Spectra Precision DET-2 Manuale utente
12/07/18 2
DET-2 Construction Theodolite
DET-2 stands for Digital Electronic
Theodolite, 2 Second
2 Arc Seconds is its angular
accuracy
Contractors ay also refer to this
instru ent as a Digital Transit, or
Transit
Generally used to ake sure things
are installed perfectly straight, or at
right angles to each other
12/07/18 3
Construction Positioning
The DET-2 replaces conventional
ethods like string and batter-boards
Allows control of align ent and position
Target Trades:
General Contractors
Concrete Contractors
Residential Contractors
Underground/Utilities Contractors
12/07/18 4
DET-2 Construction Theodolite
Highly Featured, Econo y Priced
1” or 5” selectable display
2” accuracy
Vertical Co pensation
Dual backlit displays and controls, large LCD
characters
Easy to use One-Touch buttons
Co pletely configurable via user software
Illu inated telescope
Recharge and backup alkaline packs included
12/07/18 5
Theodolite
Applications
12/07/18 6
Alignment
The DET-2 can be used
to align for s, footers
and anchor bolts
12/07/18 7
Turning 90’s
The DET-2 can be used
to turn 90’s and check
angles
12/07/18 8
Checking Plumb / Tilt Up alls
A theodolite can be set up on a
parallel offset to the line for
checking plu b
A steel scale can be used to
check a consistent offset
Tilt-up walls can be done using a
theodolite that’s set up on the
line of the wall and by checking
botto and top positions
12/07/18 9
Gravity Flow Pipe / Utility ork
The DET-2 can be used
for Dialgrade / Pipe Laser
setups, including anhole
and pipe elevations, layout
and line setting
The unit co pli ents a
Dialgrade sale
12/07/18 10
Basic Grade ork
Can be used for short
range grade work at very
steep angles
Only along the line of sight
Can be used for a run of
grade stakes
