StarTech.com EC13941A1B Manuale utente

EC13941A1B

FireWire IEEE1394

ExpressCard

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction .................................................................... 1

Features ..................................................................................1

Package Contents ...................................................................1

System Requirements .............................................................1

Installation....................................................................... 2

Troubleshooting.........................................................................2

Speciﬁcations.................................................................. 3

Technical Support........................................................... 4

Warranty Information ...................................................... 4

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com FireWire IEEE 1394 Express

Card. This card adds external Firewire 800 (1394b) and Firewire 400

(1394a) connectivity to notebook computers to support various types of

IEEE1394 (Firewire) devices including DV camcorders, hard disk drives,

PC Video cameras, removable drives, CD-RWs, DVD-ROMs and other

1394 audio/video devices.

Features

Compliant with IEEE 1394b and backwards compatible with IEEE•

1394a - 2000 as well as 1394-1995 standards

Full single lane PCI Express (x1)•

Hot swap capabilities allows you to connect or disconnect devices•

without turning off your laptop

Maximum data transfer rate of 800 Mbps•

Supports PCI Express Base Speciﬁcation Revision 1.1•

Package Contents

1 x Adapter Cable•

1 x FireWire ExpressCard•

1 x Instruction Manual•

1 x ULead Software CD•

System Requirements

Pentium IV or equivalent processor•

An available ExpressCard slot•

Windows® 2000/XP/Server 2003/Vista™, MAC OSX 10.x or higher•

Instruction Manual

Installation

1. Insert the FireWire IEEE 1394 Express Card into an open Express

Card slot in the notebook.

2. The Found New Hardware Wizard will automatically detect and install

drivers for the FireWire IEEE 1394 Express Card. Once the wizard has

completed the installation of the drivers, the device is ready for use.

Troubleshooting

To verify that the FireWire IEEE 1394 Express Card was installed

correctly, open the Device Manager by navigating to: My Computer->

Control Panel->System->Device Manager. The EC13941A1B will appear

under IEEE 1394 Bus Host Controller.

If the EC13941A1B is not functioning, ensure that none of the ports

on the device are conﬂicting with any ports present elsewhere on the

computer. Also, check to ensure that the physical connection between the

PCI-E port and the EC13941A1B is snug and secure.

Instruction Manual

Specications

Bus Type ExpressCard (34mm)

Number of Ports 2 IEEE FireWire Ports (1x 1394A and 1x

1394B)

OS Support Windows XP/2000/2003/Vista™ (32 & 64-bit)

MAC OSX 10.x and up

Maximum Data

Transfer

1394A - up to 400 M Bps

1394B - up to 800 MBps

Chipset LSI L-FW643

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-

ment to provide industry-leading solutions. If you ever need help with your

product, visit www.startech.com/support and access our comprehensive

selection of online tools, documentation, and downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materi-

als and workmanship for the periods noted, following the initial date of

purchase. During this period, the products may be returned for repair,

or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its

products from defects or damages arising from misuse, abuse, alteration,

or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA

LLP (or their ofﬁcers, directors, employees or agents) for any damages

(whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of proﬁts, loss of business, or any pecuniary loss, arising

out of or related to the use of the product exceed the actual price paid

for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or

exclusions contained in this statement may not apply to you.
