Soundcore Life Note 3S Manuale utente
Soundcore Life Note 3S
USER MANUAL
01 EN
Charging
• Fully dry off the earbuds and the USB port before charging.
• Use a certified USB-C charging cable and charger to prevent any damage.
• Fully charge both the earbuds and the charging case before the first use.
1. Place the earbuds in the charging case and close it.
2. Connect the charging case to the power supply by using a USB-C charging
cable. Alternatively, position the charging case at the center of your wireless
charger for wireless charging.
The LED indicator on the charging case indicates the charging status.
230% - 70%
0% - 30%
70% - 100%
100%
60s
1
R
Wearing
Insert the earbuds into the inner canal of your ears and turn gently until you find
the most comfortable and secure position.
02 EN
Powering On/Off
Open the charging case, and the earbuds will automatically power on.
To power off, place the earbuds in the charging case and close it.
ON
R
2
1
OFF
R
• The earbuds will automatically power off after 30 minutes if no device is
connected.
Bluetooth Pairing
1. Remove the sticker on the earbuds before first use.
2. Place the earbuds in the charging case and close it.
3. Open the charging case (no need to take out the earbuds), and the earbuds will
automatically enter Bluetooth pairing mode.
• The 3 LED indicators on the charging case will flash white in sequence
continuously.
4. Select "Soundcore Life Note 3S" on your device's Bluetooth list to connect.
• When successfully connected, the 3 LED indicators will turn white for 3
seconds and then turn off.
4
Soundcore
Life Note 3S
Soundcore
Life Note 3S
3
PAIRING
CONNECTED 3s
R
1
L
R
2
R
• Pairing with another device: Place the earbuds in the charging case and leave
the case open. To enter Bluetooth pairing mode, press and hold the button
on the case for 3 seconds until the 3 LED indicators flash white in sequence
continuously.
03 EN
• Auto pairing: Each time you power on your Soundcore earbuds, they will
automatically connect to your last successfully connected device if available
within the Bluetooth range.
• Mono mode: When Bluetooth is connected, you can use either one of the
earbuds by placing the other one into the charging case and closing it.
• When powered on and connected, if either one of the earbuds is out of
battery and powered off, you can keep using the other one.
• Stereo mode to Mono mode: When you are on a call, place either one of the
earbuds into the charging case, and the microphone in the other earbud will
be activated.
• Mono mode to Stereo mode: The unused earbud will be activated when taken
out of the charging case. The ongoing phone call and music playback will not
be affected.
Controls
Stereo Mode
Play/Pause Tap twice (R)
Next track Tap twice (L)
Answer a call Tap twice (R/L)
End/Reject a call Press and hold for 2 seconds (R/L)
Activate Siri or other voice assistant software Press and hold for 2 seconds (R/L)
04 EN
Mono Mode
Play/Pause Tap twice
Answer a call
End/Reject a call Press and hold for 2 seconds
Activate Siri or other voice assistant software
Soundcore App
Download the Soundcore app to enhance your experience.
User interface customization: In stereo mode, all of the controls (e.g. adjust
volume, control playback, activate Siri) can be customized in the app.
EQ settings: There are more than 20 EQ settings you can choose from in the app
to optimize your experience while enjoying different music genres.
Find Device: This feature allows the earbuds to start beeping and helps you locate
them.
Superior Sleep: Use a mix of your favorite ambient sounds to improve sleep.
Gaming Mode: Turn on Gaming Mode to reduce latency and enhance the sounds
of footsteps and voices.
Earbuds firmware upgrade: You will be informed once the new version of firmware
is detected when you connect the earbuds with the app. Ensure the earbuds are
placed in the charging case and the case remains open until the firmware upgrade
is completed. During the upgrade, ensure the earbuds are being charged and
avoid any operation.
05 EN
Reset
You might need to reset the earbuds if you experience any connectivity problems
or function issues.
1. Place the earbuds in the charging case and make sure they are being charged.
2. Leave the case open, press and hold the button on the case for 10 seconds until
the 3 LED indicators flash white simultaneously 3 times. This confirms that the
reset was successful and your earbuds can be connected normally.
2
R
10
s
×3
R
1
R
06 EN
Specifications
Specifications are subject to change without notice.
Input 5 V 0.7 A
Rated output power 5 mW
Battery capacity 40 mAh x 2 (earbuds);
800 mAh (charging case)
Charging time 3 hours
Playtime
(varies by volume level and content)
Up to 5 hours
(Total 35 hours with the charging case)
Driver size 13.4 mm
Frequency response 20 Hz - 20 kHz
Impedance 32 Ω
Waterproof level (Earbuds) IPX4
Bluetooth version 5.2
Bluetooth range 12 m / 39 ft
