G2 batteries are then charged via the
USB port.
IMPORTANT
Charge the integrated batteries at least 3 hours before using the device for
the first time.
IMPORTANT
Beware: the USB port will probably deactivate if a laptop is switched off.
IMPORTANT
If you do not wish to use your SmartCD.G2 for a longer period of time, con-
nect it to the USB port. This prevents the batteries from discharging and
the device is thus ready for use at any time.
If you use an external, passive USB hub without its own power supply, you
may have difficulty using more than one device since the USB port cannot
supply enough power. You should therefore connect SmartCD.G2 directly
to an unassigned USB port on the PC, netbook or laptop or to an active
USB hub with its own power supply.
SmartCD.G2 (Manual) 5. Charging the batteries
8 / 19
6 Initial operation
The pre-fitted batteries are pre-charged, so the device is ready for
immediate use.
We recommend recharging SmartCD.G2 via a USB port for about 3-4 hours
before initial use.
Complete the following steps to use the programming device:
Install LSM software. The required drives for SmartCD.G2 are installed
automatically for LSM 3.3 and above.
Connect SmartCD.G2 to the USB port on the PC or laptop.
Carry out the following additional steps to use SmartCD with a PDA:
Install the SmartLSM locking plan software using ActiveSync on the
PDA.
Interconnect SmartCD.G2 and PDA via Bluetooth (use the SmartLSM to
do so).
Set COM port on the PDA to SmartCD.G2 (use the SmartLSM to do so)
SmartCD.G2 (Manual) 6. Initial operation
9 / 19
7 Configuring the Bluetooth connection
7.1 Initial installation
When connecting SmartCD.G2 to a PDA, ensure that both devices:
Are switched on and are detected by Bluetooth
Are in close proximity to one another
Consult the SmartLSM software and possibly the PDA manufacturer's user
guide on how to proceed to connect SmartCD.G2 and the PDA.
Select 'SV [your device's serial number]' for the SimonsVoss device.
When you connect the PDA to SmartCD.G2 for the first time, you should
ensure that no other SmartCD.G2s with an activated Bluetooth are within
the receiving range.
7.2 Changing the connection
You can change the pre-set Bluetooth connection at any time if it needs to
be re-set – to allow you to programme another SmartCD.G2, for example.
Consult the SmartLSM software manual for information on how to
proceed.
SmartCD.G2 (Manual) 7. Configuring the Bluetooth connection
10 / 19
