Speco CILT13D1G Manuale utente

Please read this manual thoroughly before operation and keep

it handy for further reference.

CILT13D1G (DC AI 2.8~12mm)

CILT13D7G (3.6mm)

620Line Intense Light

Tamperproof Dome

Vandal Resistant

w/Chameleon Cover

Wall/Ceiling Mount

DO NOT use power sources other than that specified.______

The lighting flash with an arrowhead symbol, within an equilateral triangle is

Intended to alert the user to the presence of un-insulated “dangerous voltage”

within the product’s enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons____________________________________

The exclamation point within an equilateral triangle is intended to alert the user

to the presence of important operating and maintenance (serving) instructions

in the literature accompanying the appliance__________________

INFORMATION -This equipment has been tested and found to company with

limits for a class a digital device Pursuant to part 15 of the FCC rules.

These limits are designed to provide reasonable protection against harmful

Interference W hen the equipments operated in a commercial environment.

This equipment generates, uses, and Can Radiate radio frequency energy and

if not installed and used in accordance with the instruction manual, may Cause

Harmful interference to radio communications. Operation of this equipment in a

r e s i d e n t i a l a r e a is l i k e l y to c a u s e h a r m f u l i n t e r f e r e n c e in w h i c h

Case the user will be required to correct the interference at his own expense.

WARNING –Change or modification not expressly approved by the manufacturer could void

the user’s authority to operate the equipment__________________________________

CAUTION : To prevent electric shock and risk of fire hazards.

DO NOT expose this appliance to rain or moisture.000

This installation should be made by a qualified service person and should conform to all local codes.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR B ACK).

NO USER SERVICEABLE PARTS INSIDE

R E F E R S E R V I C I N G TO Q U A L I F I E D

SERVICE PERSONNEL._______________

CAUTION

WARNING & CAUTION

PACKAGE CONTENTS

Please make sure that the following items are included

in the Package:

-3 Mounting Screws and Anchors

-1 Tamperproof Screw

-1 Wrench

-1 Video Test Connector

-1 Power Cable

-1 Chameleon Cover

CAMERA INSTALLATION

* Spray the color of your choice onto the Chameleon cover

* If necessary, apply a second coat

* Painting method for the Chameleon Dome

Place the Chameleon Dome over the camera and push until it snaps

into position.

●Notes : Optional painting before installation

CHAMELEON COVER

FEATURES

1. SUPER HIGH RESOLUTION

Sony Super HAD II CCD with an innovated new DSP Technology will

enable to achieve Super High Resolution 620TVL with High S/N Ratio.

2. SENS-UP

Digitally manipulates the exposure level of the image to produce bright

images in the darkest of scenarios.

3. 3D-DNR

The high performance DSP Technology reduces the gain noise in

digital image processing, producing clear sharp images in low light

condition.

4. HLC

This feature allows extremely bright areas in the viewing area to be

masked off.

5. D-WDR (Digital Wide Dynamic Range)

With the newly innovated DSP Technology, the camera produces high

quality images even with strong backlight.

6. DPC (Defect Pixel Correction)

It performs the detection and correction of defective pixels in

a camera Image sensor array.

7. DAY / NIGHT

Switch to appropriate mode (Color or B/W) automatically.

8 . Miscellaneous

The camera conveys various features including Motion detection,

Privacy Masking, Mirror, Sharpness, BLC, etc.

OSD MENU TREE

EXPOSURE

•LENS

•AWB MODE

•D&N MODE •BURST •C-SUP

•MOTION

•ALARM OUTPUT

•AREA •SENSITIVITY •DISPLAY •HOLD TIME

•RETURN

•LANGUAGE •TITLE •COMMUNICATION •DPC

•FACTORY SET •RETURN

DAY&NIGHT

IMAGE ADJUST

MOTION

SPECIAL

EXIT

•AGC •SENS-UP •BACKLIGHT •3D-DNR •RETURN

•BLC

•HLC •D-WDR

WHITE BALANCE

•R-Y GAIN •B-Y GAIN •RETURN

•ATW •MANUAL •PUSH

•A-SUP •SMART IR •RETURN

•AUTO

•COLOR •B/W •EXT

•MIRROR •SHARPNESS •GAMMA •LSC •MONITOR •RETURN

PRIVACY

•RETURN

OSD MENU DETAILS

*EXPOSURE*

1) LENS

DC IRIS : Used with DC auto iris lens.

- BRIGHTNESS : Adjusts image brightness. (000 ~ 100)

- E. SHUTTER : Auto / Manual Shutter can be selectable.

MANUAL : Used with manual lens.

- BRIGHTNESS : Adjusts image brightness.

- E. SHUTTER : Auto / Manual Shutter can be selectable.

2) AGC : Adjusts the AGC level. (HIGH/MID/LOW/OFF)

3) SENS-UP : Sets the desired multiple of the digital exposure length.

(AUTO/OFF/x2 ~ x256)

4) BACKLIGHT : : Adjusts backlight options.

BLC : Compensates for heavily backlit scenes.

- BLC MODEL : Adjusts the BLC mode (AUTO/MANUAL)

- BLC LEVEL : Adjusts the BLC level.(HIGH/MID/OFF)

HLC : This feature allows extremely bright areas in the viewing area to

be masked off.

- HBLC : Adjust the BLC function additionally while the HLC is

enabled.

- MODE : Sets the desired mode to use HLC all day or night time only.

( ALL DAY/ NIGHT)

- HLC LEVEL : Adjusts the level of masking.

- MASK1 ~4 : Sets which areas will be active for the HLC feature.

D-WDR : Enables digital wide dynamic range to balance dark and

light areas in the scene.

5) 3D-DNR : Reduces the background noise caused by the digital

enhancement of a low light environment. If AGC is turned OFF, the 3D-

DNR will be disabled. (AUTO / HIGH / MID / LOW / OFF)

OSD MENU DETAILS

*WHITE BALANCE*

1) AWB MODE

ATW : Automatically white balances the image.

MANUAL : Select M-WR or M-WB then enter the MANUAL white

balancing mode to manually adjust the scene to your desired

settings.

2) R-Y GAIN : Adjusts the red gain level. (000 ~ 255)

3) B-Y GAIN : Adjusts the blue gain level. (000~255)

*DAY / NIGHT*

1) DAY/NIGHT MODE

AUTO: Automatically determines the D/N switching points.

- DAY/NIGHT : Adjusts the switching point level

- NIGHT>DAY : Adjusts the switching point level.

- DELAY TIME : Adjusts the calculation time for the trigger.

COLOR : Color mode.

B/W : B/W mode.

EXT : This mode allows you to apply a desired filter to external

signals.

2) BURST : Selects the BURST Mode (OFF / ON)

3) C-SUP : Controls color noise suppression at night time. (000~100).

4) A-SUP : Controls aperture level suppression at night time.

(000~100).

5) SMART IR : Produces the best image quality by preventing IR

saturation when IR LEDs are on. (AUTO (000~040) / OFF)

*IMAGE ADJUST*

1) MIRROR : Flips the image along the y-axis.

2) SHARPNESS : Sets the amount of sharpness applied on the image.

3) GAMMA : Sets the desired Gamma value. (0.45/55/65/USER)

4) LSC : Sets the Lens Shading Compensation value. (000~030)

5) MONITOR : Sets the video output to three main input types.

(CRT/LCD)

OSD MENU DETAILS

*MOTION*

1)MOTION : Adjust motion detection settings.

2)AREA : Selects the current motion zone from area1 to 4

3)SENSITIVITY : Sets the desired multiple of the digital exposure length.

(000~030)

4)DISPLAY : Sets the desired display mode when the motion is detected.

(OFF/MESSAGE/TRACE)

5)HOLD TIME : Sets the hold time when the event is detected.(000~015)

6)ALARM OUTPUT : Selects the alarm output mode. (ON/OFF)

*PRIVACY

1)MASK 1~8 : Selects the current mask number

2)DOT SEL : Sets the size of Left-Bottom/Right-Bottom/Left-Top/Right-

Top.

3)DOT XY : Sets the coordinate of Horizontal / Vertical Axis for PM

position.

4)MOVE XY : Moves the mask horizontally and vertically.

5)COLOR : Selects the desired mask color. Black, White, Red, Green,

Blue, Magenta, Cyan, Gray colors are available.

*SPECIAL*

1) LANGUAGE : Sets the desired OSD language.

(ENGLISH, SPANISH, PORTUGUESE, POLISH,

GERMAN, ITALIAN, NETHERLANDIC, KOREAN, CHINESE ).

2) TITLE : Determine the camera name. (ON/OFF)

3) COMMUNICATION : Used to configure the RS-485 port.

*Requires the RS-485 option.

ID : Sets the ID for the RS-485 (0~255).

BAUD RATE : Sets the baud rate for the RS-485 (2400~9600).

PROTOCOL : Pelco-D

4) DPC : Automatically detect and correct the defective pixels in a

camera image sensor array.

AUTO : Adjust white THR and Luma THR level.

White THR (000~255) / LUMA THR (000~255)

5) FACTORY SET : Resets all settings to it’s factory defaults.

OSD MENU DETAILS

*EXIT*

SAVE & EXIT : Press to save the current settings and exit main menu.

EXIT : Press to exit main menu without saving settings.
