Targus AKB24US Manuale utente

USER GUIDE

Visit our Website at www.targus.com Features and

specifications subject to change without notice.

AKB24US / 410-1478-001A

Wireless

2.4GHz

Keyboard

Introduction

Congratulations on your purchase of the Targus Wireless

2.4 GHz keyboard. This keyboard utilizes the latest wireless

technology to eliminate interference. Additionally, Free Smart

Link technology provides a plug-n-play experience.

Contents

•Targus Wireless Keyboard

•USB Receiver

•2 AAA Batteries (included)

•Software Driver CD

•User Guide

System Requirements

Hardware

• PC with an Intel® Pentium® processor or equivalent

• USB port

Operating System

• Windows® 2000/XP

• Windows Vista™

TARGUS WIRELESS 2.4 GHz

KEYBOARD

Targus Wireless 2.4 GHz keyboard

Installing the Batteries

Wireless Keyboard

1 Remove the battery cover located on the bottom of the

keyboard.

2 Insert the supplied batteries , making sure that the positive

(+) and negative (-) ends of each battery match the polarity

indicators inside the battery compartment.

Removing the battery cover

Targus Wireless 2.4 GHz keyboard

Establishing a Communications Link

Plug the USB receiver into an available USB port on your

computer.

NOTE: IT IS RECOMMENDED TO KEEP THE KEYBOARD AT A DISTANCE OF LESS

THAN (6 FEET / 2 METERS) TO THE RECEIVER AT THE INITIAL CONNECTION.

• Press any key on the keyboard to connect.

Targus Wireless 2.4 GHz keyboard

Download the software driver (Model # AKB24) from the

ofﬁcial Targus web site: http://www.targus.com

Save the setup ﬁle to your computer and double click on the

icon to launch the installation process.

The Installation Wizard window will prompt.

Follow the on-screen instructions to complete the installation.

NOTE: THE KEYBOARD CAN WORK WITHOUT INSTALLING THE SOFTWARE

DRIVER; HOWEVER, NOT ALL FUNCTIONS WILL BE AVAILABLE.

Installing the Software driver

The driver can be found on the CD-ROM (included)

Choose “Wireless Keyboard” and click “Run Setup”

Targus Wireless 2.4 GHz keyboard

After the software driver is successfully installed, new icons

will show in the taskbar.

There are 4 programmable “Hot Keys”. Click on the icons to

assign the new short-cut function.

Follow the on-screen instructions to setup the short-cut keys.

Keyboard Setup

Scroll LOCK - ON

CAP-LOCK - ON

Number LOCK - ON

Double click on the “Keyboard Icon” to launch the key

conﬁguration screen

Targus Wireless 2.4 GHz keyboard

Using the Hot keys

Media keys

Key Function

Launch Default Media Program

Mute

Volume Up

Volume Down

Play / Pause

Stop

Key Function

Sleep

Default Internet browser

Default E-mail Program

Favorite

Calculator

My Computer

Internet and System keys

NOTE: BY DEFAULT, THE HOT KEYS ARE PRESET AS FOLLOWS:

Targus Wireless 2.4 GHz keyboard

Troubleshooting

• Check the receiver connection; try inserting the receiver

to another USB port on your computer.

• No connection between the device(s) and the receiver.

Re-insert the receiver. Remove and reinstall batteries.

Targus Wireless 2.4 GHz keyboard

Specications

Operation Frequency 2.4 GHz

Operating Distance Up to 10m

Operating Voltage Keyboard: 3V

Receiver: 5V

Operating Current Keyboard: 3mA maximum

Receiver: 30mA maximum

Suspend Mode Keyboard: Below 300 uA

Dimensions Keyboard: 470 x 147.5 x 22 mm

Receiver: 42 x 14.5 x 7 mm

Weight Keyboard: 70.4g

Receiver: 1g

Targus Wireless 2.4 GHz keyboard

Technical Support

For technical questions, please visit:

US Internet: www.targus.com/support.asp

Australia Internet: www.targus.com/au

Email: infoaust@targus.com

Telephone: 1800-641-645

New Zealand Telephone: 0800-633-222

Product Registration

Targus recommends that you register your Targus accessory

shortly after purchasing it. Go to:

http://www.targus.com/registration.asp.

You will need to provide your full name, email address, country of

residence and product information.

Warranty

Targus warrants this product to be free from defects in materials

and workmanship for one year. If your Targus accessory is found

to be defective within that time, we will promptly repair or replace

it. This warranty does not cover accidental damage, wear and tear,

or consequential or incidental loss. Under no conditions is Targus

liable for loss of, or damage to devices; nor loss of, or damage

to, programs, records, or data; nor any consequential or incidental

damages, even if Targus has been informed of their possibility. This

warranty does not affect your statutory rights.

Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) This device must accept

any interference received, including interference that may cause

undesired operation.
