Manual Revision: 03/26/2013

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IREXT2

Wireless Infrared IR Remote Extender - 330 ft (100m)

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements .............................................................................................................................. 1

Installation ..............................................................................................1

Working without extender probe ....................................................................................................... 1

Working with extender probe .............................................................................................................. 2

Specications ..........................................................................................3

Technical Support ..................................................................................4

Warranty Information ............................................................................4

Instruction Manual

Introduction

Packaging Contents

• 1 x IR Extender transmitter

• 1 x IR Extender receiver

• 1 x IR extender probe

• 2 x 12VDC, 250mA power adapters

System Requirements

• Available power outlets near transmitter and receiver locations

• IR controlled device with remote

Installation

1. Connect one of the provided AC power adapters to an available power outlet,

then to the DC jack on the back of the IREXT2 receiver unit.

2. Situate the unit labeled “Receiver”, near the device you wish to control remotely

(Television, Home Theater Receiver etc.). If you are not using the probes outlined

in the following step, position the IR receiver unit to face the IR sensor receiving

window of the device you are controlling. Note the distances outlined in the

diagram for best performance.

Working without extender probe

Instruction Manual

4. If using the included probe(s) situate the IR Extender Probe near the IR sensor

receiving window of the device you wish to control. The probe should be within

0.5m and at angles +/- 15°.

Working with extender probe

5. Insert the metal connector provided by the probe, into the IR Extender port

located on the back of the Receiver unit.

6. Extend the antenna on the receiver unit and position it vertically.

7. Situate the unit labeled “Transmitter”, near the location from which you wish

to initiate control, ensuring that an available power outlet is easily accessible.

8. Connect the remaining AC power adapter to an available power outlet, then

to the DC jack on the back of the IREXT2 transmitter unit.

9. Extend the antenna on the transmitter unit and position it vertically.

10. The Infrared Extender is now ready for use.

Instruction Manual

Specications

Color Gray

Enclosure Type Plastic

Transmission Frequency 433.92 MHz +/-1 MHz

IR Frequency 30kHz - 60kHz

Power Gain 10 dBM

Maximum Transfer Distance 100 m / 330 ft

Power Adapter 12V DC, 250 mA

Dimensions (L x W x H) 93 x 65 x 32 mm

Weight 267 g

Operating Temperature 0°C to 43°C (32°F to 109°F)

Storage Temperature -20°C to 60°C (-4°F to 140°F)

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
