Sony Ericsson J132A Manuale utente
J132/J132a
User guide
This is the Internet version of the User guide. © Print only for private use.
2
Congratulations on your purchase of the
Sony Ericsson J132/J132a. For product support,
go to www.sonyericsson.com/support.
Instruction symbols
The following instruction symbols appear in this User guide:
> Use the navigation key to scroll and select.
Press the navigation key up.
Press the navigation key down.
Press the navigation key to the left.
Press the navigation key to the right.
Tip
Note
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
This is the Internet version of the User guide. © Print only for private use.
3
Turning on the phone
To turn on the phone
1Press and hold down .
2Enter your PIN if requested. To
correct mistakes, select Clear.
3Select OK.
4Select a language.
5Enter the time and date and select OK.
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This view or
screen is called standby. You can now make and receive calls.
To turn off the phone
•Press and hold down .
Phone model
You can check your phone model in the Settings menu.
To check the phone model
•From standby select Menu > Settings > Phone status.
If the screen turns dark when you enter your PIN, press
the left selection key to turn on the screen light.
This is the Internet version of the User guide. © Print only for private use.
4
Charging the battery
Your phone battery is partly charged when you buy it. It takes
approximately 3 hours to fully charge the battery.
To charge the battery
1Connect the charger to the phone. Press a key to view the
charging status on the screen.
2To remove the charger, pull the plug straight out.
It may take 30 minutes for the battery icon to appear
on the screen.
You can use the phone during charging. You can charge
the battery for more or less than 3 hours. Interrupted
charging will not damage the battery.
This is the Internet version of the User guide. © Print only for private use.
5
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone and
detach the charger before you insert or remove the SIM
card.
PIN code (SIM card lock)
The PIN (Personal Identification Number) code is a SIM card
lock that protects your subscription, but not the phone itself.
If the card is locked, you have to enter the PIN code when you
turn on your phone. To change your PIN code, see SIM card
lock on page 34.
Each PIN digit appears as *, unless it starts with emergency
number digits, for example, 112 or 911. You can call an
emergency number without entering a PIN.
You can save contacts on the SIM card before removing it
from your phone. Contacts may also be saved in the phone
memory. See Contacts on page 20.
If you enter the wrong PIN three times in a row, the
following message appears: PIN blocked. Enter PUK
provided by your operator. To unblock your SIM card,
see Troubleshooting on page 36.
This is the Internet version of the User guide. © Print only for private use.
6
Phone overview
Call key
Navigation key
with shortcuts
Stereo handsfree
connector
Left selection key
Battery charger
connector
Network coverage
Function for left
selection key
Menu Contacts
Keylock
End key,
On/off key
Volume keys
(Up/down)
Right selection
key
Battery status
Function for right
selection key
Torch
This is the Internet version of the User guide. © Print only for private use.
7
Menu overview
Messaging Text message, Inbox, Sent messages,
Drafts, Saved messages, Delete
messages, Messaging tips, Settings
SIM toolkit* * SIM card function. Menu is operator
and subscription dependent.
Extras Alarm clock, Reminders, Birthdays,
Calendar, Timer, Stopwatch, Calculator,
Games, Torch
Contacts View contacts, Add contact, My number,
Voicemail, Delete, Speed dial, SIM
contacts, Service numbers, Contacts
tips, Settings
Calls Call list, Call timer, Call tips, Call settings
Settings Phone status, Sounds & alerts,
Wallpaper, Time and date, Language,
Advanced
Radio
Some menus and icons described in this document may
vary depending on operator, network or subscription.
This is the Internet version of the User guide. © Print only for private use.
8
Screen icons
Network coverage
The network bars show the strength of the GSM network. Move
to another location if you have network problems. No network
means you are out of range.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
This is the Internet version of the User guide. © Print only for private use.
9
These icons may appear in your phone.
Icon Description
Battery charging, appears with battery icon.
You have missed a call.
The phone is set to silent.
You have received a new text message.
You have received a new voice message.
Ongoing call.
Divert calls is activated.
An alarm is activated.
The loudspeaker is on.
Predictive text input is used (dictionary).
The keypad is locked.
The radio is playing in the background.
Some services may be operator-, network- and
subscription-dependent.
This is the Internet version of the User guide. © Print only for private use.
10
Shortcuts
From standby you can use the navigation keys to go directly
to a function:
•To go to contacts, press .
•To write a text message, press .
•To set the alarm, press .
•To play the radio, press .
This is the Internet version of the User guide. © Print only for private use.
