StarTech.com USB2VGA Manuale utente

USB to VGA

USB2VGA Instruction Manual

USB 2.0 to VGA Dual Display Adapter

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Configuring the USB 2.0 to VGA Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

USB-VGA (Primary) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

USB-VGA (Extended) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

USB-VGA (off) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

USB 2.0 to VGA Adapter Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a USB 2.0 to VGA adapter. This adapter allows you to

connect any CRT monitor, LCD monitor, or projector to your PC or notebook,

making it the perfect solution for extending your desktop, or adding an extra

display.

FFeeaattuurreess

• Supports resolutions up to 1280 x 1024

• Lightweight, portable design

• Simple, plug and play installation

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• Windows 2000/XP operating system

• An available USB 2.0 port

• Two VGA compatible monitors/displays

Contents

This package should contain:

• USB 2.0 to VGA adapter (1)

• Drivers CD (1)

• User manual

Instruction Manual

IInnssttaallllaattiioonn

Note: Please ensure that driver installation is complete prior to the physical

installation of the USB 2.0 to VGA adapter.

1. Insert the drivers CD into your CD/DVD-ROM drive.

2. If the installation program does not begin automatically, locate the Setup.exe

application. This file will be located in the root directory of the Drivers CD.

3. Executing the Setup.exe application will launch the following screen:

4. Click on Next to advance to the following screen. Once you have read the listed text,

click on Next.

Instruction Manual

Illustration 1-1

Illustration 1-2

5. Once the drivers installation is complete, you will reach the following screen. Select

Yes, I want to restart my computer now, and click on Finish.

6. Once your computer has completely restarted, you should notice the USB 2.0 to VGA

utility in the system tray as illustrated below. Software installation is now complete.

7. Plug the power cord from the secondary monitor into a nearby power socket. Turn on

the secondary monitor.

8. Connect the VGA cord running from the secondary monitor to the adapter.

8. Plug the USB connection from the adapter into an available USB 2.0 port.

6. The secondary monitor should now be ready to use.

Instruction Manual

To access the menu,

right-click on the

application icon:

Illustration 1-3

Illustration 1-4

CCoonnffiigguurriinnggtthheeUUSSBB22..00ttooVVGGAAAAddaapptteerr

Once the driver and adapter have been installed, an icon will appear in the system tray

as shown in Illustration 1-4. This utility allows you to quickly change the settings and

resolution for your USB 2.0 VGA Adapter.

USB-VGA

Instruction Manual

Selecting USB-VGA (Primary), will set

the secondary display adapter as the

main display adapter in the system. The

system’s primary adapter (and monitor)

will automatically switch to act as the

extended desktop.

Please Note: Some display utilities and

drivers that ship with AGP and built-in

display adapters will prevent this option

from working on some systems. For the

USB-VGA (Primary) setting to take

effect, you must first disable the original

display utility (typically located in the

system tray).

USB-VGA (Extended)

This setting will extend your

desktop from your original

monitor onto the secondary

desktop.

Illustration 1-5

Illustration 1-6

Mirror

This setting will mirror the

image from your original

desktop onto the secondary

desktop.

Illustration 1-7

UUSSBB22..00ttooVVGGAAAAddaapptteerrPPrrooppeerrttiieess

1. To access the Display Properties for the USB 2.0 VGA Adapter, open the Control

Panel, and double-click on the Display icon.

2. Select the Settings tab.

3. Click on the Display drop-down menu, and select the USB 2.0 VGA DEVICE

(DISPLAY) as illustrated below:

4. From here, you can change the resolution and color depth as desired. Once the

desired changes have been made, click on OK to apply the settings.

Virtually Repositioning your displays

On the settings tab of your Display Properties, click and drag the appropriate monitor

icon (labelled 1 or 2) to the desired position. For example, the secondary display can be

dragged to the left of the primary display, allowing it to be positioned virtually on the left.

Click OK or Apply to save the changes.

Instruction Manual

USB-VGA (Off)

This option disables the USB 2.0 VGA Adapter on the

system, leaving the original display.

Illustration 1-8

Illustration 1-9

Troubleshooting

The USB 2.0 to VGA Adapter can’t be set as the primary display

Some video card manufacturers ship their product with a utility that prevents other video

cards from being set as the primary card. Please check the system tray for an icon

representing this utility, and if possible, please disable the utility prior to switching to the

USB 2.0 to VGA adapter as the primary display.

My DVD player will not work when I move the image to the extended display

Some DVD playback software does not support playing video on a second adapter of any

kind. Please refer to the documentation that was included with your DVD playback

software for further information.

Video will not display using Windows Media Player on the extended desktop

Please ensure that you have moved the Media Player window completely over to the

second screen.

The mouse pointer will not move past the right side of the primary screen

Check the display settings and make sure that Display #2 is on the right side of Display

#1. You can rearrange how Windows treats each display in relation to each other in the

Display Properties Settings.

There are horizontal lines covering the displayed image

This is due to a low refresh rate setting. You can change this in: Display Properties,

Settings, Advanced, Monitor. Make sure that you have selected the USB 2.0 VGA

Device first, and do not exceed the refresh rate limitations of the monitor. Resetting, or

resynchronizing the monitor may also help. For further details on how to reset or

resynchronize your monitor, please refer to the documentation that was included with

your monitor purchase.

I am unable to use applications that require Direct3D on the USB 2.0 VGA adapter

Currently, the drivers that support the USB 2.0 VGA adapter do not support Direct3D.

Please check for driver updates in the future, for added support. If your application

requires Direct3D, please use the main display adapter.

Instruction Manual

SSppeecciiffiiccaattiioonnss

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Operating systems supported Windows 2000/XP

Chipset PLX Netchip Net2280

Certifications (Regulatory and other) FCC, CE, ROHS

Bus Type USB

Connectors USB Type ‘A’ x 1

HD15 Female x 1

Maximum Data Transfer Rate 480 Mbits/sec

Support Resolution:

1280 x 1024

1280 x 768

1152 x 864

1024 x 768

800 x 600

640 x 480

Color Quality (bits)

8, 16

8, 16, 32

Indice

Altri manuali StarTech.com Adattatore

StarTech.com

StarTech.com USB2VGAE Manuale utente

StarTech.com

StarTech.com DKT31CHVL Manuale utente

StarTech.com

StarTech.com USB External Sound Card Adapter Manuale utente

StarTech.com

StarTech.com DP2VGDVHD Manuale utente

StarTech.com

StarTech.com USB2105S Manuale utente

StarTech.com

StarTech.com ICUSB232IS Manuale utente

StarTech.com

StarTech.com USB32VGAPRO Manuale utente

StarTech.com

StarTech.com 1P3FP-USB-SERIAL Manuale utente

StarTech.com

StarTech.com DKT30CHPDW Manuale utente

StarTech.com

StarTech.com 2CF2SATAR Manuale utente

StarTech.com

StarTech.com USB2DVI Manuale utente

StarTech.com

StarTech.com DKT30CHVAUSP Manuale utente

StarTech.com

StarTech.com CDP2HD4K60SA Manuale utente

StarTech.com

StarTech.com ICUSB232HUB2 Manuale utente

StarTech.com

StarTech.com ICUSB422IS Manuale utente

StarTech.com

StarTech.com WIF2HDMC Manuale utente

StarTech.com

StarTech.com USB2VGAPRO2 Manuale utente

StarTech.com

StarTech.com USB32HDVGA Manuale utente

StarTech.com

StarTech.com PCI100MMSC Manuale utente

StarTech.com

StarTech.com USB3SSATAIDE Manuale utente

StarTech.com

StarTech.com USBAUDIO5CH Manuale utente

StarTech.com

StarTech.com 35S24M2NGFF Manuale utente

StarTech.com

StarTech.com SSPMSVESA Manuale utente

StarTech.com

StarTech.com PCIe Ver 3.0 x2 Manuale utente

Manuali Adattatore popolari di altre marche

PCB Piezotronics

PCB Piezotronics 090B274 Manuale utente

Auvidea

Auvidea J20 Manuale del prodotto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuale utente

Akribis

Akribis ITF-21-BISS-MIT Manuale utente

Tenda

Tenda W54U Manuale utente

ROHO

ROHO AGILITY Manuale utente

PROLiNK

PROLiNK WN2001 Manuale utente

Hawking

Hawking HUF2 Manuale utente

Airlink101

Airlink101 AWLC4030 Manuale utente

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuale utente

Philips

Philips SWA4554S/10 Manuale utente

JVC

JVC TS-C9D2B Manuale di istruzioni

NETGEAR

NETGEAR A6100 Manuale utente

D-Link

D-Link DWA-121 Manuale utente

Philips

Philips SWA2037 Manuale utente

Basalte

Basalte 0610-20 Manuale utente

Yealink

Yealink EHS40 Manuale utente

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuale utente
