SMC Networks 6824MPE INT - FICHE TECHNIQUE Manuale di programmazione

TigerStack III 10/100

24-

Port Fast Ethernet PoE Swi

tch

Management Guide

◆24 auto-MDI/MDI-X 10BASE-T/100BASE-TX ports

◆10BASE-T/100BASE-TX ports support PoE capabilities

◆2 Gigabit RJ-45 ports shared with 2 SFP transceiver slots

◆8.8 Gbps of aggregate bandwidth

◆Stacks up to 8 units

◆Non-blocking switching architecture

◆Spanning Tree Protocol and Rapid STP

◆Up to six LACP or static 4-port trunks

◆RADIUS and TACACS+ authentication

◆Rate limiting for bandwidth management

◆CoS support for four-level priority

◆Full support for VLANs with GVRP

◆IP Multicasting with IGMP Snooping

◆Manageable via console, Web, SNMP/RMON

Management Guide
