Spypoint LINK-MICRO-LTE Manuale utente

v.1.8

LINK-MICRO-LTE AND

COMPARABLE*

QUICK START GUIDE

ENGLISH

IN THE BOX

1x LINK-MICRO-LTE camera

1x SIM card (preactivated and inserted in the camera)

1x Antenna holder

1x Installation strap

1x Quick Start Guide

NOTE

Memory card and batteries are sold separately.

User Manual, latest ﬁrmware, and FAQ available at:

www.spypoint.com/support.

COMPONENTS

qAntenna

wDetection lens

eMicroSD card slot

rLight sensor

tDelay light

yPhoto lens

uLED

iOFF/ON switch

oSTATUS light

aSIM card slot

sBattery compartment

dBattery holder

fSlot for installation strap

gDoor

hLocking latch

jCable lock hole

k12 V jack

lScrew-thread for standard

¼"-20 tripod mount

ENGLISH

d

ENGLISH

GETTING STARTED

CHOOSING A POWER SOURCE (3 OPTIONS)

• Alkaline or lithium AA batteries

• Rechargeable battery 12 V (#KIT-12V sold separately)

• Rechargeable battery pack 3,7 V (#LIT-10 sold separately)

NOTE

We recommend using the SPYPOINT #LIT-10

rechargeable lithium battery pack, sold separately.

FOR BEST RESULTS AND NO LEAKAGE

• Use only new alkaline or lithium batteries.

• Do not mix new and old batteries.

• Do not use rechargeable AA batteries

(their lower voltage can generate operational issues).

HOW TO INSTALL AA BATTERIES PROPERLY

• Unlock the latch and open the

LINK-MICRO-LTE door.

• Remove the battery compartment by

grasping it by the 2 small notches on

the side and pulling it out (see photo).

• Insert the AA batteries into the battery

holder following polarity (+) and (-)

indications.

• Place the battery holder back into the

battery compartment.

ENGLISH

INSTALLING A MICROSD CARD

The memory card is sold separately. You must ﬁrst purchase

a class 10 microSD card between 2 GB and 32 GB of memory.

Before inserting the microSD card into your camera, it must be

formatted to ensure proper operations. Visit www.spypoint.com/

support if you need help to format your microSD card.

INSERTING YOUR MICROSD CARD

• Make sure the camera is turned OFF.

• Find the microSD card slot. It is located on

the left, above the battery compartment

(see photo).

• Insert a microSD card (up to 32 GB) in the

microSD card slot with the metal contacts

facing down.

• The card is inserted correctly when a click

is heard.

CLEAR THE ANTENNA

The camera comes with an antenna

mount that holds and protects the

antenna during shipping. You have

to remove it. This will allow you to move

and point your antenna in the desired

direction. Save and reuse the mount

to protect your antenna during future trips.

ENGLISH

ACTIVATE YOUR CAMERA

Before you can use your camera, you have to activate

it. To do so, you will need your activation code.

FINDING THE ACTIVATION CODE

The activation code is located inside the LINK-MICRO-LTE's

battery compartment.

To activate your camera, you have two choices: you can

either do it via the SPYPOINT app or via our website

www.spypoint.com.

Activation code



ENGLISH

SPYPOINT APP

If you choose to use the SPYPOINT app to activate

your device, follow these steps:

1. On Google PlayTM or the App StoreTM, search for “SPYPOINT”.

2. Download and install the app on your smartphone or tablet.

3. Start the app. Select “ACTIVATE A DEVICE”. In the list, select

“LINK-MICRO-LTE”then follow the steps to create an account.

4. When complete, a conﬁrmation email with instructions on how

to ﬁnalize the creation of your account will be sent to you.

5. Log in to the SPYPOINT app using your email address

and password.

SPYPOINT.COM WEBSITE

If you choose to use our SPYPOINT website

to activate your device, follow these steps:

1. On the www.spypoint.com website, select “LOGIN” in the

top navigation menu. On the displayed “SPYPOINT” page,

select “REGISTER”, ﬁll out the required ﬁelds, then log in.

2. Select the +sign on the far right of the page; in the list,

select “LINK-MICRO-LTE” then follow the steps.

3. When complete, a conﬁrmation email with instructions on how

to ﬁnalize the creation of your account will be sent to you.

4. On the SPYPOINT website, log in to your account using your

email address and password.

ENGLISH

CHOOSING A PHOTO TRANSMISSION PLAN FOR YOUR CAMERA

Go to www.spypoint.com/en/spypoint-experience/plans

to read the latest oers and choose the plan that suits you.

CONFIGURING YOUR CAMERA

Both the SPYPOINT app and website let you congure all the

camera settings remotely. They also provide basic information

on your camera – such as: cellular signal strength, battery level,

and microSD card space used. This information is based upon

the latest connection with your camera.

New settings take eect every time the camera connects with

app or website.

Note that for 15 minutes after the camera is turned ON, it will

communicate with the server every time it takes a photo and will

also apply the settings you have chosen. Afterwards, it will com-

municate according to the default settings (transfer frequency/

rst transfer time) or those you chose to apply. Below are the

most basic settings you will congure.

CONFIGURATION: MAIN SETTINGS

Delay: Allows you to set the time interval between each detection

before the camera records the next photo or video.

Multi-shot: Allows you to set the number of photos per detection

(up to 2) with a 5-second delay between each photo.

Sensitivity: Allows you to set the detection sensitivity of the

camera.

Camera name: Allows you to name each owned camera.

ENGLISH

CELLULAR SETUP

First transfer time:Allows you to choose the time when the

camera makes its rst transfer of the day.

Transfer frequency:Allows you to choose the number of daily

transfers.

ADVANCED OPTIONS/CONFIGURATION

Schedule:Allows you to set the period of operation for each day

of the week. For a 24-hour operation mode, both the start and

stop times must be 12 AM.

NOTE

Camera transfers are set by default to 4-hour intervals determined

from the time you activated your camera. For example, if your

camera was activated at 1:42p.m., the next transfer will take

place at 5:42p.m.

STARTING YOUR CAMERA

1. Turn ON the camera.

2. The green STATUS light will ash while searching for a signal

(can take a few minutes).

3. The STATUS light will light up in one of the following 3 colors:

Red: Insucient signal

Orange: Acceptable signal

Green: Optimal signal

4. When the top right light ashes red, 30 seconds remain

before the photo mode is turned ON. This allows you to leave

the area without being photographed.

ENGLISH

5. The camera is ready for use when all the lights turn OFF.

6. If the light is red during step 3, you should:

• Turn your camera OFF and then back ON.

• Retry while pointing the antenna at diﬀerent angles.

• Try moving it to a spot with better signal.

• Try our #CA-01 long range cellular antenna (sold separately),

which could help improve signal strength.

INSTALLING YOUR CAMERA

1. Mount the camera using the installation strap.

2. The camera should be at the same height as the animal’s

mid-body.

3. The targeted animal should be at 25 feet (7.5 meters) away

from the camera.

4. To produce brighter photos at night, there sould be items

reﬂecting the camera's ﬂash in the background.
