StarTech.com ECUSB3S1 Manuale utente

ExpressCard USB 3.0 Adapter

1-Port ExpressCard to

SuperSpeed USB 3.0

Adapter Card - Flush Mount

ECUSB3S1

Instruction Manual

Manual Revision:11/30/2010

For the most up-to-date information, please visit www.startech.com

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes

only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Table of Contents

Introduction.............................................................................................. 1

Packaging Contents.................................................................................................. 1

System Requirements .............................................................................................. 1

Installation................................................................................................ 2

Hardware Installation................................................................................................ 2

Driver Installation...................................................................................................... 2

Speciﬁcations........................................................................................... 3

Technical Support.................................................................................... 4

Warranty Information............................................................................... 4

Introduction

The ECUSB3S1 Flush Mount 1-Port USB 3.0 ExpressCard Adapter uses a unique form

factor design that allows it to sit fully in a standard 34mm laptop ExpressCard slot without

sticking out; the port sits ﬂush with the sides of the laptop, creating a seamless addon

that can be left installed, even while on the move, without fear that it will get snagged or

hit against which could cause damage to the card or slot.

The USB 3.0 ExpressCard supports data transfer rates up to 5Gbps, and is still

backward compatible with USB 2.0 devices at up to 480Mbps, or USB 1.1/1.0 at up to

12/1.5 Mbps respectively.

Packaging Contents

• 1 x ExpressCard Adapter

• 1 x USB to DC Adapter Cable

• 1 x 34mm to 54mm Stabilizer Bracket

• 1 x Driver CD

• 1 x Instruction Manual

System Requirements

• ExpressCard/34 (34mm) enabled computer system

• Microsoft®Windows®2000/XP/Vista/Server 2003/Server 2008 R2/7 (32/64-bit)

Installation

Hardware Installation

ExpressCard adapters can be hot-plugged into a computer system, while running.

Turning the computer off to insert/remove ExpressCard adapters should not be

necessary.

The ExpressCard adapter will simply slide into the ExpressCard slot on any compatible

system, label side up. Push the card all the way in, until it ‘clicks’ and locks into place. To

eject the card, simply push the card further into the slot until it clicks, and then release

and it will then be automatically ejected from the slot.

OPTIONAL: For some high-powered USB 3.0 devices, additional power may be required.

Connect the USB to DC adapter cable from a USB port on the computer system to the

DC plug on the card. This will provide additional power to the USB 3.0 port.

Driver Installation

Windows 2000/XP/Server 2003

1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,

cancel/close the window and insert the included Driver CD into the computer’s CD/

DVD drive.

2. AutoPlay should automatically launch and display all of the folders on the CD. If not,

open “My Computer” and double-click on the CD/DVD drive.

3. Enter the folder “USB 3.0 Host”, then “NEC” and double-click the ﬁle “Setup.exe”.

4. This should launch the driver Installation wizard. Continue through the wizard and

once complete, all the necessary drivers will be installed.

Windows Vista/7/Server 2008 R2

1. Upon starting Windows, if the “Found New Hardware” wizard appears on the screen,

cancel/close the window or choose not to install the drivers and insert the included

Driver CD into the computer’s CD/DVD drive.

2. AutoPlay should automatically launch and display all of the folders on the CD. If not,

open “Computer” and double-click on the CD/DVD.

3. Enter the folder “USB 3.0 Host”, then “NEC” and double-click the ﬁle “Setup.exe”.

4. This should launch the driver Installation wizard. Continue through the wizard and

once complete, all the necessary drivers will be installed.

Specications

Bus Interface

ExpressCard 2.0

USB 3.0 base speciﬁcation 1.0

Intel xHCI speciﬁcation 0.95

Form Factor “Slim” ExpressCard/34 (34mm)

Chipset ID NEC uPD720200

Connectors 1 x USB type A female

1 x DC Power female (type A)

LEDs None

Maximum Data Transfer Rate USB 3.0: 5 Gbps*

Power Adapter None

Operating Temperature 5°C ~ 50°C (41°F ~ 122°F)

Storage Temperature -25°C ~ 70°C (-13°F ~ 158°F)

Humidity 15% ~ 90% RH

Dimensions (LxWxH) 75.0mm x 34.0mm x 5.0mm

Weight 20g

Compatible Operating Systems Windows 2000/XP/Server 2003/Vista/

Server 2008 R2/7 (32/64-bit)

* If used with ExpressCard 1.0 enabled computer systems, the max throughput is

limited to 2.5 Gbps. If used with ExpressCard 2.0 enabled computer systems, the max

throughput is 5 Gbps.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.

com/support and access our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in materials and

workmanship for the periods noted, following the initial date of purchase. During this

period, the products may be returned for repair, or replacement with equivalent products

at our discretion. The warranty covers parts and labor costs only. StarTech.com does not

warrant its products from defects or damages arising from misuse, abuse, alteration, or

normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ofﬁcers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of proﬁts, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the actual

price paid for the product. Some states do not allow the exclusion or limitation of incidental

or consequential damages. If such laws apply, the limitations or exclusions contained in

this statement may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy”

since 1985, providing high quality solutions to a diverse

IT and A/V customer base that spans many channels,

including government, education and industrial facilities

to name just a few. We offer an unmatched selection of

computer parts, cables, A/V products, KVM and Server

Management solutions, serving a worldwide market

through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com today for complete information

about all our products and to access exclusive interactive

tools such as the Cable Finder, Parts Finder and the

KVM Reference Guide.
