SMC Networks SMC-EZ1026DT Manuale utente

Benefits

SMC-EZ1026DT

Model Number::

EZ SwitchTM 10/100

24-Port 10/100 Mbps Standalone Unmanaged

Layer 2 Switch

Features

• 24 RJ-45 ports

• Optional expansion modules

• 8.8 Gbps aggregate bandwidth

• Desktop or rackmountable

• Port based VLANs

• Broadcast storm control

• Half and full duplex flow

control

Benefits

• High-port density enables easy network

expansion

• Expansion modules offer flexibility in

network growth

• Gigabit uplinks can provide 4 Gbps band-

width for congested network

• 8.8 Gbps available bandwidth for growing

workgroups

• Suitable for all networking needs

Compatibility

• IEEE 802.3

• 802.3u

• 802.3z

• IEEE 802.3x full-duplex flow

control

• ISO/IEC 8802-3

Switches/Hubs

Today’s IT managers with high-density and compli-

cated networks require flexibility of options,stan-

dards-based compliance pack with industry lead-

ing support. SMC’s upgraded SMC1026DT is the

perfect solution for all these things. Redesigned

with the modular port on the front for ease of use,

the SMC1026DT features 24 10Base-T/100Base-TX

ports and is the ideal choice for boosting LAN

bandwidth for mid-sized workgroups. Moreover,

with modules that include 8 additional 10/100

ports,Gigabit Copper and fiber and 100 Mbps

fiber,the SMC1026DT is THE solution for any net-

work anywhere.

Designed for the SMB space,the EZ1026DT is the

most cost effective solution when migrating to

higher port density (32-ports with optional 8-port

module inserted),fiber connectivity to a backbone

with 100 Mbps or 1000 Mbps.

This Fast Ethernet switch is an excellent choice as a

departmental collapsed backbone,as it supports

Fast Ethernet hubs, servers, power users,in addi-

tional to legacy Ethernet LAN segments. Its store-

and-forward design prevents bad data packets

from propagating throughout the network.

Featuring a large 12000k MAC address table,flow

control and VLAN capabilities,the SMC1026DT

ensures data integrity and delivery even under

heavy loading.

6 H u g h e s

Irvine,CA 92618

1-800-SMC-4YOU

www.smc.com

SMC-EZ1026DT

Switches/Hubs

Ports

24 RJ-45 ports, fixed crossover

10Base-T1100Base-TX ports

ForwardingMode

Store-and-forward

MACAddressTable

12,000 MAC address entries

Automatic MAC address learning

Filtering/Forwarding/

LearningRates

Full line rate

Full Duplex

All ports via Auto-Negotiation

LEDIndicators

Power,Link/Activity,Half-/

full-duplex

Power on self diagnostics

Size

(17.3 x 9.5 x 1.69) in

Weight

6.6 lbs

Temperature

Operating:32° - 131˚ F

Storage: -4° - 185˚ F

Humidity

5% - 95% (non-condensing)

PowerSupply

100 to 240 VAC (+/- 10%)

50 to 60 Hz (+/- 3 Hz)

PowerConsumption

35Watts (maximum)

HeatDissipation

119 BTU/hr.maximum @ 100-

240VAC

Standards

IEEE802.3,802.3u,802.3x

ISO/IEC 8802-3

EMCSafetyCompliances

CE Mark

Emissions

FCC Class A

EN55024 (CISPR22) Class A

EN5500022 (CISPR 22) Class A

C-Tick – AS/NZS 3548 (1995)

Class A

Immunity

IEC 1000-4-2/3/4/5/6/11

Safety

CSA/NRTL (CSA 22.2 No.950 &

UL 1950)

EN60950 (TUV/GS)

Warranty

Limited lifetime

OptionalModules:

10/100Base-TX Module

Model

SMC-EZ1026T

AccessMethod

CSMA/CD

Ports

8 10Base-T/100Base-TX,with

auto-negotiation

CommunicationMode

Full and half duplex with auto-

negotiation

NetworkInterface

RJ-45:100 ohm,UTP cable

10Base-T – Categories 3,4,5

100Base-TX – Category 5

LEDs

LINK/ACT,FDX/COL

Standards

IEEE 802.3

IEEE 802.3u

1000Base-T Module

Model

SMC-EZ1026GT

AccessMethod

CSMA/CD

Ports

2 10Base-T/100-Base-

TX/1000Base-T,with auto-negoti-

ation

CommunicationMode

Full and half duplex with auto-

negotiation

NetworkInterface

RJ-45:100 ohm,UTP cable

10Base-T – Categories 3,4,5

100Base-TX – Category 5

1000Base-T – Category 5 or 5e

LEDs

SPD,LINK,ACT,FDX/COL

Standards

IEEE 802.3

IEEE 802.3u

IEEE 802.3ab

100Base-FX Module

Model

SMC-EZ1026FMSC

AccessMethod

CSMA/CD

Ports

2 100Base-FX/

CommunicationMode

Full duplex

NetworkInterface

SC connector:50/125 or 62.5/125

micron multimode fiber cable

LEDs

LINK/ACT

Standards

IEEE 802.3u

1000BaseSE-SX Module

Model

SMC-EZ1026GSSC

AccessMethod

CSMA/CD

Ports

2 1000-BaseSX

CommunicationMode

Full duplex

NetworkInterface

SC connector:50/125 or 62.5/125

micron multimode fiber cable

LEDs

LINK/ACT

Standards

IEEE 802.3z

EZ SwitchTM 10/100

24-Port 10/100 Mbps Standalone Unmanaged

Layer 2 Switch

Product Description

SMC-EZ1026DT Fast Ethernet Switch with 24 10/100 Ports and 2 Gigabit Uplink Slots

SMC1026T 8-Port 10/100 Expansion Module

SMC1026GT 2-Port 10/100/1000 Expansion Module

SMC1026FMSC 2-Port 100Base - FX Expansion Module

SMC1026GSSC 2-Port 1000Base-SX Expansion Module
