Assembly Manual
Australia - 1800 316 962 | New Zealand 0800 21 8020
Ensure that the 2 wires protruding from
front of floor base are stood up straight.
Place the sauna floor in the desired location.
It is necessary to position the floor out from your walls for assembly and move the sauna following assembly.
Prepare & Position the Sauna Floor
If you are assembling your sauna on a hard surface floor, it is recommended that
you apply the included adhesive felt to the bottom of the sauna floor.
Please note: It is important that the sauna floor is level. Checking with a large level is recommended. If the
floor is not level, shimming or other remedies should be applied before assembling the sauna.
Australia - 1800 316 962 | New Zealand 0800 21 8020
Position the Back Wall
It is easiest if the Back Wall is placed behind the sauna floor base. Simply lean the Back Wall against
your room wall at this time.
Front Wall
Place the sauna front wall into the Floor
Base channel.
Take care with the 2 wires protruding from
floor base.
Australia - 1800 316 962 | New Zealand 0800 21 8020
Right Side Wall
Place the Right Side Wall in the
Floor Base channel
Front Right Corner
Connect the Right Side Wall to the
Front Wall by raising the Side Wall
approx 1/2" then sliding down to
connect the 2 fasteners.
Cinch the two walls together by
applying pressure on the outside of the
Side Wall with the inside of your knee.
It is helpful if the second person applies pressure against the opposite edge of the Front Wall. This will help
ensure that the two walls remain in contact and the fasteners will connect.
NOTE: It is NOT necessary to lift the
entire Side Wall. Simply slide the
Side Wall upward at the front corner
of the sauna to connect to the Front
Wall
Australia - 1800 316 962 | New Zealand 0800 21 8020
Hold Front Wall DOWN while
sliding Side Wall UP
There are two sets of fasteners to join the saunas' corners together. After lowering the Side Wall, check
to ensure that both sets of fasteners have connected by looking at the corner inside of the sauna. It is
possible to connect one set of fasteners and miss the other. If there is an obvious gap in the corner
between the two walls at least one fastener has not connected and the raising and lowering procedure
will need to be repeated.
Australia - 1800 316 962 | New Zealand 0800 21 8020
Position Back Wall
Place the Back Wall into the Floor Base channel.
Back Right Corner
Connect the Right Side Wall to the Back Wall by
raising the Side Wall approx 1/2" then sliding down
to connect fasteners
Back Wall
NOTE: It is NOT necessary to lift the entire Side Wall.
Simply slide the Side Wall upward at the back corner of the sauna to connect to the Back Wall
Hold Back Wall DOWN while sliding Side Wall UP
Australia - 1800 316 962 | New Zealand 0800 21 8020
Position Left Side Wall
Place the Left Side Wall into the Floor Base channel
Front Left Corner
Slide Left Side Wall up then down to connect
the Left Side Wall to Front Wall
Hold Front Wall DOWN while sliding Left Side Wall UP
Australia - 1800 316 962 | New Zealand 0800 21 8020
Position Back Wall
Place the Back Wall into the Floor Base channel
Back Left Corner
Slide Left Side Wall up then down to connect the Left Side Wall to Back Wall
Hold the Back Wall DOWN while sliding the Left Side Wall UP
Back Wall
Australia - 1800 316 962 | New Zealand 0800 21 8020
Under-Bench Electrical
NOTE: Do not connect main power cord to your wall outlet at this time.
Connect the circular connector to power supply
box. Align the groove in connector to properly
insert. Thread the cuff of the connector on fully.
Attach the 'D-Sub' computer
style connector as shown.
Plug in all heater leads to the
receptacles in the power supply box.
Australia - 1800 316 962 | New Zealand 0800 21 8020
Feed the main Power Supply Cord in through the hole in the Back Wall and
insert in Power Supply Box.
Do NOT plug power cord into your wall outlet until all electrical connections are finished
inside of the sauna and for the roof.
Connect the 2 floor/front wall connectors and install wooden cover plate
