Insert a memory card
Insert the memory card into the slot as silk-screen indication, until you hear the sound of the "click".
Memory card remove: Push forward the memory card. (It is better to remove in the shutdown status to avoid memory
card damage.)
Video Mode
Press the on/off key to boot and in video mode directly and green light flicks. Press the REC key to stop recording
and save the file, then DVR is in standby mode and Green light is on; In Standby mode, press "REC" key to restart
recording, press again to pause again. In video mode, press the "UP" key can light on/off LCD screen display to
save power.
Photo mode:
press MODE key to be in photo mode. Press REC button to take pictures, and hear the sound of click; Press UP key
in photo mode can also light on/off LCD screen display
Playback and delete
In standby mode, short press the MODE key to be in playback mode. Press up or down key to select the file, press
REC key to play or pause; If you want to delete the file, press the ON/OFF key to be Delete menu, press the up or
down key to select "delete" and press the REC key to choose "delete current" or "delete all" . press REC key
and back to Delete menu. Press on/off key to exit Delete menu and back to playback mode.
SOS function
When video recording , click the ON/OFF button, the file will be forced to save in order to save important files and
not be overwritten.（save method：if ON/OFF button is pressed in prior 10 seconds of the video clip, the last and
current video clip will be saved peremptorily. Press the ON/OFF button in last 10 seconds of the video clip, the
current and next video clip will be saved ; Press the ON/OFF button between the prior 10 seconds and last10
seconds, only the current video clip will be saved.
G_SENSOR function - SOS
When video recording, if the car brakes suddenly or is striked heavily, G-sensor function works to save the current
file because of sudden change of the accelerated speed. The saved file will not be overwritten when loop recording.
the sensitivity of G-sensor can be set in the system menu: high, medium and low, to cater for different users. SOS
works as same as G-sensor.
