ST121HDT4P

HDMI® over Single Cat 5e/6 Extender w/

Power over Cable, Ethernet, IR - 1080p

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements .............................................................................................................................. 1

Front View – Transmitter/Receiver Unit ............................................................................................. 2

Rear View – Transmitter/Receiver Unit .............................................................................................. 2

Installation ..............................................................................................3

Preparing Your Site ................................................................................................................................... 3

Hardware Installation .............................................................................................................................. 3

Specications ..........................................................................................5

Technical Support ..................................................................................6

Warranty Information ............................................................................6

Instruction Manual

Introduction

The ST121HDT4P HDMI® over CAT5e/6 Video Extender kit lets you extend HDMI® video

and audio up to 330 feet (100 Meters) over a single Cat5e cable. For added benet

both the Transmitter and Receiver are powered by the same power source, connected

to the Transmitter and sent to the Receiver using Power Over Cable (POC).

This versatile HDMI® extender also allows you to extend Infrared for an IR Remote

Control, and 2 Ethernet LAN connections over the same Cat5e/6 cable.

With support for resolutions of up to 1920x1080 and the accompanying digital audio,

this cost-eective HDMI® extender is a plug-and-play solution that can easily be

installed using new or existing Ethernet infrastructure wiring.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Packaging Contents

• 1x HDMI® Extender Transmitter Unit

• 1x HDMI® Extender Receiver Unit

• 1x Universal Power Adapter (NA/UK/EU)

• 1x Instruction Manual

• 2x IR Extender Cables

System Requirements

• HDMI® enabled video source device (i.e. computer, Blu-ray Player)

• HDMI® enabled display device (i.e. television, projector)

• Available AC electrical outlet for either the transmitter or receiver

• HDMI® cables for receiver and transmitter

Instruction Manual

Front View – Transmitter/Receiver Unit

Transmitter Unit

Receiver Unit

Rear View – Transmitter/Receiver Unit

1. HDCP LED

2. Link LED

3. Mode LED

4. Power LED

5. IR-RX Port

6. IR-TX Port

1. HDCP LED

2. Link LED

3. Mode LED

4. Power LED

5. IR-RX Port

6. IR-TX Port

1. Power jack

2. Cat5e/6 Out (RJ-45 Connector)

3. HDMI IN Port

4. 100Base-T IN Port 1

5. 100Base-T IN Port 2

1. Cat5e/6 IN (RJ-45 Connector)

2. HDMI OUT Port

3. 100Base-T Out Port 1

4. 100Base-T Out Port 2

1 2

1 2 13 24 35 4

Instruction Manual

Installation

Preparing Your Site

1. Determine where the local video source (i.e. computer, Blu-ray Player) will be

located and set up the device.

2. Determine where the remote display will be located and place/ mount the

display appropriately.

NOTE: This HDMI® extender kit features Power over cable, allowing both the

transmitter and Receiver to be powered from a single power source that connects

to the transmitter unit. Please ensure that the Transmitter Unit is situated near an

available AC electrical outlet. Make sure all devices are turned o before

beginning installation.

Hardware Installation

1. Install Transmitter Unit

a) Position the Transmitter Unit near the video source (i.e. Computer, Blu-ray Player).

b) Connect an HDMI® cable from the video source device (i.e. computer, Blu-ray

Player) to the “HDMI® IN” on the Transmitter Unit.

c) Connect the power supply.

d) (Optional) If using the Extender to extend one or two 10/100 Network signal(s),

connect the Ethernet cable(s) from the Network gateway to the 100Base-T IN Port(s)

on the Transmitter Unit.

e) (Optional) If using the Extender kit to transmit an infrared (IR) device signal, and

the device receiving the IR signal is on the Receiver side. Connect the IR Transmitter

Cable to the IR-RX port on the Transmitter Unit, and position the extended IR sensor

directly in front of the video source’s IR sensor. Check the manual of your video

source device for the IR sensor location. If the device receiving the IR signal is on

the Transmitter side, and connect the IR Transmitter Cable to the IR-TX port, and

position the IR sensor where the remote control will point.

Instruction Manual

2. Install RJ45 terminated Cat5e/6 Ethernet Cable

a) Connect an RJ45 terminated Cat5e/6 Ethernet cable (not included) to the RJ45

connector on the Transmitter unit.

NOTE:

If you are using surface cabling, ensure you have enough Category 5e unshielded

twisted pair (UTP) network cabling to connect the Host Unit to the Remote Unit’s

location, and that each end is terminated with a RJ45 connector. The cabling should

not go through any networking equipment (i.e. router, switch).

If you are using premises cabling, ensure that the Category 5 unshielded twisted

pair (UTP) network cabling between the Host Unit and the Remote Unit has been

properly terminated in a wall outlet in each location and there is a patch cable long

enough to connect the Remote Unit and the Host Unit to their respective outlets.

The cabling should not go through any networking equipment (i.e. router, switch).

b) Connect the other end of the Cat5e/6 cable run to the RJ45 connector on the

Receiver Unit.

3. Install Receiver Unit

a) Position the Receiver Unit near the video display (i.e. television, projector).

b) Connect the video source to the HDMI® OUT on the Receiver Unit using an HDMI®

cable.

c) (Optional) If using the Extender to extend one or two 10/100 Network signal(s),

connect the Ethernet cable(s) from the 100Base-T OUT Port(s) on the Receiver Unit

to RJ-45 port on your network device(s).

d) (Optional) If using the Extender kit to transmit an infrared (IR) device signal,

and the device receiving the IR signal is on the Transmitter side. Connect the IR

Transmitter Cable to the IR-TX port on the Receiver Unit, and position the IR sensor

where the remote control will point. If the device receiving the IR signal is on

the Transmitter side, and connect the IR Transmitter Cable to the IR-TX port, and

position the extended IR sensor directly in front of the video source’s IR sensor.

Check the manual of your video source device for the IR sensor location.

4. Your source video image will now appear on the remote video display.

Instruction Manual

Specications

AV Input HDMI®

AV Output HDMI®

Cabling Cat 5e/6 UTP

Audio Yes

Local Unit Connectors

2x IrDA (Infrared; SIR/FIR)

1x HDMI (19 pin) Female

3x RJ-45 Female

Remote Unit Connectors

2x IrDA (Infrared; SIR/FIR)

1x HDMI (19 pin) Female

3x RJ-45 Female

Max Distance 100 m / 330 ft

Maximum Digital Resolutions 1080p @ 60Hz, 48-bit

Wide Screen Supported Yes

Audio Specications Supports Dolby® TrueHD, DTS-HD MA

Input Voltage 110 ~ 240V AC

Input Current 2 A

Output Voltage 48 DC V

Output Current 0.5A

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.

Indice

Altri manuali StarTech.com Estensione

StarTech.com

StarTech.com ST121UTPHD2 Manuale utente

StarTech.com

StarTech.com SV565UTPHDU Manuale utente

StarTech.com

StarTech.com USBthere USB221EXT Manuale utente

StarTech.com

StarTech.com STUTPEALR Manuale utente

StarTech.com

StarTech.com UTPE Series Manuale utente

StarTech.com

StarTech.com SV565FXHD4KU Manuale utente

StarTech.com

StarTech.com ST12MHDLAN2K Manuale utente

StarTech.com

StarTech.com ST121HDBTPW Manuale utente

StarTech.com

StarTech.com ST12MHDLAN4K Manuale utente

StarTech.com

StarTech.com ST121HDBTU Manuale utente

StarTech.com

StarTech.com SV565HDIP Manuale utente

StarTech.com

StarTech.com ST121UTPDVI Manuale utente

StarTech.com

StarTech.com 110VDSLEXT2 Manuale utente

StarTech.com

StarTech.com SV565LANDUA Manuale utente

StarTech.com

StarTech.com ST121HDBTL Manuale utente

StarTech.com

StarTech.com USBthere USB204EXTFIB Manuale utente

StarTech.com

StarTech.com 110VDSLEXTGB Manuale utente

StarTech.com

StarTech.com USB2G4LEXT2 Manuale utente

StarTech.com

StarTech.com VS321HDBTK Manuale utente

StarTech.com

StarTech.com ST121DVI25 Manuale utente

StarTech.com

StarTech.com USB2G4LEXT2 Manuale utente

StarTech.com

StarTech.com ST121SHD30 Manuale utente

StarTech.com

StarTech.com VS321HDBTK Manuale utente

StarTech.com

StarTech.com USB2001EXT2 Manuale utente

Manuali Estensione popolari di altre marche

SY HDBT-60T Manuale utente

Appsys ProAudio

Appsys ProAudio ADX-16 Manuale utente

Atlona

Atlona RS232 Manuale utente

IDK

IDK OPF-TH1000-A Manuale utente

Enable-IT

Enable-IT 824WP Manuale utente

Worx

Worx Landroid RadioLink WA0864 Scheda tecnica

TP-Link

TP-Link TL-WA730RE Manuale utente

Camplex

Camplex CMX-HDMI-SFPL Manuale utente

SC&T

SC&T HE03-4K Manuale utente

Marmitek

Marmitek MegaView70 Manuale utente

Samsung

Samsung SCS-26UC4 Manuale utente

Foxun

Foxun SX-GES24 Manuale utente

MuxLab

MuxLab 500771 Manuale utente

foxunhd

foxunhd SX-AEX01 Manuale utente

TERK Technologies

TERK Technologies LFIRX2 Manuale utente

Devolo

Devolo Audio Extender Manuale

Edimax

Edimax EW-7438RPn V2 Manuale utente

Shinybow USA

Shinybow USA SB-6335T5 Manuale utente
