StarTech.com PCI100MMST Manuale utente

Manual Revision: 09/11/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

PCI100MMSC

PCI100MMST

100Mbps Full/Low Prole Ethernet

MM SC/ST Fiber PCI NIC Card

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements .............................................................................................................................. 1

Installation ..............................................................................................2

Hardware Installation .............................................................................................................................. 2

Driver Installation ...................................................................................................................................... 3

Specications ..........................................................................................4

Technical Support ..................................................................................5

Warranty Information ............................................................................5

Instruction Manual

Introduction

The StarTech.com Fiber Ethernet Network Adapter Card adds the speed, reliability,

and security of a Fiber Ethernet connection to a PCI compatible PC. This Fiber Optic,

Multi-Mode SC/ST, PCI Ethernet Adapter Card oers the perfect “Fiber-to-the-desk”

solution. Perfectly suited for high bandwidth applications with support for Full Duplex

operation and 10/100 Mbps transfer speeds.

Packaging Contents

• 1 x PCI100MMSC or PCI100MMST card

• 1 x Low Prole bracket

• 1 x Driver Installation CD

• 1 x Instructional Manual (on CD)

System Requirements

• PCI enabled computer system with available slot

• Microsoft® Windows® 2000/ XP/ Server 2003/ Vista/ Server 2008 R2/ 7 (32/64-bit)/

8 (32/64-bit), or Linux®

Instruction Manual

Installation

WARNING! PCI cards, like all computer equipment, can be severely damaged by static

electricity. Be sure that you are properly grounded before opening your computer

case or touching your PCI card. StarTech.com recommends that you wear an anti-static

strap when installing any computer component. If an anti-static strap is unavailable,

discharge yourself of any static electricity build-up by touching a large grounded metal

surface (such as the computer case) for several seconds. Also be careful to handle the

PCI card by its edges and not the gold connectors.

Hardware Installation

1. Turn your computer o and any peripherals connected to the computer (i.e. Printers,

external hard drives, etc.).

2. Unplug the power cable from the rear of the power supply on the back of the

computer and disconnect all peripheral devices.

3. Remove the cover from the computer case. Refer to documentation for your

computer system for details.

4. Locate an open PCI or PCI-X slot and remove the metal cover plate on the rear of the

computer case.

5. If installing into a low prole system, remove the full prole bracket from the card, by

releasing the two screws and installing the included low prole bracket in it’s place.

6. Insert the card into the open PCI or PCI-X slot and fasten the card’s bracket to the

rear of the case.

7. Place the cover back onto the computer case.

8. Insert the power cable into the socket on the power supply and reconnect all other

connectors removed in Step 2.

Instruction Manual

Driver Installation

Windows 2000/XP/Server 2003

1. When the Found New Hardware wizard appears on the screen, insert the Driver CD

into your CD/DVD drive. If you are prompted to connect to Windows Update, please

select the “No, not this time” option and click Next.

2. Select the option “Install Drivers Automatically (Recommended)” and then click the

Next button.

3. Windows should now start searching for the drivers. Once this has completed, click

the Finish button.

Windows Vista/Server 2008 R2/7 / 8

No driver installation is required for these operating systems, as this adapter card is

natively supported, so the drivers are already installed.

Instruction Manual

Specications

Bus Interface PCI rev 2.1

(3.3V/5V compatible)

Chipset ID VIA VT6105M

Connectors

PCI100MMSC:

1 x SC duplex

PCI100MMST:

1 x ST duplex

LEDs 1 x Link

1 x Activity

Supported Protocols IEEE802.3u 100Base-FX, IEEE802.3x,

IEEE802.1Q, IEEE802.1p

Link Speeds 10/100Mbps

Maximum Transmission Distance 2km

Optical Wave Length 1310nm

Compatible Cabling 50 or 62.5/125µm, Multi-Mode

Operating Temperature 0°C ~ 45°C (32°F ~ 113°F)

Storage Temperature -10°C ~ 70°C (14°F ~ 158°F)

Humidity 5 ~ 95% RH

Compatible Operating Systems

Windows 2000/XP/Server 2003/Vista/

Server 2008 R2/7 (32/64-bit)/

8 (32/64-bit), Linux

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
