StarTech.com PEX1S952 Manuale utente

PEX1S952

PEX2S952

PEX1S952LP

PEX2S952LP

Native PCI Express RS232

Serial Adapter Card

with 16950 UART

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual

Table of Contents

Introduction.................................................................................... 1

Features ......................................................................................1

Package Contents .......................................................................1

Jumper Conﬁguration ................................................................... 2

Hardware Installation .................................................................... 3

Driver Installation .......................................................................... 3

Windows 2000/XP Driver Installation ..........................................3

Windows Vista Driver Installation ................................................5

Speciﬁcations ................................................................................ 7

Technical Support ......................................................................... 8

Warranty Information .................................................................... 8

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com PEX1S952/PEX2S952/

PEX1S952LP/PEX2S952LP Native PCI Express 16C950 UART Serial

Card. This dual proﬁle Serial card converts a PCI Express slot into one or

two RS-232 (DB9) serial connections, while relying on a native, single-

chip design for optimal performance and reliability.

Features

128-byte deep FIFO per transmitter and receiver•

Automated in-band software ﬂow control using programmable Xon/Xoff•

in both directions

Automated out-of-band hardware ﬂow control using Tx/Rx/RTS/CTS/•

DSR/DTR/DCD/RI/GND

Compliant with IEEE1284, SPP/EPP/ECP parallel port•

Compliant with PCI Express base speciﬁcations revision 1.1•

High Performance Dual Channel Oxford 950 UART•

Native single-Chip, single lane PCI Express•

Selectable power output on pin 9 for the serial port•

High speed RS-232 serial ports with data transfer rate up to•

460.8 Kbps

Package Contents

1 X Serial Card (Low Proﬁle bracket preinstalled on LP models)•

1 X Driver CD•

1 X Instruction Manual•

1 X Low Proﬁle Bracket (PEX1S952 only)•

2 X Low Proﬁle Bracket (PEX2S952 only)•

1 x Full Proﬁle Bracket (PEX1S952LP/PEX2S952LP only)•

Instruction Manual

Jumper Conguration

The card is specially designed to allow power output from the ninth pin of

the connector to enable power up of the connected devices without the

use of a power adapter. The card allows user to set each individual port

with 5V, 12V, or RI (no power). The user may also choose to draw the

needed power from the PC’s internal system power supply via an LP4

molex connector.

Instruction Manual

Hardware Installation

Turn off the power to your computer.1.

Unplug the power cord and remove your computer’s cover.2.

Remove the slot bracket from an available PCIe slot.3.

To install the card, carefully align the card’s bus connector with the4.

selected PCIe slot on the motherboard. Push the board down ﬁrmly.

Optional:5. Connect the LP4 molex power connector from the computer

power supply to the card. Make sure the Jumper settings on the card

are conﬁgured properly.

Replace the slot bracket’s holding screw to secure the card.6.

Replace the computer cover and reconnect the power cord.7.

Driver Installation

Windows 2000/XP Driver Installation

At the Add New Hardware Wizard window, click on “Next.”1.

Select the option “Search for the best driver for your devices2.

(Recommended)” and click on “Next.”

Select the option “Specify the location” and type in D:\Uart (where D: is3.

your CD-ROM drive) then click on “Next.”

Click “Next” and then “Finish” respectively.4.

Remove the disc, then select “Yes” to restart the computer for the5.

setup to take effect.

Instruction Manual

To verify successful installation on Windows 2000/XP:

From the main desktop, right-click on “My Computer”, then select1.

Manage. In the new Computer Management window, select “Device

Manager” from the left window panel.

Double-click on both “Ports (COM & LPT)” and “Multifunction Adapters”.2.

The Serial Adapter board and additional serial ports (COM ports)

should be displayed when successfully installed. The port is ready to

be connected to new device(s).

Instruction Manual

Windows Vista Driver Installation

At the Found New Hardware prompt, click on “Locate and install driver1.

software (recommended).”

When prompted, insert the disc included with your Serial Card and2.

then click “Next.”

A notiﬁcation will appear informing you that Windows has encountered3.

a problem installing the driver software for your device. Click “close” to

continue.

When another Found New Hardware prompt appears, install the4.

software from the disc included with your Serial Card and then click

“Next.”

A notiﬁcation will appear informing you that Windows has encountered5.

a problem installing the driver software for your device. Click “close” to

continue.

Instruction Manual

To verify successful installation on Windows Vista:

From the main desktop, right-click on “Computer”, then select Manage.1.

In the new Computer Management window, select “Device Manager”

from the left window panel.

Double-click on both “Ports (COM & LPT)” and “Multifunction Adapters”.2.

The Serial Adapter board and additional serial ports (COM ports)

should be displayed when successfully installed. The port is ready to

be connected to new device(s).

Instruction Manual

Specications

PEX1S952

PEX1S952LP

PEX2S952

PEX2S952LP

Bus Type PCI Express rev 1.1 (3.3V)

External Ports 1 x DB9 2 x DB9

Internal

Connectors 1 x LP4 molex

Chipset Oxford OXPCIe952

UART 16C950

Power Mode* 5V / 12V / RI (no power)

Maximum Data

Transfer Rate 460 Kbps

Stop Bits 1, 1.5, 2

Data Bits 4, 5, 6, 7, 8

Compatible

Operating Systems

Windows 2000/XP/Server 2003/Vista,

Linux kernel 2.6.11 or later

*Selectable power output on Pin 9 of the serial port
