USER’S MANUAL
Stereo Headphones
with Microphone
ap-620
ENG
1
User’s Manual
Congratulations on your purchase of the SVEN headphones!
APPLICATION
Sven АР-620 stereo headphones with a microphone are designed for
operation with PC sound cards and other compatible systems. They can be
also used in VoIP telephony, video conferencing, multimedia applications,
interactive games, for speech recognition and learning foreign languages.
One of the distinctive features of the model is SVEN PNC (passive noise
cancelling) system providing isolation from outside sounds.
SAFETY PRECAUTIONS
•Don’t use the stereo headphones while driving.
•Don’t use the stereo headphones at high volume for a long time (more
than 15 minutes), as this may cause hearing impairment.
SPECIAL FEATURES
•2*3.5 mm (3 pin) connector for PC
•Unilateral connection of the cable
•Rotary microphone
•Intense bass
•Volume control on cable
•Adjustable headband
•Heavy-duty non-tangling cable with fabric braid
•SVEN PNC passive noise cancelling system
CONNECTION AND OPERATION
•Connect the headphones connector to the audio output jack of your audio
source (PC, laptop, MP3 player), as shown in Fig. 1.
•Insert the microphone connector into the microphone input jack of your
audio source.
•Adjust the headphones volume level as desired with the volume control wheel
on the cable.
ap-620
Fig. 1. Connection diagram
Volume control
wheel
Headphones
connector
Microphone
connector
Microphone
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Sensitivity, dB
Frequency range, Hz
Membrane, mm
Connector type
Cable length, m
Weight, g
Value
headphones: 106 ± 2
microphone: -48 ± 3
headphones: 18 – 22,000
microphone: 50 – 16,000
Ø 40
Ø 2*3.5 mm (3 pin) stereo mini-jack
2.2
140
Notes:
• Technical specifications given in this table are supplemental information
and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to the
improvement of SVEN production.
Technical support is on www.sven.fi.
Sound card
Phone out
Mic in
ENG
2
Stereo Headphones
with Microphone
Модель:
AP-620
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. ap-620
