StarTech.com PEX1000SFP Manuale del sistema

PCI Express Gigabit Ethernet Fiber Open SFP PCIe Network Card Adapter NIC

StarTech ID: PEX1000SFP

The PEX1000SFP PCI Express Gigabit Ethernet Fiber Open SFP Network Card lets you connect a PCI Express-

based PC directly to a fiber optic network using the Gigabit SFP of your choice.

A versatile solution for connecting a computer directly to a gigabit fiber network, the PCIe SFP network adapter

enables you to choose the Gigabit SFP that best suits your network fiber connection and distance requirements

(see our full line of Gigabit transceivers for compatible solutions).

Ideal for secure network setups, the open SFP NIC offers a direct fiber connection which is not susceptible to

electronic interference like standard RJ45 networks.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Applications

Ideal for secure setups - a direct fiber connection means no electronic interference, which can be a problem

with RJ45 network cards

Perfect for remote embedded industrial monitoring systems, and high speed video surveillance

Retain full Gigabit network speeds to a remote terminal over long distances

uk.startech.com

0800 169 0408

Features

Compatible with any Gigabit SFP modules

Supports Full/Half-duplex Auto-Negotiation, Auto-MDI/MDIX

Compliant with IEEE 802.3z 1000Base-SX/LX, IEEE802.1Q VLAN Tagging, IEEE802.1p Layer 2 Priority

Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1

Jumbo Frame Support

Supports PCI Message Signaled Interrupt (MSI)

Preboot Execution Environment (PXE) 2.1

uk.startech.com

0800 169 0408

Technical Specifications

Warranty 2 Years

Bus Type PCI Express

Card Type Standard Profile

Chipset ID Realtek - RTL8168B; Marvell - 88E1111-RCJ1

Industry

Standards

IEEE 802.3z 1000Base-SX/LX, IEEE802.1Q VLAN Tagging, IEEE802.1p Layer 2 Priority

Encoding, IEEE 802.3x full duplex flow control, RFC 1157 SNMP v1

Ports 1

Connector

Type(s)

1 - PCI Express x1

Auto MDIX Yes

Buffer Size 48 KB

Compatible

Networks

1000 Mbps (1 Gbps)

Full Duplex

Support

Yes

Maximum Data

Transfer Rate

2000Mbps (Full-Duplex)

OS Compatibility Windows® 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64), 2000

Windows® Server 2008 R2, 2003(32/64)

Linux 2.4.x/ 2.6.x

Product Height 125 mm [4.9 in]

Product Length 121 mm [4.8 in]

Product Weight 80 g [2.8 oz]

Product Width 20 mm [0.8 in]

LED Indicators 1 - Activity (Yellow)

LED Indicators 1 - Link (Green)

Power

Consumption

2.3 W Max

Humidity 5~95% RH (Non-condensing)

Operating

Temperature

0°C to 45°C (32°F to 113°F)

Storage

Temperature

-10°C to 70°C (14°F to 158°F)

Note Fiber data transfer speeds and distances are dependent on the SFP used (sold separately)

Shipping

(Package)

0.3 kg [0.7 lb]

uk.startech.com

0800 169 0408

Weight

Included in

Package

1 - PCI Express Open SFP Network Card

Included in

Package

1 - Driver CD

Included in

Package

1 - Instruction Manual

Certifications, Reports and Compatibility

uk.startech.com

0800 169 0408
