OPERATION

MANUAL

AP-B770MV

Wireless Stereo Headphones

with Microphone

ENG

Operation Manual

Congratulations on your purchase of the SVEN stereo headphones!

This Manual and information contained in it are copyrighted. All rights

reserved.

APPLICATION

SVEN AP-B770MV wireless stereo headphones with microphone are

designed for operation with PC, notebookes and other mobile devices by

means of data transfer via Bluetooth protocol. They can be also used in

internet telephony, during video conferences, in multimedia applications, in

interactive games, for speech recognition and foreign language teaching.

PACKAGE CONTENTS

•Stereo headphones – 1 pc

•Power cord USB to mini USB – 1 pc

•User’s Manual – 1 pc

•Warranty card – 1 pc

SAFETY PRECAUTIONS

•Don’t use the stereo headphones while driving.

•Don’t use the stereo headphones at high volume for a long time (more than

15 minutes), as this may cause hearing impairment.

SPECIAL FEATURES

• 3.0 Bluetooth wireless signal transmission

• Operation time with battery up to 22 hours

• Radius of operation up to 10 m

• Track switching control possibility

• Call acceptance function

AP-B770MV

ENG

DESCRIPTION

a: next track

b: Рlay/Рause

c: previous track

dCHARGE: mini USB jack for

battery charging

eMIC: microphone

f: headphones on/oﬀand

call control button

gV-: volume down button

hV+: volume up button

iLED indicator

CONNECTION AND OPERATION

Device switching on/off

•Press and hold down the button funtil the battery beeps to switch on

the headset. During the headphones switching on the LED iwill start

blinking blue color. Press once more and hold down the button funtil the

battery beeps to switch oﬀthe device. During the headphones switching oﬀ

the LED iwill blink red three times.

Control buttons

Jointly with a telephone:

•to receive an entry call press the button f. Press the button fonce

more to ﬁnish the call f;

•when the button fis pressed long (~2 sec.), the last call dialing will start;

•when the button fis pressed short (less than 2 sec.) (not in the call

mode) the voice activated dialing function is activated (depending on a tele-

phone conﬁguration).

In the player mode:

•when buttons cor aare pressed long, track/video rewinding will be

started.

Headset charging

•Connect the headset to PC with the USB to mini USB cable (included).

The indicator ilights red during charging.

Fig. 1. Headphones description

Wireless Stereo Headphones

with Microphone

ENG

Operation Manual

•When the device is fully charged, the indicator will blow out.

•When the battery is low-charged, it beeps several times and the indicator

iwill blink red.

•The battery is used in the headphones as an integral part of the device,

so do not try to remove or replace it as it can result in the warranty

cancellation or to a damage of the device.

Bluetooth technology

•Wireless data transfer via the Bluetooth protocol allows connecting head-

phones without wiring to compatible devises. Maximum radius of action of

data transfer is 10 m. Such obstacles as walls or other electronic devices

can interfere with the signal transfer.

Headset to a device interface

•It is necessary ﬁrst to interconnect the device with a sound source (see the

connection diagram in Fig. 2) to transfer signals via Bluetooth. To do this,

switch on the headset not releasing the button fwhile the search mode

will start, LED indicator iwill alternate blue light with red one.

•It is necessary to select the search mode of a Bluetooth device on a sig-

nal source (telephone, notebook, smartphone, etc.), the «AP-B770MV» name

will be displayed on the screen with which connection is to be required*.

•If connection is successful, there will be a short sound signal in the

headphones; the search mode indication on the headphones is over. If no

devices will be connected, the search mode will be turned oﬀautomatically

in three minutes and the headphones will go to the standby mode. If the

interface of devices has been failed, it is necessary to switch the system in

the search mode once more (switch oﬀand on)**.

Fig. 2. Connection diagram

Phone

PC Headphones

AP-B770MV

ENG

•The indicator ion the headphones blinks blue short during the data

exchange with a device connected via Bluetooth.

* You might have to enter “0000” code to connect some models of devices

via Bluetooth.

** If the item has been already registered in the device list of a source, then

the second search mode activation is not obligatory. Choose only the item

name and the “connect” command on the source.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit

Sensitivity, dB

Frequency range, Hz

Impedance, Ohm

Membrane, mm

Connection type

Bluetooth supported proﬁles

Radius of operation, m

Operation time with battery

Weight, g

Value

headphones: 106 ± 2

microphone: -58 ± 2

headphones: 20 – 22 000

microphone: 100 – 10 000

Ø 40

Bluetooth 3.0 + EDR

HSP, HFP, A2DP, AVRCP

up to 22 hours

210

Notes. Technical speciﬁcations given in this table are supplemental informa-

tion and cannot give occasion to claims. Technical speciﬁcations are subject

to change without notice due to the improvement of SVEN production.

Technical support is on www.sven.ﬁ

Wireless Stereo Headphones

with Microphone

Модель: AP-B770MV

Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024, РФ,

г. Москва, ул. Авиамоторная, д. 65, стр. 1.

Уполномоченная организация вРоссии: ООО «РТ-Ф»,

105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.

Условия гарантийного обслуживания смотрите

вгарантийном талоне или на сайте www.sven.ﬁ

Гарантийный срок: 12 мес.

Срок службы: 2 года.

Производитель: «СВЕН ПТЕ. Лимитед»,

176 Джу Чиат Роуд, №02-02, Сингапур, 427447.

Произведено под контролем «Свен Скандинавия

Лимитед», 48310, Финляндия, Котка,

Котолахдентие, 15. Сделано вКитае.

Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,

№02-02, Singapore, 427447. Produced under the control

of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka,

Finland, 48310. Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
