Smeg SI2M7643D Manuale utente
SI2M7643D
User Manual
Hob
Notice d'utili‐
sation
Table de
cuisson
Benutzerin‐
formation
Kochfeld
CONTENTS
Safety information 2
Safety instructions 4
Product description 6
Daily use 8
Hints and tips 13
Care and cleaning 15
Troubleshooting 15
Installation 17
Technical data 20
Energy efficiency 21
Subject to change without notice.
SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the result of
incorrect installation or usage. Always keep the instructions
in a safe and accessible location for future reference.
Children and vulnerable people safety
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
the use of the appliance in a safe way and understand the
hazards involved.
•Children between 3 and 8 years of age and persons with
very extensive and complex disabilities shall be kept away
unless continuously supervised.
•Children of less than 3 years of age should be kept away
unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are hot.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user maintenance
of the appliance without supervision.
2
General Safety
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
•Do not operate the appliance by means of an external
timer or separate remote-control system.
•WARNING: Unattended cooking on a hob with fat or oil
can be dangerous and may result in fire.
•NEVER try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
•CAUTION: The cooking process has to be supervised. A
short term cooking process has to be supervised
continuously.
•WARNING: Danger of fire: Do not store items on the
cooking surfaces.
•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can get
hot.
•Do not use a steam cleaner to clean the appliance.
•After use, switch off the hob element by its control and do
not rely on the pan detector.
•If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In
case the appliance is connected to the mains directly using
junction box, remove the fuse to disconnect the appliance
from power supply. In either case contact the Authorised
Service Centre.
•If the supply cord is damaged, it must be replaced by the
manufacturer, an authorized Service or similarly qualified
persons in order to avoid a hazard.
•WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by the
manufacturer of the appliance in the instructions for use as
suitable or hob guards incorporated in the appliance. The
use of inappropriate guards can cause accidents.
3
SAFETY INSTRUCTIONS
Installation
WARNING! Only a qualified
person must install this
appliance.
WARNING! Risk of injury or
damage to the appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Keep the minimum distance from other
appliances and units.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Seal the cut surfaces with a sealant to
prevent moisture to cause swelling.
• Protect the bottom of the appliance
from steam and moisture.
• Do not install the appliance adjacent to
a door or under a window. This
prevents hot cookware falling from the
appliance when the door or the window
is opened.
• Each appliance has cooling fans on the
bottom.
• If the appliance is installed above a
drawer:
– Do not store any small pieces or
sheets of paper that could be pulled
in, as they can damage the cooling
fans or impair the cooling system.
– Keep a distance of minimum 2 cm
between the bottom of the
appliance and parts stored in the
drawer.
Electrical Connection
WARNING! Risk of fire and
electric shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Make sure the appliance is installed
correctly. Loose and incorrect electricity
mains cable or plug (if applicable) can
make the terminal become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to the near
sockets.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the
mains cable. Contact our Authorised
Service Centre or an electrician to
change a damaged mains cable.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
4
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
Use
WARNING! Risk of injury,
burns and electric shock.
• Remove all the packaging, labelling
and protective film (if applicable) before
first use.
• Use this appliance in a household
environment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Set the cooking zone to “off” after each
use.
• Do not rely on the pan detector.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become
hot.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is
cracked, disconnect immediately the
appliance from the power supply. This
to prevent an electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it may
splash.
WARNING! Risk of fire and
explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
WARNING! Risk of damage to
the appliance.
• Do not keep hot cookware on the
control panel.
• Do not put a hot pan cover on the glass
surface of the hob.
• Do not let cookware to boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron, aluminium
or with a damaged bottom can cause
scratches on the glass / glass ceramic.
Always lift these objects up when you
have to move them on the cooking
surface.
• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
Care and cleaning
• Clean the appliance regularly to
prevent the deterioration of the surface
material.
• Deactivate the appliance and let it cool
down before you clean it.
• Disconnect the appliance from the
electrical supply before maintenance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
5
Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
Disposal
WARNING! Risk of injury or
suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
PRODUCT DESCRIPTION
Cooking surface layout
1
11
2
1
1Induction cooking zone
2Control panel
Control panel layout
1 2 3 675
9 8
10
4
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell
which functions operate.
Sensor
field
Function Comment
1ON / OFF To activate and deactivate the hob.
6
Sensor
field
Function Comment
2Lock / Child Safety De‐
vice
To lock / unlock the control panel.
3 / MultiZone To activate and deactivate the function.
4Auto-Vent To activate and deactivate the manual mode
of the function.
5- Heat setting display To show the heat setting.
6- Timer indicators of
cooking zones
To show for which zone you set the time.
7- Timer display To show the time in minutes.
8- To select the cooking zone.
9 / - To increase or decrease the time.
10 - Control bar To set a heat setting.
Heat setting displays
Display Description
The cooking zone is deactivated.
- The cooking zone operates.
Accelerator operates.
Power function operates.
+ digit There is a malfunction.
/ / Eco-Heat (3-step Residual heat indicator): continue cooking / keep
warm / residual heat.
Lock / Child Safety Device operates.
Incorrect or too small cookware or no cookware on the cooking zone.
Automatic Switch Off operates.
7
Eco-Heat (3 step Residual heat
indicator)
WARNING! / / There
is a risk of burns from residual
heat. The indicator shows the
level of the residual heat. If a
given zone becomes too hot
the function may lower the heat
setting for neighbouring zones.
The induction cooking zones produce the
heat necessary for the cooking process
directly in the bottom of the cookware. The
glass ceramic is heated by the heat of the
cookware.
DAILY USE
WARNING! Refer to Safety
chapters.
Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after you
activate the hob,
• you spill something or put something
on the control panel for more than 10
seconds (a pan, a cloth, etc.). An
acoustic signal sounds and the hob
deactivates. Remove the object or
clean the control panel.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking
zone cool down before you use the hob
again.
• you use incorrect cookware. The
symbol comes on and the cooking
zone deactivates automatically after 2
minutes.
• you do not deactivate a cooking zone
or change the heat setting. After some
time comes on and the hob
deactivates.
The relation between the heat setting
and the time after which the hob
deactivates:
Heat setting The hob deacti‐
vates after
1 - 3 6 hours
4 - 7 5 hours
8 - 9 4 hours
10 - 14 1.5 hour
The heat setting
To set or change the heat setting:
Touch the control bar at the correct heat
setting or move your finger along the
control bar until you reach the correct heat
setting.
Using the cooking zones
Place the cookware in the centre of the
selected zone. Induction cooking zones
adapt to the dimension of the bottom of
the cookware automatically.
You can cook with large cookware placed
on two cooking zones at the same time.
The cookware must cover the centres of
both zones. Correct cookware positions:
8
Incorrect cookware positions:
MultiZone
The function operates when the
pot covers the centres of the
two zones.
This function connects two cooking zones
and they operate as one.
First set the heat setting for one of the
cooking zones.
To activate the function for left / right
cooking zones: touch / . To set or
change the heat setting touch one of the
left / right control sensors.
To deactivate the function: touch / .
The cooking zones operate independently.
Accelerator
Activate this function to get a desired heat
setting in a shorter time. When it is on, the
zone operates on the highest setting in the
beginning and then continues to cook at
the desired heating setting.
To activate the function the
cooking zone must be cold.
To activate the function for a cooking
zone: touch the end of the control bar on
the right ( comes on). Immediately
touch a desired heat setting. After 3
seconds comes on.
To deactivate the function: change the
heat setting.
Power function
This function makes more power available
to the induction cooking zones. The
function can be activated for the induction
cooking zone only for a limited period of
time. After this time the induction cooking
zone automatically sets back to the
highest heat setting.
Refer to “Technical information”
chapter.
To activate the function for a cooking
zone: touch the end of the control bar on
the right. comes on.
To deactivate the function: change the
heat setting.
Timer
Count Down Timer
You can use this function to set how long
the cooking zone should operate for a
single cooking session.
First set the heat setting for the cooking
zone then set the function.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of the
timer to set the time (00 - 99 minutes).
When the indicator of the cooking zone
starts to flash slowly the time counts
down.
To see the remaining time: set the
cooking zone with . The indicator of
the cooking zone starts to flash quickly.
The display shows the remaining time.
To change the time: set the cooking zone
with . Touch or .
To deactivate the function: set the
cooking zone with and touch .
9
The remaining time counts back to 00.
The indicator of the cooking zone goes
out.
When the time comes to an
end, the sound operates and
00 flashes. The cooking zone
deactivates.
To stop the sound: touch .
CountUp Timer (The count up timer)
You can use this function to monitor how
long the cooking zone operates.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of the
timer. comes on. When the indicator of
the cooking zone starts to flash slowly the
time counts up. The display switches
between and counted time (minutes).
To see how long the cooking zone
operates: set the cooking zone with
. The indicator of the cooking zone
starts to flash quickly. The display shows
how long the zone operates.
To deactivate the function: set the
cooking zone with and touch or
. The indicator of the cooking zone goes
out.
Minute Minder
You can use this function as a Minute
Minder when the hob is activated and the
cooking zones do not operate. The heat
setting display shows .
To activate the function: touch .
Touch or of the timer to set the time.
When the time comes to an end, the
sound operates and 00 flashes.
To stop the sound: touch .
The function has no effect on
the operation of the cooking
zones.
Lock
You can lock the control panel while
cooking zones operate. It prevents an
accidental change of the heat setting.
Set the heat setting first.
To activate the function: touch .
comes on for 4 seconds. The Timer stays
on.
To deactivate the function: touch .
The previous heat setting comes on.
When you deactivate the hob,
you also deactivate this
function.
Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: activate the hob
with . Do not set the heat setting. Touch
for 4 seconds. comes on.
Deactivate the hob with .
To deactivate the function: activate the
hob with . Do not set the heat setting.
Touch for 4 seconds. comes on.
Deactivate the hob with .
To override the function for only one
cooking time: activate the hob with .
comes on. Touch for 4 seconds.
Set the heat setting in 10 seconds. You
can operate the hob. When you deactivate
the hob with the function operates
again.
OffSound Control (Deactivating
and activating the sounds)
Deactivate the hob. Touch for 3
seconds. The display comes on and goes
out. Touch for 3 seconds. or
comes on. Touch of the timer to
choose one of the following:
• - the sounds are off
10
Indice
Altri manuali Smeg Piano cottura
Smeg
Smeg SA611XA Manuale
Smeg
Smeg SE2842ID2 Manuale utente
Smeg
Smeg Classic PM3953D Manuale utente
Smeg
Smeg Linea PX7502AU Manuale utente
Smeg
Smeg P1752XBN Manuale utente
Smeg
Smeg Hob Manuale di istruzioni
Smeg
Smeg AS21T76F Manuale utente
Smeg
Smeg SE264SX3 Manuale utente
Smeg
Smeg Electric Built-in Hob Unit SE2755PS Manuale operativo
Smeg
Smeg Universale Aesthetic SI7633B Manuale utente
Smeg
Smeg PGA32C Manuale utente
Smeg
Smeg SR 864 OGH Manuale utente
Smeg
Smeg PGA95SC3 Manuale utente
Smeg
Smeg CIR34XS Manuale utente
Smeg
Smeg PVA750A Manuale utente
Smeg
Smeg SE2931ID Manuale utente
Smeg
Smeg GKC641-3 Manuale utente
Smeg
Smeg SR775AOD Manuale utente
Smeg
Smeg 3EI375B Manuale di istruzioni
Smeg
Smeg Hob Manuale utente
