Squier Affinity Strat (Maple) Manuale

Squier Affinity Stratocaster

Affinity Strats come from 3 different sources:

Affinity Series-Reliant. Serial numbers begin with “CY”

“Start Playing” Special-Cort. Serial numbers begin with “IC”

Start Playing SE Series- AXL. Serial numbers begin with “CAX”

Cort models “IC” serial numbers

Maple- m/n 0310602xxx

Rosewood- m/n 0310600xxx

Loc # Description Part Number

1 Standard Tuners (set of 6) 007-3867-000

2 Bone Nut (blank) (2) 099-4920-000

3 Vintage String Guides (pack of 2) 099-4910-000

4 Strap Buttons (2) 099-4915-000

5 Pickguard Assembly (w/ pickups/pots, etc.) 007-7507-000

9 500K Split Shaft Pot (Volume) 006-2382-000

10-11 500K Split Shaft Pot (Tone) 006-2383-000

9-11a Volume/Tone Knobs (set of 3) 005-5425-000

12 5 Way Pickup Selector Switch 005-5412-000

12a Switch Tip (2) (white) 099-4940-000

13 Output Jack 007-2892-000

17 Jack Plate (chrome) 007-2893-000

18 Bridge Assembly 005-5409-000

18a Tremolo Arm 004-1359-000

AXL models “CAX” serial numbers

Maple- m/n 0301600xxx

Loc # Description Part Number

1 Standard Tuners (set of 6) 007-7456-049

2 Bone Nut (blank) (2) 099-4920-000

3 Vintage String Guides (pack of 2) 099-4910-000

4 Strap Buttons (2) 099-4915-000

5 Pickguard Assembly (w/ PU & Pots) 007-7457-000

6 Knobs (set of 3) 007-7458-000

7 Bridge Assembly 007-7459-000

8 Tremolo Arm 007-7460-000

Last Revision Date: 9/8/2008

Page 1 of 4

Reliant models “CY” serial numbers

Maple- m/n 0310602xxx

Rosewood- m/n 0310600xxx

Loc # Description Part Number

1 Standard Tuners (set of 6) 005-5404-000

2 Bone Nut (blank) (2) 099-4920-000

3 Vintage String Guides (pack of 2) 099-4910-000

4 Strap Buttons (2) 099-4915-000

5 Pickguard (white) 005-5433-000

5a Pickguard Screws (24) 099-4923-000

6 Affinity Pickups (set of 3) 005-5428-000

7-9 500K Split Shaft Pot (Set of 3) 005-5440-000

7-9a Volume/Tone Knob Set (white) 005-5442-000

10 5 Way Pickup Selector Switch 007-7490-000

12a Switch Tip (2) (white) 099-4940-000

13 Output Jack/Jack Plate 005-5449-000

14 Bridge Assembly 007-7433-000

14b Tremolo Arm (RH) 006-9969-000

Last Revision Date: 9/8/2008

Page 2 of 4

Wiring Diagram

Last Revision Date: 9/8/2008

Page 3 of 4

Control Function

Last Revision Date: 9/8/2008

Page 4 of 4
