StarTech.com ST12MHDDC Manuale utente
Manual Revision: 01/16/2013
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
ST12MHDDC
HDMI® Over CAT5/6 Extender with
Daisy Chain
*actual product may vary from photos
Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.
Instruction Manual
i
Table of Contents
Introduction ............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements .............................................................................................................................. 1
Transmitter Unit ......................................................................................................................................... 2
Receiver Unit ............................................................................................................................................... 2
ST12MHDDCRP Repeater ....................................................................................................................... 3
Preparing Your Site ................................................................................4
Hardware Installation ............................................................................5
Specications ..........................................................................................7
Technical Support ..................................................................................8
Warranty Information ............................................................................8
Instruction Manual
1
Introduction
The ST12MHDDC HDMI® to CAT5 Extender kit lets you extend an HDMI® audio and
video signal over a single Cat5 or Cat6 cable up to 330 feet (100 meters). The extender
oers a highly scalable installation when used with the optional ST12MHDDCRP
repeater units, which can be daisy-chained to additional displays at greater distances.
Using ST12MHDDCRP repeater units (sold separately), you also have the option to
daisy-chain the HDMI® over Cat 5/6 up to 30 broadcasting levels to over 100 displays.
With 2 RJ45 to HDMI® output ports per unit, each repeater allows you to output to a
display - and also extend the HDMI® signal to 2 additional HDMI® repeaters at up to
an additional 330 feet (100 meters) at each level, making this the perfect solution for
large-scale digital signage applications that require maximum HDMI® signal quality.
For further scalability, the ST12MHDDC kit can be used with existing network cable
for a cost-eective and exible extension. Plus, because the HDMI® signal is extended
over standard Cat5/Cat6 Ethernet cable with RJ45 connectors, proprietary cables aren’t
necessary which eliminates both expense and the hassle of running specialized cable.
The HDMI® over Ethernet Extender kit includes optional mounting hardware and
features an HDMI® output on the local transmitter unit, which allows you to keep a
display or projector near your video source.
Ideal for High-Denition applications, the HDMI® over UTP extender supports 1080p
video resolutions, 7.1 digital audio and features built-in EDID monitor emulation,
which ensures native resolution and maximum compatibility with your display or
projector, for a convenient plug-and-play installation.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Packaging Contents
• 1x HDMI® Over CAT5 Transmitter
• 1x HDMI® Over CAT5 Receiver
• 2x Universal Power Adapter (NA / UK / EU)
• 2x Foot Pad Set
• 1x Instruction Manual
System Requirements
• HDMI® enabled video source (i.e. computer, Blu-ray Player)
• HDMI® enabled display device(s) One for each Receiver/Repeater (i.e. television,
projector)
• Available AC electrical outlet for transmitter, receiver and optional repeaters
• HDMI® cable from for each display
Instruction Manual
2
Transmitter Unit
Front View of Transmitter Back View of Transmitter
1. HDMI® IN
2. Power Status LED
3. Link Status LED
1. Power Jack
2. HDMI Out Link (RJ-45 Connector)
Receiver Unit
Front View of Receiver Back View of Receiver
1. HDMI® OUT
2. Power Status LED
3. Link Status LED
4. EDID Copy Button
1. Power Jack
2. HDMI® Out Link (RJ-45 Connector)
Instruction Manual
3
ST12MHDDCRP Repeater
Unit (Sold Separately)
The ST12MHDDC HDMI extender kit allows for additional displays to be added
between the extender and receiver at any time using ST12MHDDCRP repeater units.
Repeaters provide an HDMI output for a display, as well as 2 additional RJ-45 Jacks to
potentially be daisy chained to 2 additional repeaters.
Front View of Repeater Back View of Repeater
1. HDMI® OUT
2. Power Status LED
3. Link Status LED
4. EDID Copy Button
1. Power Jack
2. HDMI® Out Link #1 (RJ-45 Connector)
3. HDMI® Out Link #2 (RJ-45 Connector)
4. HDMI® IN Link (RJ-45 Connector)
Instruction Manual
4
Preparing Your Site
1. Determine where the local video source (i.e. computer, Blu-ray Player) will be
located and set up the device.
2. Determine where the remote display(s) will be located and place/ mount the display
appropriately.
3. (Optional) If using ST12MHDDCRP Repeater unit(s) (sold separately), determine
where the remote display will be located in relation to the other displays and place/
mount the display(s) appropriately. Repeaters allow for an additional 330 ft. (100
meters) of Cat5/6 between each device. The repeater(s) must be situated between
the extender and the receiver, as the receiver does not have an RJ45 out port to
continue the chain.
NOTE: Ensure the Transmitter Unit, the Receiver Unit, and any Repeater Units are all
situated near an available AC electrical outlet. Make sure all devices are turned o
before beginning installation.
Instruction Manual
5
Hardware Installation
1. Install Transmitter Unit
a) Position the Transmitter Unit near the video source (i.e. Computer, Blu-ray Player).
b) Connect an HDMI® cable from the video source device (i.e. computer, Blu-ray
Player) to the “HDMI® IN” on the Transmitter Unit.
c) Connect the provided Transmitter Unit power supply.
2. Install RJ-45 terminated Cat5/6 Ethernet Cable
a) Connect an RJ-45 terminated Cat5/6 Ethernet cable to the HDMI® Out Link (RJ-45
Connector) on the Transmitter unit.
NOTE: If you are using surface cabling, ensure you have enough Category 5/6
unshielded twisted pair (UTP) network cabling to connect the Transmitter Unit to
the Remote Unit’s (Repeater/Receiver) location, and that each end is terminated
with a RJ45 connector. The cabling should not go through any networking
equipment (i.e. router, switch).
OR
If you are using premises cabling, ensure that the Category 5/6 unshielded twisted
pair (UTP) network cabling between the Host Unit and the
Remote Unit has been properly terminated in a wall outlet in each location and
there is a patch cable long enough to connect the Remote Unit and the Host Unit
to their respective outlets. The cabling should not go through any networking
equipment (i.e. router, switch).
b) Connect the other end of the Cat5/6 cable run to the RJ45 connector on the
remote Unit (Receiver/Repeater) Unit.
c) (optional) When adding multiple repeaters, a run of Cat 5/6 cable will be required
from and to each device.
Instruction Manual
6
3. (Optional) Install Repeater Unit(s) (sold separately)
a) Position the Repeater Unit near the video display (i.e. television, projector) within
330 ft. (100 meters) from the level up device be it the initial transmitter or
another repeater.
b) Connect the video source to the HDMI® Out on the Repeater Unit using an
HDMI® cable.
c) Connect the Cat5/6 cable positioned in Step 2 to the”HDMI® In Link (RJ-45
Connector)” on the Repeater. Connect the Receiver Unit power supply. The Power
LED will light, and LINK LED will turn on after a successful connection between both
units is established. This may take several seconds.
NOTE: These steps can be repeated at each level when adding additional Repeaters
up to 30 levels. Each Repeater has two HDMI® out Links (RJ-45 Connectors) allowing
for the same signal to go in 2 dierent directions at each level.
4. Install Receiver Unit
d) Position the Receiver Unit near the video display (i.e. television, projector) within
330 ft. (100 meters) from the level up device be it the initial transmitter or
another repeater.
e) Connect the video source to the HDMI® out on the Receiver Unit using an
HDMI® cable.
f) Connect the provided Receiver Unit power supply. The Power LED will light,
and Link LED will turn on after a successful connection between both units is
established. This may take several seconds.
NOTE: The Receiver should only be used as the last device in the chain as it does not
have an HDMI out port (RJ-45 Connector).
5. Your source video image will now appear on the remote unit(s) attached
video display.
Instruction Manual
7
Specications
Local Unit Connectors 1x HDMI (19 pin)
1x RJ-45
Remote Unit Connectors 1x RJ-45 Female
1x HDMI (19 pin) Female
Max Distance 100 m / 330 ft
Maximum Digital Resolutions 1920x1200 @60Hz
Supported Resolutions
1920 x 1200
1920 x 1080
1600 x 1200
Wide Screen Supported Yes
Audio Specications 7.1 Surround Sound
