Allows for the mixed mounting of 5 SJ series valve sizes

The SJ3000Aand SJ4000

have been added.

SJ4000

SJ3000A

SJ3000

SJ2000

7.5

SJ1000

6.5

Series Valve [mm] Flow rate characteristics Flow rate∗1

Width Height C [dm3/(s·bar)] b

L/min (ANR)

SJ1000 6.5 40 0.32 0.33 83

SJ2000 7.5 40 0.36 0.13

SJ3000 10 40 0.56 0.11 128

SJ3000A 10 40 0.76 0.19 181

SJ4000 15 50 2.61 0.20 625

∗1 Inlet pressure: 0.6 MPa, Outlet pressure: 0.5 MPa (at 20°C)

Connector

connection

CAT.ES11-87E

4-Port Solenoid Valve

Cassette Type Manifold

Rubber Seal

SJ1000/2000/3000/4000

Series

∗1

SJ2000/3000 only

∗1

Power consumption

0.15 W*1(SJ3000/4000 with power-saving circuit)

0.23 W*1(SJ1000/2000 with power-saving circuit)

*1 Refer to page 140 for details.

The manifold uses

halogen-free lead wires.

Connector type (Card edge type)

SJ1000, SJ2000, SJ3000, and

SJ4000 series valves can be

mounted together.

· Easily increase or decrease the

number of stations and easily

replace valves

The 34-pin connector allows for up

to 16 stations with double solenoids

or 32 stations with single solenoids.

Non plug-in individual wiring

compliant

*SJ2000/3000 only

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Card edge

connector

2.61

0.32

0.76

0.56

0.36

106.5 7.5 15

*1 Flow rate Q is the reference value when the inlet

side is 0.6 MPa and the outlet side is 0.5 MPa

(20°C)

*2 Weight reduced by changing the valve body material

from zinc to aluminum

*Weight (g) for the 5-station D sub-connector manifold/

single solenoids

Valve width [mm]

Sonic conductance C [dm3/(s·bar)]

SJ1000/2000/3000/4000

SJ2000

SJ1000

SJ4000

SJ3000A

456 g

(−12%)

SJ3000 comparison

413 g

(−20%)

SJ3000 comparison

386 g

(−25%)

SJ3000 comparison

796 g

SJ3000

Flow rate

4.9 times

Flow rate Q

(Reference value)*1

128 a625

L/min (ANR)

SJ3000 comparison

Flow rate

1.4 times

Flow rate Q

(Reference value)*1

128 a181

L/min (ANR)

SJ3000 comparison

516 g

4-position dual 3-port valve

• 3-port valves integrated into a single valve

• It is possible to control the 4(A) and 2(B)

ports individually.

• Can be mounted on the same manifold as

a 4-port valve

• 3 types of combinations are available.

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Unlocked

Locked

Type of manual overrideLight indication

Piping variations

With One-touch ﬁttings Threaded type

The threaded type is

not available for the

1(P) or 3/5(E) ports.

Manual locking

A sliding mechanism covers the manual override button to

prevent unintentional operation.

Connector mounting

direction

Connecter mounting direction can

be changed by sliding the switch.

Fittings are replaceable.

Fittings (including type and size) can be easily

changed by removing a clip.

Valve connection

mechanism

Connection between valves can be

secured using the valve lock switch.

Connection can be conﬁrmed by

checking to see whether the

connection hook is inserted into the

connection groove of the adjacent

valve.

*Excludes the SJ4000

SOL.a

SOL.a: ON

SOL.b: ON

SOL.b

The valve coil is kept in a de-energized

state even when there is an electric

signal from the manifold side

connector, and this enables manifold

operation.

With switch (Connector type)

• It is possible to shut off the signal of each valve individually.

• Manual operation is possible by switching the valve OFF, even if it is

in an energized state.

*SJ2000/3000 only

Green

OFF Switch

Clip

Non-locking

push type

Slide locking

type

Push-turn

locking

slotted type

The manual

button will hold the

pushed (ON) status.

OFF

B side manual

(Yellow)

A side manual

(Blue)

FREE

LOCK

Switch

Valve lock switch

Connection hook

The word “FREE” can be seen

when connection is unlocked.

SJ1000 SJ2000 SJ3000 SJ4000

Elbow ﬁtting — V V —

Thread piping — V V —

SJ1000 SJ2000 SJ3000 SJ4000

Non-locking push type V V V V

Push-turn locking

slotted type V V V V

Slide locking type — V V —

Red

A side coil

B side coil

B side manual

A side manual

B side passage symbol

A side passage symbol

A side B side Symbol

N.C.

valve

N.C.

valve

N.O.

valve

N.O.

valve

N.C.

valve

N.O.

valve

1(P)5(EA)

4(A)

3(EB)

2(B)

1(P)5(EA)

4(A)

3(EB)

2(B)

1(P)5(EA)

4(A)

3(EB)

2(B)

Details Ap. 142

¡CC-Link (32 outputs), DeviceNet®(16 or 32 outputs)

¡The connector allows for easy attaching/detaching of the SI

unit and wiring.

Separated valve power unit and transmission power unit/Improved

maintenance safety

Select between a T-branch or a straight type communication connector

¡Max. 128 points (Input 64 points/Output 64 points)

¡All wires can be plugged into the connector units.

¡CC-Link, DeviceNet®, and PROFIBUS-DP compliant

SI unit

Communication connector

Transmission power unit (for CC-Link)

Valve power unit

Straight type

T-branch type

For DeviceNet®, a transmission power unit exists in the

communication connector side of the T-branch or straight type.

Connector Type Manifold

Cable

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

D-sub connector

EX510 Gateway type serial transmission

system

*Connector type only

*Excludes the SJ4000

Flat ribbon cable

EX180 Integrated type (for output) serial

transmission system

*Connector type only

Plug-in Cable Type Manifold

*SJ2000/3000 only

D side

U side

FREE

LOCK

P port

0.5 MPa

D side

Regulator

block

0.2 MPa

U side

This is a regulator block with the same width (10 mm) as the SJ3000.

Pressure supplied from the D side is used to reduce pressure in the manifold.

The U side valves are all depressurized by the regulator block.

*Excludes the SJ4000

Regulator block

SJ3000-01-P(-H)

SJ3000-M1-P(-H)

SJ3000-00-P(-H)

Both the pressure gauge mounting position and the method of operating the pressure adjustment

screw can be selected.

*This reduces supply pressure from the

D side of the manifold. Supply pressure

from the U side cannot be reduced.

Pneumatic circuit (Example of a regulator block installation)

1(P) 3/5(E)

(Pilot passage)

2(B)4(A)

(SJ3260)

2(B)4(A)

(SJ2260) (SJ3000-00-P) (SJ3260) (SJ2260)

2(B)4(A) 2(B)4(A)

0.5 MPa

U sideD side

Regulator block

Set to 0.2 MPa

P port

0.5 MPa applied

0.2 MPa

With manual operation of the

pressure adjustment screw

Pressure gauge, top mounting

Pressure gauge, side mounting

Without pressure gauge

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Regulator block

Details Ep. 109

FREE

LOCK

Intermediate

connector block

U side

D side

This connector block can be used by inserting it into the middle

of the manifold.

It can be used, for example, when you wish to separate

electrical control of valves in the same manifold or when

the number of control points is insufﬁcient.

Intermediate connector block

Intermediate connector block wiring example

∗The U side solenoid valve with an intermediate connector block can be controlled.

∗The intermediate connector block can be ordered using the manifold speciﬁcation sheet.

Intermediate connector block

D side

U side

D side

SOL.b

SOL.a

SOL.b

Station 2

Station 1

19 20

COM

Connector block

Double solenoid

(Station 1)

SOL.a SOL.b

Double solenoid

(Station 2)

SOL.bSOL.a

SOL.b

SOL.a

SOL.b

Station 4

Station 3

19 20

COM

SOL.a SOL.b

Double solenoid

(Station 3)

SOL.bSOL.a

Double solenoid

(Station 4)

Intermediate

connector block

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Details Ep. 115

This pressure regulator is intended to adjust the SUP pressure of the manifold.

Additionally, a pressure switch and pressure gauge can be mounted on it.

*Excludes the SJ4000

SUP/EXH block with regulator and pressure switch

Lateral knob

Upward knob

Valve with speed controller

SUP/EXH block with regulator and pressure switch

Pneumatic circuit (Installation example of a SUP/EXH block with regulator and pressure switch and a valve with

speed controller)

As a speed controller is built into this valve, the cylinder

speed can be adjusted on the valve side.

2 types, meter-in and meter-out, are provided.

Meter-in: Black

Meter-out: Silver

(SJ3000B-PCB)

(B)2 4(A)

(SJ3260-S0)

(SJ3260)

4(A)(B)2

(SJ3260)

4(A)(B)2

(SJ3260-S1)

(SJ3260)

(E)3/5

(Pilot passage)

4(A)(B)2 4(A)(B)2

1(P)

U sideD side

Valve with speed controller SUP/EXH block with regulator and pressure switch

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Details Ep. 111

Low-profile

SUP/EXH block

10.2

123

The width dimension of the SUP/EXH block is only 10.2 mm, smaller

than the 15.5 mm width of the standard product, which allows for the

length of the entire manifold to be reduced.

∗Excludes the SJ4000

Low-proﬁle SUP/EXH block

(Made to order)

∗SJ1000 5-station manifold example

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

[mm]

Width Reduction

Low-proﬁle SUP/EXH block 10.2 5.3

Standard product 15.5 —

10.2

∗

The values are for an individually operated 2-position type manifold base with 5 stations.

∗Excludes the SJ3000A (Large ﬂow type) and SJ4000

Flow Rate Characteristics

Series

Port size Flow rate characteristics

1(P)

3/5(E)

4, 2

(A, B)

1 R4/2 (P RA/B) 4/2 R3/5 (A/B RE)

C [dm3/(s·bar)] C [dm3/(s·bar)]

SJ1000 C6 C2 0.12 0.13

C4 0.26 0.30

SJ2000 C6

C2 0.13 0.13

C4 0.30 0.34

M3 0.18 0.20

SJ3000 C6

C2 0.13 0.14

C4 0.38 0.45

C6 0.45 0.51

M5 0.40 0.45

Part no. Applicable

port

TG-0204 TG-0608 TG-1012

Applicable tubing O.D.

ø2/ø4 ø6/ø8 ø10

Series

SJ1000 For A, B port V— —

For P, E port — V—

SJ2000 For A, B port V— —

For P, E port — V—

SJ3000 For A, B port V V —

For P, E port — V—

SJ4000 For A, B port — V—

For P, E port — V V

ø6 One-touch fitting

Tube Releasing Tool Details EWeb Catalog

Use this to remove tubing from the A, B and P, E ports.

Details Ep. 117

TG-0204 TG-0608 TG-1012

ø8 ø12

ø6 ø10

ø4

ø2

1(P)

Release pressure port

3/5(E)

Vacuum pressure port

Slotted

locking typeManual

2(B)

Vacuum pad port

PS port: Pressure detection port

(M5 x 0.8)

Plug-in

Connector connection

Cable connection

• Individual wiring

Non plug-in

Adsorbing and Transferring System Circuit Example

With 2 built-in spool valves

Vacuum suction and release can be

controlled with a single valve.

• Serial (EX180)

• Serial (EX510)

• D-sub connector

• Flat ribbon cable

• D-sub connector

• Flat ribbon cable

Wiring variations

Filter

Restrictor

• Eliminates foreign matter on the

vacuum and release sides

• Replaceable

• Flow rate adjustment

of release air

• Prevents workpiece

blow-off

LPower consumption: 0.15 W*1(with power-

saving circuit)

LWidth: 10 mm (same as the SJ3000 series)

LEquipped with restrictor to enable ﬂow rate

adjustment of release air

LReplaceable ﬁlters are built-in on the vacuum

and release sides.

LEquipped with a pressure detection port

which allows for the connection of a

pressure switch, etc.

LCan be combined with 4-port solenoid

valves, as well as SJ1000, 2000, and 3000

series valves (Special order)

(Please contact SMC for details.)

LEnables 2-system pressure switching where

the 1(P) port and the 3/5(E) port are set to

different positive pressures

(In this case, ﬂow can be adjusted on the P-port side only.)

*1 Refer to page 140 for details.

2(B)

Vacuum pad port

1(P)

Release

pressure port

3/5(E)

Vacuum

pressure port

Vacuum

pressure

switching

valve

Filter

Vacuum side

Filter

Release side

SJ3A6

Release pressure

switching valve

(Built-in restrictor)

Vacuum Release Valve with Restrictor

SJ3A6 Series

4-Port Solenoid Valve Cassette Type Manifold SJ1000/2000/3000/4000 Series

Individual wiring

EX510

(Gateway type)

EX180

(For output)

Flat ribbon cable

D-sub connector

Connection

Parallel wiring

Serial transmission

SJ1000/2000/

3000/4000

SS5J1/2/3/4-60

SJ2000/3000

SS5J2/3-60L

SJ2000/3000

SS5J2/3-60-

SJ3A6

SS3J3-V60

SJ3A6

SS3J3-V60L

SJ3A6

SS3J3-V60-

4-port solenoid valve

Vacuum release valve with restrictor

Plug-in

Non plug-in

Connector type

Cable type

Plug-in

Non plug-in

Connector type

Cable type

∗1 A linkage-printed circuit board is built into individual wiring

valves so as to allow for use in combination with the plug-in types.

∗2

Specify the required specifications on the manifold specification sheet.

∗3 All single wiring or all double wiring can be specified.

∗4 The vacuum release valve can only use double wiring.

∗5 Only the SJ3000 size is available.

∗6

Adding 1 additional station is possible up to the max. number of stations.

∗7 Only the SJ2000 and SJ3000 sizes are available.

∗8 Excludes the SJ4000

p. 30

p. 62

p. 78

p. 29 p. 29 p. 61 p. 77

p. 33 p. 33

p. 95

p. 128p. 127 p. 127 p. 127 p. 127

p. 129 p. 129

p. 133

∗1

∗7

∗8∗8

∗1

—

——

————

—

——

————

Manifold Variations

4-Port Solenoid Valve

SJ1000/2000/3000 /4000 Series

Vacuum Release Valve

with Restrictor

SJ3A6 Series

Manifold type

Item

Questo manuale è adatto per i seguenti modelli

Altri manuali SMC Networks Unità di controllo

SMC Networks

SMC Networks VFS1000 Manuale utente

SMC Networks

SMC Networks KE Series Manuale utente

SMC Networks

SMC Networks TigerSwitch series Manuale utente

SMC Networks

SMC Networks VF1000 Series Manuale utente

SMC Networks

SMC Networks VP4 Series Manuale utente

SMC Networks

SMC Networks EX600 Series Manuale utente

SMC Networks

SMC Networks VG342 Series Manuale utente

SMC Networks

SMC Networks EX600-DX Series Manuale utente

SMC Networks

SMC Networks EX600-SMJ Series Manuale utente

SMC Networks

SMC Networks SJ 1000 Series Manuale utente

SMC Networks

SMC Networks SJ4000 Series Manuale utente

SMC Networks

SMC Networks AV2000 Manuale utente

SMC Networks

SMC Networks 56-VQC4000 Series Manuale

SMC Networks

SMC Networks VV100 Series Manuale utente

SMC Networks

SMC Networks VQC1000 Manuale utente

SMC Networks

SMC Networks EX245-FPS1 Manuale utente

SMC Networks

SMC Networks AV2000 Manuale utente

SMC Networks

SMC Networks EX250-SCF1-X200 Manuale utente

SMC Networks

SMC Networks JSXD Series Manuale utente

SMC Networks

SMC Networks VQ2000 Series Manuale

SMC Networks

SMC Networks S070 Series Manuale

SMC Networks

SMC Networks VTA301 Series Manuale utente

SMC Networks

SMC Networks MPCXX-XXX-XXX-XX-DUT01607 Manuale utente

SMC Networks

SMC Networks EX140-SMJ1 Series Manuale utente

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
