Swann SW-R-DVR16 Manuale utente

• Motion trigger recording function

• Support 2 removable HDDs (over 250GB), IDE type

• Wavelet Compression Format replaces Time Lapse VCR + Multiplexer

• Stand-alone design

• 4 Level video quality adjustable: Best / High / Normal / Basic

• Support 4 / 7 / 9 / 10 / 13 / 16 Channels Multiplexing function

• 16 Channels alarm input, one alarm output and ALARM display

• Video loss detected in each channel can record up to 160 events

• Power-loss memory function

• Quick Multiple Search by date / time, alarm and full list

• Security password protection

• RS-232 and RS-485 communication protocol

www.swannsecurity.com

Enquiries: [email protected]

Product Code: SW-R-DVR16

Home/Office Security System

16 Channel Digital Video Recorder

With Motion Detection and Audio

Monitoring & Recording

16 Ch Digital Multiplex recorder, is a device which uses digital technology to manage video image in HDD.

It includes features such as timer setting for searching, nice recording quality, fast / slow forward, reverse

search and user-friendly operations. It is the best device to replace Time Lapse VCR + 16 Ch Multiplexer

and the best unit to cover 4 Ch to 16 Ch DVR Installation.

Home/Office Security System

16 Channel Digital Video Recorder

With Motion Detection and Audio

Technical Specifications

Video format: NTSC/EIA or PAL/CCIR

Hard disk storage: IDE type, UDMA 66,

supported over 250GB HDD

Camera Input Signal &

Loop Back: Composite video signal

1 Vp-p 75O BNC, 16 channels

Main & Call

Monitor Output: Composite video signal

1 Vp-p 75O BNC

Audio input: 4 audio inputs, (RCA)

Audio output: 2 audio outputs, (RCA)

Motion Detect Area: 15 * 12 targets per camera (NTSC) /

15 * 14 targets per camera (PAL)

Video Loss Detection: Yes

Refresh Rate: Up to 120 fields/sec. for NTSC /

100 fields/sec. for PAL

Recording Rate: Up to 25 images/sec. for NTSC /

18 images/sec. for PAL

Picture in Picture: Yes (Movable)

Key Lock: Yes

Picture Zoom: 2*2 (Movable)

Video Adjustable: Color/ Contrast/

Brightness Adjustable

Alarm Input: TTL input, Hi (5V),

Low (GND)

Alarm Output: COM,/N.O.

Remote Control: RS-232 or RS-485

Power Source: AC100~240V

± 10% switching adaptor

Power Consumption: <45W

Operation Temperature: 10 ~ 40°C

RS-232C / RS-485 (bps) 115200, 57600, 19200,

9600, 4800, 3600, 2400, 1200

Dimension: (mm) 432(W) x 110(H)

x 325(D)

Net Weight: 5.7 kgs

Package Contents

DVR

Power Adaptor

Power Cable

Instructional Manual (Manual only available in English)

www.swannsecurity.com

Please note that the information

contained within this document is

subject to change without notification.
