SMART Board™ 600i3

and SBD600i3 Interactive

Whiteboard System

Configuration and User’s Guide

Product Registration

If you register your SMART product, we’ll notify you of new features and software

upgrades.

Keep the following information available in case you need to contact

SMART Technical Support.

Serial Number: ___________________________________________________

Date of Purchase: ___________________________________________________

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the manufacturer’s instructions, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Trademark Notice

SMART Board, GoWire, the SMART logo and smarttech are trademarks or registered trademarks of SMART Technologies

ULC in the U.S. and/or other countries. Bluetooth is a trademark owned by Bluetooth SIG, Inc. and is used by SMART

Technologies ULC under license. Sanford, EXPO and EXPO2 are registered U.S. trademarks of SANFORD or its Affiliates.

All other third-party product and company names may be trademarks of their respective owners.

transcribed, stored in a retrieval system or translated into any language in any form by any means without the prior written

consent of SMART Technologies ULC. Information in this manual is subject to change without notice and does not

represent a commitment on the part of SMART.

Patent No. US5448263; US6141000; US6320597; US6326954; US6337681; US6540366; US6741267; US6747636;

US7151533; US7289113; US7499033; CA2058219; and CA2252302. Other patents pending.

11/2009

Introduction

Important Information

Read This Section First

Before you install and use your SMART Board™ 600i3 or SBD600i3 interactive

whiteboard system, read and understand the safety warnings and precautions in this

user’s guide, your projector user’s guide and the included warnings document. These

safety warnings and precautions describe the safe and correct operation of your

interactive whiteboard system and its accessories, helping you to prevent injuries and

equipment damage. You must always ensure that your interactive whiteboard system

is being used correctly.

NOTE

If you own a SMART product other than a SMART Board 600i3 or SBD600i3

interactive whiteboard system, refer to the installation guide for your product

for relevant warnings and maintenance instructions.

In this document, “SMART Board 600i3 interactive whiteboard system” or

“SMART Board SBD600i3 interactive whiteboard system” refers to your

SMART Board 600 or SBD600 series interactive whiteboard and its UF55/UF55w

projector, accessories and optional equipment.

The UF55/UF55w projector included with your system is designed to work only

with certain SMART Board interactive whiteboard models. Contact your authorized

SMART reseller for more information.

ii | INTRODUCTION – IMPORTANT INFORMATION

Safety Warnings, Cautions and Important

Information

WARNINGS – GENERAL

• Failure to follow the installation instructions included with your interactive

whiteboard, or found in this guide, could result in personal injury or product

damage.

• Two people are required to safely mount the projector boom and the

interactive whiteboard on a wall because the items might be too heavy for one

person to maneuver onto their wall-mounting brackets.

• Do not leave cables on the floor where they can be a tripping hazard. If you

must run a cable over the floor, lay it in a flat, straight line and secure it to the

floor with tape or a cable management strip of a contrasting color. Handle

cables carefully and avoid excessive bending.

• To reduce the risk of fire or electric shock, do not expose any component

of your SMART Board interactive whiteboard system to rain or moisture.

• When mounting the projector boom on a framed wall, you must attach both

the mounting bracket and safety tether to a stud to safely support the

projector’s weight. If you use only drywall anchors, the drywall can fail,

resulting in product damage and possible personal injury.

• If you remove the bolt supporting the limit strap, the projector’s boom will be

free to swing. Make sure that the bolt is tightened, and never remove it from

the unit without supporting the projector boom first.

• Do not climb (or allow children to climb) on any part of your

wall-mounted SMART Board interactive whiteboard system.

Climbing on your interactive whiteboard or the

UF55/UF55w projector’s boom could result in personal

injury or product damage. Do not climb on, hang from or

suspend objects from the projector’s boom.

• Cleaning a boom-mounted projector may result in a fall or injury.

iii | INTRODUCTION – IMPORTANT INFORMATION

WARNINGS – PROJECTOR

• Refer to the safety warnings and precautions published in the UF55/UF55w

projector manual.

• Do not stare (or allow children to stare) directly into your projector’s beam

of light. Instruct children not to look in the direction of this beam of light.

Encourage users to keep their back to the projector when working at the

interactive whiteboard. Before they turn to face the audience, users should

step sideways, out of the projector’s beam.

• Do not attempt to service the projector other than performing routine lamp

replacement. Other than the lamp module, there are no user-serviceable parts

inside the unit.

• This projector detects its own remaining lamp life. Replace the lamp when a

lamp life warning message appears. If you continue to use the projector after

the replacement message appears, the lamp might shatter or burst, scattering

glass throughout the projector head.

• If the lamp has shattered or burst:

– Call your authorized SMART reseller for instructions. Do not attempt

to replace the lamp.

– Do not touch the glass fragments because they might cause injury.

– Leave and then ventilate the area where the lamp shattered or burst.

– Wash your hands thoroughly if you have come in contact with

lamp debris.

– Thoroughly clean the area around the projector, and then discard any

edible items placed in that area because they might be contaminated.

• You must remove the projector from the projector’s boom before servicing

the lamp.

– Two people are required to remove and replace the projector.

– Replacing the lamp in a boom-mounted projector might result in a fall

or injury.

– Uncovering the lamp while the projector is mounted on the boom might

lead to product damage or personal injury from falling pieces of glass

if the lamp is broken.

iv | INTRODUCTION – IMPORTANT INFORMATION

• When replacing the projector lamp:

– Turn the projector off and wait 30 minutes for the lamp to cool completely

before removing the projector from the boom.

– Do not remove any screws other than those specified in the lamp

replacement instructions.

– Wear protective eyewear while changing the lamp. Failure to do so can

cause injury or loss of eyesight if the lamp shatters or bursts.

– Use only replacement lamps approved by SMART Technologies. Contact

your authorized SMART reseller for replacement parts.

– Never replace the lamp assembly with a previously-used lamp assembly.

– To prevent premature lamp failure or exposure to mercury, always handle

the fragile lamp assembly with care. Use gloves when touching the lamp.

Do not touch the lamp with your fingers.

– Recycle or dispose of the lamp module as hazardous waste,

in accordance with local regulations.

• When returning the projector to the boom, replace all of the screws that you

removed when you removed the projector. Failure to do so can result in the

projector falling from the boom, causing injury or equipment damage.

• To reduce the risk associated with a leaking battery in your projector’s remote

control:

– Use only the specified coin-cell type battery.

– Orient the battery’s plus (+) and minus (-) terminal according

to the markings on the remote control.

– Remove the battery when the remote control is unused for an extended

period.

– Do not heat, disassemble, short or recharge the battery, or expose it to

fire or high temperatures.

– Avoid eye and skin contact if the battery has a leak.

– Dispose of the exhausted battery and product components in accordance

with applicable regulations.

v | INTRODUCTION – IMPORTANT INFORMATION

CAUTIONS

• Do not operate this unit immediately after moving it from a cold location to a

warm location. When the unit is exposed to such a change in temperature,

moisture could condense on the lens and crucial internal parts. Allow the

system to reach room temperature before operation to prevent possible

damage to the unit.

• Do not place the unit in hot locations, such as near heating equipment.

Doing so could cause a malfunction and shorten the life of the projector.

• Make sure that an electrical socket is near to your SMART product and

remains easily accessible during use.

• Do not add any extra weight or apply pressure to the UF55/UF55w projector

boom, the wall-mounted interactive whiteboard or its pen tray. SMART

designed the brackets to support only the weight of the components during

normal use.

• For operating safety and to prevent damage to your interactive whiteboard,

connect the included USB cable only to a computer that has a USB compliant

interface and that bears the USB logo. In addition, the USB source computer

must be compliant with CSA/UL/EN 60950 and bear the CE mark and CSA

and/or UL Mark(s) for CAS/UL 60950.

• Do not connect your serial cable directly to the projector’s RS-232 serial

interface. Use the extended control panel’s (ECP’s) RS-232 serial

interface only.

• In a location over 6000' (1829 m) altitude, the air is thin and cooling efficiency

is reduced, so use the projector with the fan mode set to High.

• Do not block the projector’s ventilation slots and openings.

• Avoid turning off the projector during the lamp ignition phase since this may

lead to premature lamp failure. Keep the projector lamp on for a minimum

of 15 minutes before turning it off to preserve the lamp life.

• Cycling power to the projector repeatedly can lock or damage your interactive

whiteboard system. After you turn off the system, wait at least 15 minutes

for cooling before starting the system again.

• Before you clean the UF55/UF55w projector, press the power button twice

on the ECP or remote to put the system into Idle mode, and then allow the

bulb to cool for 30 minutes.

• Do not allow liquids or commercial solvents of any kind to flow into the

projector base or head. Do not use spray cleaners or solvents near any part

of the projector since they may damage or stain the unit.

vi | INTRODUCTION – IMPORTANT INFORMATION

IMPORTANT

• Use the instructions that are in the UF55/UF55w projector boxes to install

your system. Do not use the instructions in your SMART Board interactive

whiteboard product box.

• Do not set up or use your interactive whiteboard system in an area

with excessive levels of dust, dirt, humidity or smoke.

• Do not place your interactive whiteboard system near any appliance that

generates a strong magnetic field.

• Do not place your interactive whiteboard system in direct sunlight.

• The screws that secure your interactive whiteboard to the wall are located

directly behind the pen tray. The pen tray must be removed before you can

remove your interactive whiteboard. When you secure the pen tray, you also

secure your interactive whiteboard.

• Using the UF55/UF55w projector system near a TV or radio may cause

interference to the images or sound. If this happens, move the TV or radio

away from the projector.

• Your SMART Board 600i3 or SBD600i3 interactive whiteboard system does

not include speakers. To play audio, connect an audio system to the

projector’s audio output. Consult your authorized SMART reseller

to determine your audio output options.

• If you have peripheral devices that do not use a 4-pin mini-DIN connector or

an RCA composite video jack, or if your device has an audio connection that

does not use RCA jacks, you may need to purchase third-party adapters.

• When cleaning your interactive whiteboard system:

– Wipe the exterior of the projector using a lint-free cloth.

– If necessary, use a soft cloth moistened with a mild detergent to clean the

projector housing.

– Do not use abrasive cleaners, waxes or solvents.

• Disconnect the product from its power source when it’s not used for a

long period.

• If your interactive whiteboard system requires replacement parts, make sure

that the service technician uses replacement parts specified by SMART

Technologies, or parts with the same characteristics as the original.

Contents

Important Information ..............................................................................................i

Read This Section First ....................................................................................i

Safety Warnings, Cautions and Important Information ....................................ii

1About Your SMART Board 600i3 or SBD600i3 Interactive Whiteboard System... 1

SMART Board 600i3 or SBD600i3 Interactive Whiteboard System Features 2

Interactive Whiteboard Features .............................................................. 2

UF55/UF55w Projector System Features................................................. 3

ECP and Cable ........................................................................................ 4

Standard Accessories..................................................................................... 5

Remote Control ........................................................................................ 5

Pen Tray Tools ......................................................................................... 5

Eraser....................................................................................................... 5

Optional Accessories ...................................................................................... 6

SMART Board Audio (SBA) USB Speakers............................................. 6

Wireless Bluetooth® Connection (WC6) .................................................. 6

Active USB Extension Cables (USB-XT).................................................. 6

Cat 5 to USB Cable Extender (CAT5-XT) ................................................ 6

Serial Conversion Module (RS-232)......................................................... 6

GoWire™ SMART Notebook Software

Auto-launch Cable (USB-GW).................................................................. 7

2Installing Your SMART Board 600i3 or SBD600i3

Interactive Whiteboard System ............................................................................. 9

Environmental Requirements ....................................................................... 10

Before Installing Your SMART Board 600i3 or SBD600i3

Interactive Whiteboard System..................................................................... 12

Recommended Mounting Heights .......................................................... 12

viii | CONTENTS

After Installing Your SMART Board 600i3 or SBD600i3

Interactive Whiteboard System..................................................................... 13

Adjusting Keystone Alignment ............................................................... 13

Focusing the Image................................................................................ 14

Performing an Image Alignment............................................................. 15

Securing the Pen Tray and Interactive Whiteboard................................ 19

3Connecting Your SMART Board 600i3 or SBD600i3

Interactive Whiteboard System ........................................................................... 21

Installing SMART Software........................................................................... 22

Connecting the Cables to the UF55/UF55w Projector.................................. 23

Routing the Cables................................................................................. 23

Connecting Your Guest Computer to the ECP’s Inputs ......................... 27

Connecting Peripheral Visual or Audio-Visual Devices ................................ 28

4Using Your SMART Board 600i3 or SBD600i3 Interactive Whiteboard System . 29

Turning the System On and Off and Selecting an Input ............................... 30

Using Your Interactive Whiteboard ............................................................... 30

Using Your UF55/UF55w Projector .............................................................. 31

Using Your Remote Control ................................................................... 31

Menu Options......................................................................................... 31

5Remotely Managing Your SMART Board 600i3 or SBD600i3

Interactive Whiteboard System ........................................................................... 35

Connecting Your Room Control System to the ECP .................................... 36

Pin Configuration on the ECP RS-232 Connector.................................. 36

Serial Interface Settings ......................................................................... 36

UF55/UF55w Programming Commands....................................................... 38

Powerstate Controls............................................................................... 38

Command Inventory............................................................................... 38

Powerstate Control................................................................................. 40

Source Selection .................................................................................... 41

Video Control ......................................................................................... 41

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Smart Technologies Lavagna interattiva

Smart Technologies

Smart Technologies Board 660 Manuale utente

Smart Technologies

Smart Technologies SMART Board 3000i Manuale utente

Smart Technologies

Smart Technologies Smart Board Manuale utente

Smart Technologies

Smart Technologies SMART Board 600i4 Manuale utente

Smart Technologies

Smart Technologies SMART kapp iQ Pro 55 Manuale di servizio

Smart Technologies

Smart Technologies SMART Board 480iv Manuale utente

Smart Technologies

Smart Technologies SMART Board 480iv Manuale utente

Smart Technologies

Smart Technologies SMART Board 480i5 Manuale utente

Smart Technologies

Smart Technologies Smart Board Manuale utente

Smart Technologies

Smart Technologies SMART Board 800i5e-SMP Manuale utente

Smart Technologies

Smart Technologies SB800ix3 Manuale utente

Smart Technologies

Smart Technologies SMART Board 800ixe-SMP Manuale utente

Smart Technologies

Smart Technologies Smart Board Manuale utente

Smart Technologies

Smart Technologies SMART Board 8070ie-SMP Manuale utente

Smart Technologies

Smart Technologies SMART Board 600i5 Manuale utente

Smart Technologies

Smart Technologies SMART Board 400iv Manuale utente

Smart Technologies

Smart Technologies HAWM-600i2 Manuale utente

Smart Technologies

Smart Technologies SB680i2-SE240 Manuale utente

Smart Technologies

Smart Technologies SMART Board V280 Manuale utente

Smart Technologies

Smart Technologies Smart Board Manuale utente

Smart Technologies

Smart Technologies SMART Board 480i5 Manuale utente

Smart Technologies

Smart Technologies Smart Board Istruzioni operative

Smart Technologies

Smart Technologies SBID-MX365 Manuale utente

Smart Technologies

Smart Technologies Hub PE Manuale utente

Manuali Lavagna interattiva popolari di altre marche

SMART

SMART KAPP42 Manuale utente

HitachiSoft

HitachiSoft StarBoard FX-TRIO-88W Manuale utente

Buhl

Buhl LyteBoard Manuale utente

SMART Board

SMART Board 680 Manuale utente

SMART

SMART SBX880 Manuale utente

Legamaster

Legamaster e-SCREEN ETX Manuale utente

SMART Board

SMART Board SBM685ix2 Manuale utente

Seneca

Seneca eno Manuale utente

BenQ

BenQ RP840G Manuale utente

SMART

SMART Sympodium IC-150 Manuale utente

Olivetti

Olivetti OLIBOARD Manuale utente

Turning Technologies

Turning Technologies MOBIVIEW Manuale utente

Panasonic

Panasonic UB-5335 Manuale utente

Dukane

Dukane ITP84 Manuale utente

Bretford

Bretford EDUIMS Guida alla configurazione

Panasonic

Panasonic Panaboard UB-5315 Manuale utente

Plus

Plus M-11S Manuale utente

TRIUMPH BOARD

TRIUMPH BOARD ULTRA SLIM Manuale utente
