SunSet xDSL IDSL Module:

IDSL Circuit Testing

Publication Number APP-xDSL-011 Rev. A

TRANSPORT FOR IDSL CIRCUITS

IDSL Circuits can be rovisioned

from the DSLAM at the Central

Office (CO) location to the

Customer Premises Equi ment

(CPE) over a co er air directly

(as shown in Figure 1), if the

customer is located within the

reach range (about 18,000 feet

without re eaters). A number of

IDSL circuits can also be multi-

lexed and trans orted over a

Digital Loo Carrier (DLC) system,

which meets the Telcordia TR-

TSY-000397 requirement to bring

IDSL service to a cluster of

customers in the same area (refer

to Figure 2).

TESTING IDSL CIRCUITS

The turn-u of an IDSL circuit

requires verifying end-to-end

continuity and bit error erfor-

mance of the circuit between the

CO and the CP. There are two

ossible ways to achieve the

verification test for the circuit:

• Single-ended test: Only one test set is required and

the circuit can be tested from either:

– The central office where the test set emulates the

Line Termination (LT) device, i.e. the DSLAM or,

– From the field where the test set emulates the

customer remises equi ment (NT).

• Two-ended test: Two test sets are required, one

emulates the LT at the CO location and the other

emulates the NT at the CPE location.

SINGLE-ENDED TESTING FROM THE

CENTRAL OFFICE

In general, single-ended testing is done from the CO

location. A test set, emulating the LT at the CO, is

connected to the IDSL circuit under test. Then, ANSI

T1.601 embedded o erations channel (eoc) loo u

commands can be sent to loo u the IDSL Router (NT/

TA) at the CP if it has been installed. A Bit Error Rate

Test (BERT) can then be run towards the loo , to verify

the erformance of the circuit.

For an IDSL circuit trans orted over a DLC system, it is

required that the DLC be configured to use the 3-DS0

TDM multi lexing method to enable eoc commands to

ass through the system. In this method, the DLC

designates three DS0 channels to trans ort the entire

2B+D ayload lus the overhead from one end to the

other end of the system. This method also enables eoc

loo commands to be sent to the channel unit cards (U-

BRiTE cards), which act as re eaters at either the DLC

CO Terminal or the DLC Remote Terminal. These loo

commands can hel when troubleshooting the line

cards. If the DLC is set to run in Trans arent mode, the

eoc channel will not be assed through the DLC to the

CPE and the loo commands will not be su orted in

the DLC system. Therefore, a two-ended test must be

erformed.

To successfully BERT test an IDSL circuit over a DLC, the

test set must be synchronized to the network clock to

avoid intermittent attern sync loss due to clock sli s.

This is detailed in the SunSet xDSL A lication Series,

Publication Number APP-XDSL-010, IDSL Testing with

an External Reference Clock.

U-2B1Q

2-wire DSL

to ATM

backbone

Central Office

DSLAM

IDSL Router

NT/TA

Customer Premises

T1or

higher order U-2B1Q

2-wire DSL

U-2B1Q

2-wire DSL

to ATM

backbone

DSLAM

IDSL Router

NT/TA

DLC

Terminal

DLC

Remote

Terminal

Central Office Customer Premises

Figure 1 IDSL Circuit transported over a 2-wire Copper Pair

Figure 2 IDSL Circuit transported over a Digital Loop Carrier

The single-ended tests from the

CO (Figures 3 and 4) are a li-

cable only if the CPE has already

been connected to the IDSL

circuit, or if the DLC system

su orts and asses through the

eoc channel. If the eoc is su -

orted, the SunSet xDSL with an

IDSL Module will be able to

loo back not only the CPE, but

also the channel unit line cards in

each of the DLC Terminals (CO and

Remote) for BERT analysis.

Configuring the Test Set

The configuration of the test set is

similar for testing an IDSL circuit

over a co er air or over a DLC

system. The only difference is the

TX CLOCK setting. For testing

IDSL over a co er air, the TX

CLOCK source should be set to

INTERN, to use the internal clock

of the test set. However, for IDSL

circuits carried over a DLC, an

external reference clock should be

used to synchronize the test set to

the network. In most cases, a U

interface signal from either the DSLAM or an ISDN

switch is used, so TX CLOCK should be set to EXT-U (as

shown in Figure 5).

The TX CLOCK setting is only available when the test set

is configured to LT-144k. In this mode, the selected test

attern is sent in the test channel s ecified. As you

cursor down to the TX CLOCK field, four F-keys will be

dis layed. Select the a ro riate clock setting that fits

the a lication to be run.

Connect the U-2B1Q connector of the test set to the

IDSL circuit under test and connect the U EXT CLK

connector to the external clock source, if a licable.

The TEST CHANNEL selection should be set to 2B+D to

BERT test the IDSL circuit at the full rate of 144 kb s.

You can also select a smaller set of channels to BERT

test at a lower s eed.

The T1/E1 SIG LED should turn green, followed by the

LP1 SYNC LED after Layer 1 frame synchronization is

acquired. When the TX CLOCK field is set to EXT-U, the

FRAME LED will be used to indicate the status of the

external clock in ut. The FRAME LED will be solid green

to indicate a ro er external clock signal, or will be red

if the external clock is not received ro erly.

higher order

Channel loopback

SSxDSL

w/IDSL Module

LT-

44K Mode

IDSL Router

NT/TA

DLC

Terminal

U-2B

2-wire DSL

U-2B

2-wire DSL

DLC

Remote

Terminal

eoc loop up command

Central Office Customer Premises

Figure 3 Single-ended test on IDSL Circuit fro the CO

Figure 4 Single-ended test on IDSL Circuit transported over a DLC fro the CO

TEST CONFIGURATION

INTERFACE : U

MODE : LT-144K

TEST CHANNEL : 2B+D

TEST PATTERN : 2047

INTERN EXT-T1 EXT-E1 EXT-U

08:11:01

TX CLOCK : EXT-U

Figure 5 IDSL Module TEST CONFIGURATION Screen

SSxDSL

w/IDSL Module

LT-144K Mode

Ext.Clock

from DSLAM or

ISDN Switch

Central Office

IDSL Router

NT/TA

U-2B1Q

2-wire DSL

Channel loopback

eoc loop up command

Customer Premises

ADDRESS : 0 (NT1

EOC CONTROL

COMMAND : 2B+D LOOPBACK

EOC BITS : 000101010000

RX ADDRESS : 0 (NT1

RX COMMAND : 2B+D LOOPBACK

RX EOC BITS: 000101010000

SEND NORMAL LOOP2BD MORE

08:11:05

---------------------------

Figure 6 EOC CONTROL Screen

ELAPSED TIME:

000:10:08

ERROR COUNT:

PAGE-UP PAGE-DN STOP STORE

MEAS 08:23:20

Figure 7 BERT & RESULTS Screen

Looping Up a Channel Unit Line Card or CPE

Esca e from the TEST CONFIGURATION screen and enter

the EOC CONTROL screen (Figure 6).

To loo back the IDSL Router (NT/TA), set the ADDRESS

to 0 (NT1) and the COMMAND to LOOP2BD. This eoc

command will then be sent to the NT (CPE) and will

initiate a loo back of the B1, B2, and D-channels. Press

the SEND F-key to transmit the eoc command. Check in

the bottom half of the screen to see the RX (received)

ADDRESS and COMMAND returned from the device.

The RX ADDRESS and COMMAND should be identical to

those transmitted. This indicates a successful command

and res onse, and that the loo back is in lace. If the

identical message is not shown in the Received field, the

loo command has failed.

Running a BERT Test

Once the loo back is confirmed, a BERT test can be

started. Esca e from the EOC CONTROL screen and

enter the BERT & RESULTS screen from the IDSL/ISDN

BERT menu. Check that the PAT SYNC LED is solid green

(indicating test attern synchronization) and that the

BIT ERR LED is off. Inject a bit error from the test set by

ressing the ERR INJ key on the key ad. The BIT ERR

LED should turn red for about one second and start

blinking red. Check that the ERROR COUNT reads one;

this verifies that the channel is ro erly loo ed back.

Press the HISTORY key to acknowledge the error

condition. You will notice that the BIT ERR LED will

sto blinking. Press the STOP/

START F-key twice to restart the

BERT test. This will set the ERROR

COUNT back to 0 (see Figure 7).

For testing a bit rate of 144 kb s

(i.e. TEST CHANNEL setting of

2B+D), it is recommended by the

ANSI T1.601 s ecification, that the

BERT test be run for at least 10

minutes. For testing a bit rate of

64 kb s (i.e. TEST CHANNEL setting

of B1 or B2), the test should be run

for 25 minutes.

SINGLE-ENDED TESTING

FROM THE FIELD

The test set functions as an NT

emulating the CPE, and the DSLAM

is required to rovide a loo back

on the IDSL circuit to be able to

erform a BERT test from the CP

(Refer to Figures 8 and 9).

Single-ended BERT to loop

SSxDSL

w/IDSL Module

NT-144K Mode

T1or

higher order U-2B1Q

2-wire DSL

U-2B1Q

2-wire DSL

to ATM

backbone

Central Office Customer Premises

DSLAM

DLC

Terminal

DLC

Remote

Terminal

Figure 8 Single-ended test on IDSL Circuit fro the CP

Figure 9 Single-ended test over a DLC fro the CP

U-2B1Q

2-wire DSL

Single-ended BERT to loop

to ATM

backbone

Central Office

DSLAM

SSxDSL

w/IDSL Module

NT-144K Mode

Customer Premises

-POWER

TEST CONFIGURATION

INTERFACE : U

TEST PATTERN : 2047

NT-144K LT-144K NT-LOOP LT-LOOP

09:11:01

TEST CHANNEL : 2B+D

MODE : NT-144K

Figure 10 TEST CONFIGURATION Screen

-POWER

NET NT

M4 ACCESS

M4 : 11111111

*ACT *DEA *SOC *UOA *AIB

08:11:05

Figure 11 M4 ACCESS Screen

With the SunSet xDSL test set, you can choose which

channels to run a BERT test on, from only the D-channel

(16 kb s) to the full combined 2B+D channels (144 kb s).

If the eoc channel is not assed through the DLC

system, or a loo cannot be laced at the DSLAM, a

two-ended test is required to run a BERT test on the

IDSL circuit.

Configuring the Test Set

The configuration of the test set is identical for testing

IDSL circuits over a co er air or over a DLC. The

configuration is as shown in Figure 10. The test set is

configured to the NT-144k emulation mode and allows

the user to configure a TEST PATTERN and designate

which TEST CHANNEL is used.

Connect the U-2B1Q connector of the test set to the

IDSL circuit under test. The TEST CHANNEL selection

should be set to 2B+D to run the BERT test at the full

rate of 144 kb s. As with single-ended testing from the

CO, you can also select a smaller set of channels to BERT

test at a lower s eed.

The T1/E1 SIG LED should turn green, followed by the

LP1 SYNC LED after Layer 1 synchronization is acquired.

Checking Continuity to the DSLAM

If the IDSL goes through a DLC, a green T1/E1 SIG LED

means that the test set has achieved Layer 1 frame

synchronization to the last channel unit line card of the

DLC. This does not necessarily mean you have connec-

tivity all the way to the DSLAM. To confirm this, check

the status of the ACT bit in the M4 channel, which is

art of the overhead. Enter the M4 ACCESS screen

(Figure 11). In NT-144k mode, the test set shows only

the received M4 bits. The left most M4 bit dis layed on

the screen is the ACT bit. If it is set to a 1, or if the ACT

indication is marked with an asterisk (*), the circuit is

connected through the DLC all the way to the DSLAM.

Running a BERT Test

If a loo can be rovided at the DSLAM, then a BERT

test can be started on the IDSL circuit. Enter the BERT

& RESULTS screen to start the BERT test. Check that the

PAT SYNC LED is solid green (indicating test attern

synchronization) and that the BIT ERR LED is off. Inject

a bit error from the test set by ressing the ERR INJ key

on the key ad. The BIT ERR LED should turn red for

about one second and start blinking red. Check that

the ERROR COUNT reads one. This verifies that the

channel is ro erly loo ed back. Press the HISTORY key

to acknowledge the error condition. You will notice

that the BIT ERR LED will sto blinking. Press the STOP/

START F-key twice to restart the BERT test. This will set

the ERROR COUNT back to 0.

TWO-ENDED TEST OVER AN IDSL CIRCUIT

In this case, two test sets are used to test from each end

of the IDSL circuit. One in the CO, emulating the LT (or

the DSLAM), and the other at the customer remises

emulating the NT (or the CPE). This test is extremely

useful to qualify the cable air and/or ath rovisioned

by the DLC for IDSL service before the DSLAM is

connected to the circuit and the CPE is installed.

Because of the two-ended, bidirectional BERT test

erformed in this a lication, it will also detect

directional roblems from assing data over the IDSL

circuit and through the DLC system.

Configuring the Test Set

In this two-ended testing a lication, two SunSet xDSL

units with IDSL modules are required (one at each end

of the IDSL circuit - see Figures 12 and 13 on next

age). The test set on the CO side of the circuit will be

configured to LT-144k mode and the test set on the

customer side of the circuit will be configured to NT-

144k. Each test set should have the TEST CHANNEL set

U-2B

2-wire DSL

SSxDSL

w/IDSL Module

NT-

44K Mode

SSxDSL

w/IDSL Module

LT-

44K Mode Bidirectional end-to-end BERT

Central Office Customer Premises

Figure 12 Two-ended test on an IDSL Circuit

SSxDSL

w/IDSL Module

NT-

44K Mode

SSxDSL

w/IDSL Module

LT-

44K Mode

higher order

DLC

Terminal

U-2B

2-wire DSL

U-2B

2-wire DSL

DLC

Remote

Terminal

Ext.Clock

from DSLAM or

ISDN Switch

Bidirectional end-to-end BERT

Central Office Customer Premises

Figure 13 Two-ended test on an IDSL Circuit over a DLC

to 2B+D in order to run the test at

the full rate of 144 kb s. An

external clock reference in ut for

the LT-144k unit on the CO side of

the circuit, is required if the circuit

goes through a DLC system.

The configuration of the test set

emulating the LT-144k mode is the

same as that shown in Figure 5.

The TX CLOCK is set according to

the requirement as detailed in the

Single-Ended Testing section. Refer

to Figure 10 for the configuration

of the test set emulating the NT-

144k mode.

The T1/E1 SIG LED should turn

green, followed by the LP1 SYNC

LED after Layer 1 frame synchroni-

zation is acquired. If the circuit

goes through a DLC, enter the M4

ACCESS screen on the NT-144k

unit to confirm ath continuity

between the two test sets. This

will allow you to observe the

status of the ACT bit (see Figure

11). If it is set to a 1, or if the ACT

indication is marked with an asterik (*), the circuit is

connected through the DLC to the DSLAM, or in this

case, the SunSet xDSL emulating the DSLAM (LT-144k).

When set to 1, the end-to-end BERT test can be started

by going to the BERT & RESULTS screen. Check that the

PAT SYNC LED is solid green (indicating test attern

synchronization) and that the BIT ERR LED is off on

both test sets. Inject a bit error from each of the test

sets by ressing the ERR INJ key on the key ad. The BIT

ERR LED should turn red for about one second and start

blinking red. Check that the ERROR COUNT reads one.

This verifies that the channel is ro erly loo ed back.

Press the HISTORY key to acknowledge the error

condition. You will notice that the BIT ERR LED will

sto blinking. Press the STOP/START F-key twice to

restart the BERT test. This will set the ERROR COUNT

back to 0 (refer back to Figure 7).

Altri manuali Sunrise telecom Unità di controllo

Sunrise telecom

Sunrise telecom SSxDSL-5M Manuale utente

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
