C2003 Sony Corporation Printed in Japan

Recording Tips

IC Recorder ICD-BM1/BM1PRO

Quick Reference Card

3-261-558-11(1)

For details, see the operating instructions.

Playing Back

1Slide POWER

to ON. 4Speak into the

built-in

microphone.

2To record as a

new message,

press NEW FILE.

3Slide the control

key to REC.

Recording

1Press FOLDER.

2Press the jog lever

up or down (>/

.) to display

the desired folder.

4Press the jog lever

up or down (>/

.) to display

the desired

message.

5Slide the control

key to PLAY.

6Adjust the volume

with VOL +/– .

3Press ENTER

to select the

folder.

OPR indicator

Lights in red during

recording.

To stop recording

Slide the control key to STOP.

To select a folder for recording

Follow steps 1 through 3 of “Playing back.”

Remaining

memory

Recording

mode

Message

number

Microphone

sensitivity

Counter display

OPR indicator

Lights in green during playback.

Counter display

To stop playback

Slide the control key to STOP.

Start recording at any point

by pressing NEW FILE

Start recording at the end

of Message 1

Start recording at a point

in the middle of Message 1

Message 1 Message 2

Recording is added as part of Message 1. It overwrites part of the original Message 1.

Blank space

Recording is added as a new message after the last message (Message 3).

Message 1 Message 2 Message 3

Overwrite

recording

New

recording

You can use the following three types of recording (1/

2/3) depending on where or how you start recording:

Example)

Recording is added as part of Message 1. It is added after the end of the original Message 1

without deleting part of the original message.

Message 1 Message 2 Blank space

Add

recording

bbb

Quick Reference Card

Erasing Messages

Setting the Recording Mode Adjusting the Playback Speed

in natural tone

— DPC(Digital Pitch Control)

Setting the Microphone Sensitivity

ERASE

FOLDER

ENTER

CANCEL

Jog lever (>/.)

To erase messages one by one

1Press ERASE during playback or press

ERASE for more than 1 second during

stop mode.

2Press ENTER while “ERASE” is flashing.

To erase all the messages in a folder

1Select the desired folder. (Follow steps 1

through 3 of “Playing back.”)

2Press FOLDER. Then keep pressing

FOLDER and press ERASE for more than

1 second.

3While “ERASE ALL?” is flashing, press

ENTER.

Jog lever (>/.)

ENTER CANCEL

You can select the recording mode:

ST: High quality recording mode (Stereo

recording is available with an external

stereo microphone (not supplied).)

SP: Standard play monaural recording

mode

LP: Long play monaural recording mode

1Press MENU to display the menu mode.

Press the jog lever up or down (>/.)

to select “MODE” and press ENTER.

3Press the jog lever up or down (>/

.) to select the desired recording

mode (ST/SP/LP) and press ENTER.

4Press MENU to exit the menu mode.

MIC SENS (microphone

sensitivity) switch

CONF(H): To record a small sound at a

conference or in a quiet and/or

spacious place.

DICT(L): To record for dictation.

Slide the MIC SENS

(microphone sensitivity )

switch during stop or

recording mode.

DPC (Digital Pitch

Control) switch

Setting the playback speed

Follow the steps of “Setting the Recording

Mode” to select DPC in the menu and press

the jog lever for the playback speed:

:Fast play (up to +100% in increments

of 10%)

:Slow play (down to –50% in

decrements of 5%)

Playing back a message rapidly or

slowly

Slide the DPC switch to ON.

“FAST PLAY” or “SLOW

PLAY” flashes and the

message is played back at

the speed you specified with

the menu.

To resume normal playback

Slide the DPC switch to OFF.

Starting Recording Automatically

in Response to the Sound — VOR

VOR (voice operated

recording) switch

Slide the VOR switch to ON.

Recording starts when the unit

detects sound. “VOR” is

displayed.

Recording pauses when no sound is

detected. “VOR PAUSE” is displayed.
