StarTech.com PCI4S9503V Manuale utente

Manual Revision: 01/26/2012

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

PCI4S9503V

PCI8S9503V

4/8 Port PCI RS232 Serial Adapter Card

16950 Cable Included

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................2

Windows XP/2000..................................................................................................................................... 3

Windows NT ................................................................................................................................................ 3

DOS ................................................................................................................................................................ 4

LINUX............................................................................................................................................................. 5

SCO OpenServer........................................................................................................................................ 7

Technical Specications ........................................................................9

Technical Support ..................................................................................10

Warranty Information............................................................................10

Instruction Manual

Introduction

The PCI8S9503V 8 Port PCI RS232 Serial Adapter Card High Speed 16950 (cable

included) lets you connect up to 8 RS-232 serial devices to the host computer at data

rates up to 921 Kbps, and can be installed in either a 3.3V or 5V PCI/PCI-X slot.

The PCI4S9503V 4 Port PCI RS232 Serial Adapter Card High Speed 16950 (cable

included) lets you connect up to 4 RS-232 serial devices to the host computer at

transfer rates up to 921 Kbps, and can be installed in either a 3.3V or 5V PCI/PCI-X slot.

The PCI serial card uses a 16 Byte buer simultaneously in both transmit and receive

channels, reducing the number of CPU interrupts while improving system performance.

Ideally suited to industrial applications, the buered Serial PCI card is compatible

with a broad range of operating systems, including Windows®, DOS®, Linux, and Unix

operating environments.

Backed by a StarTech.com Lifetime warranty and free lifetime technical support.

Packaging Contents

• 1x PCI Serial Card

• 1x 8 Port DB9 Break-out Cable

• 1x Driver CD

• 1x Instruction Manual

System Requirements

• Acomputer running Windows XP/Vista/2000/NT/ DOS, Linux or SCO Open Server

• An open 3.3 or 5V PCI slot

Instruction Manual

Installation

Note: In one system, you can install two of these serial cards. You must dierentiate

between the two cards by using the jumper (located near the end of the card). The

card with the jumper ON will be card number 1. The card with the jumper OFF will be

card number 2. Install the cards one at a time, starting with the card you want to be

designated number 1.

Installing the Card

1. Make sure that your system is unplugged and you are grounded.

2. Remove the cover of your system (see your computer’s user manual for details, if

necessary) and gently turn your computer onto its side.

3. Locate an empty PCI slot (usually white in colour) and remove the metal plate that

covers the rear bracket. You may need a Phillips screwdriver to perform this step.

Hang on to the screw! You will need it to secure the card later.

4. Gently insert the card into the empty slot, making sure it is rmly seated.

5. Secure the card in place using the screw you removed in Step 3 and put your

computer case back on.

6. Plug the 37-pin end of the serial cable into the port on the card.

7. Turn the computer on.

Driver Installation

Note: Depending on your operating system and the conguration of your system, the

instructions below may not be identical to what you see on your screen.

Instruction Manual

Windows Vista/XP/2000

Once you turn your computer on after installing the card, Windows will automatically

detect the new hardware. Follow the onscreen prompts and direct Windows to the

appropriate folder on the driver disk

Notes:

• To change the COM port number: Windows will automatically assign the card a

COM port number. If you need to specify another port number, you can use the

setup utility included with the driver. Go to: Control Panel/System/Hardware/Device

Manager/Multi-Port Serial Adapter/Setup. From here you will be able to set the

target value.

• Each serial card needs an open IRQ for Plug and Play function.

Windows NT

Before you begin the installation, make sure you are logged in as a user with

administrative privileges.

1. Start the Control Panel applet by double-clicking on its icon in the Program

Managers main group.

2. Double-click the Network icon to bring up the Network Control Panel applet.

3. Select Add Adapter. A list of possible adapters will be displayed. Select “Other:

Requires disk from manufacturer.”

4. When prompted for the path, specify the location of the driver for the card you

installed. Depending on your version of the driver disk, the drivers may be found in

the P584/NT4 folder.

5. Follow the onscreen prompts to complete installation. Make sure that the COM port

number does not conict with any other devices in your system.

Use the“Binding”functiontomakemoreserial ports available. Ifyoudo notperform abinding

function, youmay nothavean extraCOMport availablein yournextboot procedure.

Notes:

• When installing two cards in the same system, the card with the jumper ON will be

assigned the lower COM port number. The card with the jumper OFF will have the

higher COM port number.

Instruction Manual

DOS

When installing multiple cards in DOS, it is important to install the card designated

card Number 1 (with the jumper ON) rst.

1. Change your active directory to the target directory:

ex: c:\RAYON

2. Insert the driver disk into the disk drive and copy the DOS les from the driver diskette:

ex: xcopy /s/e/v a:\DOS\*.*

3. Run the driver installation command:

ex: c:\rayon\pciport

4. The cards will now be installed in your system. Each card will show the card number

in the system (for the application to specify the target card and target port), the card

model, the card jumper setting (for card number 1 or 2), the IRQ assigned, and the

COM port number for the card.

You may see the following error messages:

• PCIPORT already installed. This means the driver has already been installed.

• Please check the“JP1”. This means that both cards in the system have their jumpers ON.

• PCIPORT not in system. There is no card in the PCI slot.

Notes:

The driver function call description can be found on the DOS driver diskette. There is

also a DEMO program for the user to meet their target application program.

Instruction Manual

LINUX

1. Login as super-user (SU) or root.

2. Change your directory to root and copy the driver diskette to the system:

# cd /

# tar xvf /dev/fd0

3. Change the directory to /etc/pciport and run the Install command:

# cd /etc/pciport

# ./Install

4. Follow the prompts to perform the following:

• Choose your Linux kernel version

• Rebuild your system

• Exit and reboot with new settings

The device name will be /dev/tty8[1--2] [a--h]

Card Denitions

Card Number Device Name

1 tty81?

2 tty82?

Note: Card 1 is the card with the jumper ON.

Instruction Manual

I/O Port Number Denitions

Port Number Device Name

A tty8?a

B tty8?b

C tty8?c

D tty8?d

E tty8?e

F tty8?f

G tty8?g

H tty8?h

For example, the device named /dev/tty82b is the device plugged into port B on card

Number 2.

Notes:

• The above installation procedure installs a module type driver. If you can not install

the driver successfully, you may need to use a kernel type driver. You will need to

enter the Build directory and run Install again. In kernel type drivers, you may need

to have the full source le for the Linux system to be re-compiled.

• Each serial card needs an open IRQ for Plug and Play function.

Instruction Manual

SCO OpenServer

1. Log in as a super-user (SU) or root.

2. Extract all the les on the diskette using the tar command:

# cd /

# tar xvf /dev/fd0135ds18

3. Change the directory to /etc/pciport and run the Build command:

# cd /etc/pciport

# ./build

4. Reboot your system.

The device name will be /dev/tty8[1--2] [a--h]

Card Denitions

Card Number Device

1 tty81?

2 tty82?

Note: Card 1 is the card with the jumper ON.
