Setting up the ACU-1 from the Front Panel

Introduction

The switches that are normally used for channel selection can be used to change some operating parameters

of the ACU-1 that may not be accessible through third party software. It is impossible to predict if third party

software will react properly if unsupported adjustments are made in hardware. If you make changes to the

system using the information contained in this document, you are accepting the responsiblity for making

alterations to the system that may not be supported by your software vendor or by Sine Systesm, Inc.

Set EEROM to Factory Default

This is the same as command 3B (hex) and is executed by pressing buttons 1 and 8 simultaneously for at least

one second.

Program User Settings from the Front Panel

(firmware version 6 and later)

All user programming in the ACU-1 can be read and altered from the front panel. To enter the front panel

programming mode, press buttons 1 and 3 simultaneously for at least one second. The POWER/SYNC LED

will begin flashing to indicate that the programming mode has been entered. The front panel will display a

memory address in binary using the left 8 LEDs of the left VU meter. The data at that address is displayed in

binary on the channel LEDs:

The starting address will be 27 (binary 00011011) which programs the "Box Address." The memory address

may be changed using buttons 5 or 6. To change the data at that address, push buttons 7 or 8. If data is

changed, the new data will be stored in EEROM and will unaffected by a power failure.

ACU-1 page 1

Setting up the ACU-1 from the Front Panel

The following table shows the locations that can be programmed:

Name Address (decimal) Address (binary) Default Data (binary)

Channel 1 Up Rate 1 00000001 00000000

Channel 2 Up Rate 2 00000010 00000000

Channel 3 Up Rate 3 00000011 00000000

Channel 4 Up Rate 4 00000100 00000000

Channel 5 Up Rate 5 00000101 00000000

Channel 6 Up Rate 6 00000110 00000000

Channel 7 Up Rate 7 00000111 00000000

Channel 8 Up Rate 8 00001000 00000000

Channel 1 Down Rate 9 00001001 00000000

Channel 2 Down Rate 10 00001010 00000000

Channel 3 Down Rate 11 00001011 00000000

Channel 4 Down Rate 12 00001100 00000000

Channel 5 Down Rate 13 00001101 00000000

Channel 6 Down Rate 14 00001110 00000000

Channel 7 Down Rate 15 00001111 00000000

Channel 8 Down Rate 16 00010000 00000000

Temperature Calibrate 17 00010001 00001000

Baud Rate 18 00010010 00000111

Momentary Relay Time 19 00010011 00110010

Left Silence Threshold 20 00010100 00000001

Right Silence Threshold 21 00010101 00000001

Left Silence Alarm Time 22 00010110 00011110

Right Silence Alarm Time 23 00010111 00011110

Silence Alarm Link 24 00011000 00000001

Parallel Input Hold Time 25 00011001 01100100

ALC Release Speed 26 00011010 00000101

Box Address 27 00011011 00000001

CONFIG1 28 00011100 10000000

CONFIG2 29 00011101 00000000

When finished reading or programming user EEROM, push any of the first four buttons to exit the programming

mode.

Read Firmware Version

Firmware version and be read by simultaneously pressing buttons 1 and 2. The firmware version is read on the

channel status LEDs in binary for as long as the buttons are held. For example, if LEDs 1 through 6 are off and

7 and 8 are on, this represents binary 00000011 or firmware version "3."

Note: If buttons 1 and 2 are pushed carefully at the same time, it will not disturb the currently selected audio

channel.

ACU-1 page 2

Setting up the ACU-1 from the Front Panel

ACU-1 Commands

FadeUp

Function: Turn one or more audio channels on.

Format: AAhex/boxnode/31hex/byte4

Set bits in byte4 to turn channel(s) on. Bit 0 is channel 1.

FadeDown

Function: Turn one or more audio channels off.

Format: AAhex/boxnode/32hex/byte4

Set bits in byte4 to turn channel(s) off. Bit 0 is channel 1.

SetLevel

Function: Sets fader level.

Format: AAhex/boxnode/33hex/byte4/byte5

Set bits in byte4 to designate channel(s). Bit 0 is channel 1. Byte5 sets level from 0 to 255 where 255 is full on.

SetUp

Function: Sets fade up rate.

Format: AAhex/boxnode/34hex/byte4/byte5

Byte4 determines the channel(s) which are to be set (bit 0 being channel 1). byte5 sets the fade up rate. 0 to

25.0 seconds = 0 to 250.

SetDown

Function: Sets fade down rate.

Format: AAhex/boxnode/35hex/byte4/byte5

Byte4 determines the channel(s) which are to be set (bit 0 being channel 1). byte5 sets the fade down rate. 0

to 25.0 seconds = 0 to 250.

SetSilence

Function: Sets silence sense threshold.

Format: AAhex/boxnode/36hex/byte4/byte5

Byte4: Active channels:

1 left channel

2 right channel

3 both channels

Byte5: Detection threshold:

0 silence detection off (both channels)

1 -42 dB

2 -39 dB

3 -36 dB

ACU-1 page 3

Setting up the ACU-1 from the Front Panel

4 -33 dB

5 -30 dB

6 -27 dB

7 -24 dB

8 -21 dB

9 -18 dB

10 -15 dB

11 -12 dB

12 -9 dB

13 -6 dB

14 -3 dB

15 0 dB

16 +3 dB

SetStime

Function: Sets silence sense activation time.

Format: AAhex/boxnode/37hex/byte4/byte5

Byte4: Channel(s) set:

1 left channel

2 right channel

3 both channels

Byte5 sets time. 1 to 250 sets 1 to 250 seconds.

SetPo

Function: Sets parallel output.

Format: AAhex/boxnode/38hex/byte4

Bits set in byte4 turn relays on. Bit 0 is relay 1.

ReadPi

Function: Reads the 16 parallel inputs.

Format: AAhex/boxnode/39hex —replybyte1/replybyte2

Bit0 in replybyte1 corresponds to parallel input 1.

ReadAud

Function: Reads the instantaneous audio level.

Format: AAhex/boxnode/3Ahex/byte4 —replybyte1

Byte4:

1 read left

2 read right

Replybyte1:

0 <-42 dB

1 -42 dB

2 -39 dB

ACU-1 page 4

Setting up the ACU-1 from the Front Panel

3 -36 dB

4 -33 dB

5 -30 dB

6 -27 dB

7 -24 dB

8 -21 dB

9 -18 dB

10 -15 dB

11 -12 dB

12 -9 dB

13 -6 dB

14 -3 dB

15 0 dB

16 +3 dB

Default

Function: Returns box to default settings.

Format: AAhex/boxnode/3Bhex/C4hex

Default settings:

Node Address: 1

Baud Rate: 57.6K

Sources: All off

Fade Up Time (all): 0 seconds

Fade Down Time (all): 0 seconds

Silence Level Left: -42 dB

Silence Level Right: -42 dB

Silence Time Left: 30 seconds

Silence Time Right: 30 seconds

Silence Link: 1 (L and R separate)

Automatic Level Control: On, 5 sec/dB increase speed, gating at -20 dBVU

Parallel Input Hold Time: 1.0 seconds

Momentary Relay Time: 0.5 seconds

Temperature Calibration: 8

Config1 10000010

Config2 00000000

ReadXP

Function: Reads the status of input sources.

Format: AAhex/boxnode/3Chex —replybyte1

Bit 0 is channel 1.

ReadSil

Function: Reads silence detector.

Format: AAhex/boxnode /3Dhex —replybyte1

ACU-1 page 5

Setting up the ACU-1 from the Front Panel

Replybyte1:

Bit0 Silence Alarm Left Channel is active

Bit1 Silence Alarm Right Channel is active

Bit2 Silence Detect Left Channel is active

Bit3 Silence Detect Right Channel is active

ReadPo

Function: Reads the current relay settings.

Format: AAhex/boxnode/3Ehex —replybyte1

Bits set in replybyte1 correspond to relays on. Bit 0 is relay 1.

SetLink

Function: Sets linking for silence sense.

Format: AAhex/boxnode/3Fhex/byte4

Byte4:

0 silence detect off

1 left and right separate

2 left or right linked

3 left and right linked

FadeUpDown

Function: Turn one or more audio channels on and off.

Format: AAhex/boxnode/51hex/byte4/byte5

Set bits in byte4 to turn channel(s) on. Set bits in byte5 to turn channel(s) off. Bit 0 is channel 1. If common

bits are set in byte4 and byte5, the byte5 (fade down) bits override.

PoMomen

Function: Operate relays momentarily

Format: AAhex/boxnode/52hex/byte4

Bits set in byte4 will cause momentary relay operation. Bit0 corresponds to relay 1. Any combination of relays

may be operated momentarily at the same time. Relays that were previously turned on and are operated

momentarily will turn off after the delay period (delay period defined in SetPoTime).

SetNode

Function: Set/read node address.

Format: AAhex/boxnode/53hex/byte4

byte4:

0 read only

1-10 set node address

11-255 read only

SetBaud

Function: Set baud rate.

Format: AAhex/boxnode/54hex/byte4

ACU-1 page 6

Setting up the ACU-1 from the Front Panel

byte4: Baud Rate:

0 2400

1 4800

2 9600

3 14.4K

4 19.2K

5 28.8K

6 38.4K

7* 57.6K default value

8 115.2K

SetClock

Function: Set clock

Format: AAhex/boxnode/55hex/byte4/byte5/byte6/byte7

Byte4, byte5 and byte6 are hours, minutes and seconds

Byte7:

0 24 hour time

1 AM (12 hour time)

2 PM (12 hour time)

ReadClock

Function: Read clock

Format: AAhex/boxnode/56hex —replybyte1/replybyte2/replybyte3/replybyte4

Replybyte1, replybyte2 and replybytebyte3 are hours, minutes and seconds

Replybyte4:

0 24 hour time

1 AM (12 hour time)

2 PM (12 hour time)

3 clock not set

SetCalendar

Function: Set calender

Format: AAhex/boxnode/57hex/byte4/byte5/byte6

Byte4, byte5 and byte6 are month, day and year

ReadCalender

Function: Read calender

Format: AAhex/boxnode/58hex —replybyte1/replybyte2/replybyte3

Replybyte1, replybyte2 and replybytebyte3 are month, day and year

SetTCal

Function: Calibrate temperature sensor

Format: AAhex/boxnode/59hex/byte4

ACU-1 page 7

Setting up the ACU-1 from the Front Panel

If byte4 is 0, this is a read only function. Replybyte1 is the current calibration value.

If byte4 is 1 to 15, the value of byte4 is programmed as the calibration value (center range =8).

ReadTemp

Function: Read temperature

Format: AAhex/boxnode/5Ahex —replybyte1/replybyte2

Replybyte is temperature plus 100 degrees.

If replybyte1=0, sensor is defective or not installed.

Replybyte2 =Temp scale, 0 for Fahrenheit and 1 for Celsius

SetALC

Function: Set/read ALC (automatic level control) mode and speed

Format: AAhex/boxnode/5Bhex/byte4

Byte4:

0 read ALC mode (value returned in replybyte1)

1 set ALC off

2-255 set ALC on, 2 to 255 seconds per 1 dB gain increase

SetPiHold

Function: Set/read parallel input hold time

Format: AAhex/boxnode/5Chex/byte4

Byte4:

0 read only

6-255 0.06 to 2.55 seconds

SetPoTime

Function: Set/read relay momentary on time

Format: AAhex/boxnode/5Dhex/byte4

Byte4:

0 read only

6-255 0.06 to 2.55 seconds

SetConfig1

Function: Set Config1 byte.

Format: AAhex/boxnode/5Ehex/byte4

Byte4:

b0 panel switches 0/1=interlocked/alternate

b1 multiplex output 0/1=always/solo only

b2 autodaylight adjust 0/1=off/on

b3 temperature scale 0/1=Fahrenheit/Celsius

b4 VU mode 0/1=bar/dot

b5 -20/+1 VU markers 0/1=off/on

ACU-1 page 8

Setting up the ACU-1 from the Front Panel

b6 VU backlight 0/1=off/on

b7 alarm LED blink 0/1=off/on

ReadConfig1

Function: Read Config1 byte.

Format: AAhex/boxnode/5Fhex —replybyte1

SetConfig2

Function: Set Config2 byte.

Format: AAhex/boxnode/61hex byte4

Byte4:

b0 data mode 0/1=8E1/8N1

b1 ALC attack speed 0/1=normal/slow (firmware version 6 and later)

b2 unused

b3 unused

b4 unused

b5 unused

b6 unused

b7 unused

ReadConfig2

Function: Read Config2 byte.

Format: AAhex/boxnode/62hex —replybyte1

ReadFirm

Function: Read Firmware Version

Format: AAhex/boxnode/63hex —replybyte1

Note: Firmware version can also be read with the front panel switches and LEDs as described elsewhere in this

document.

ACU-1 page 9

Setting up the ACU-1 from the Front Panel

Errata

Setting baud rate from front panel; Firmware Version 6.

The following table shows the required data value at address 18 to set various baud rates for Firmware Version

6 only.

Baud Rate Address (decimal) Address (binary) Data (binary)

115.2K 18 00010010 00000000

57.6K 18 00010010 00000001

38.4K 18 00010010 00010000

28.8K 18 00010010 00000010

19.2K 18 00010010 00010001

14.4K 18 00010010 00000011

9600 18 00010010 00010010

4800 18 00010010 00010011

2400 18 00010010 00010100

For later firmware versions, use the table listed under SetBaud in the ACU Commands.

ACU-1 page 10

Indice

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
