Instructions

P6137

10X Passive Probe

for 2400 Series Oscilloscopes

070-6432-03

*P070643203*

070643203

www.tektronix.com

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes

that in all previously published material. Specifications and price change privileges reserved.

Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

WARRANTY

Tektronix warrants that the products that it manufactures and sells will be free from defects in materials and

workmanship for a period of one (1) year from the date of purchase from an authorized Tektronix distributor. If

any such product proves defective during this warranty period, Tektronix, at its option, either will repair the

defective product without charge for parts and labor, or will provide a replacement in exchange for the defective

product. Batteries are excluded from this warranty.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration

of the warranty period and make suitable arrangements for the performance of service. Customer shall be

responsible for packaging and shipping the defective product to the service center designated by Tektronix,

shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the

product to Customer if the shipment is to a location within the country in which the Tektronix service center is

located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for

products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate

maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage

resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;

b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any

damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been

modified or integrated with other products when the effect of such modification or integration increases the time

or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE LISTED PRODUCTS IN

LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS

DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE

PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR

BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY

INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF

WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF

SUCH DAMAGES.

P6137 10X Passive Probe Instructions i

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to

this product or any products connected to it. To avoid potential hazards, use this

product only as specified.

Only qualified personnel should perform service procedures.

Use Proper Power Cord. Use only the power cord specified for this product and

certified for the country of use.

Use Proper Voltage Setting. Before applying power, ensure that the line selector is

in the proper position for the power source being used.

Connect and Disconnect Properly. Connect the probe output to the measurement

instrument before connecting the probe to the circuit under test. Disconnect the

probe input and the probe ground from the circuit under test before disconnecting

the probe from the measurement instrument.

Ground the Product. This product is indirectly grounded through the grounding

conductor of the mainframe power cord. To avoid electric shock, the grounding

conductor must be connected to earth ground. Before making connections to the

input or output terminals of the product, ensure that the product is properly

grounded.

Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings

and markings on the product. Consult the product manual for further ratings

information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that

exceeds the maximum rating of that terminal.

Do Not Operate Without Covers. Do not operate this product with covers or panels

removed.

Use Proper Fuse. Use only the fuse type and rating specified for this product.

Avoid Exposed Circuitry. Do not touch exposed connections and components

when power is present.

Do Not Operate With SuspectedFailures. If you suspect there is damage to this

product, have it inspected by qualified service personnel.

Do Not Operate in Wet/DampConditions.

Do Not Operate in an Explosive Atmosphere.

Keep Product Surfaces Clean and Dry.

Provide Proper Ventilation. Refer to the manual’s installation instructions for

details on installing the product so it has proper ventilation.

To Avoid Fire or

Personal Injury

General Safety Summary

ii P6137 10X Passive Probe Instructions

Terms in this Manual. These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols on the Product. The following symbols may appear on the product:

CAUTION

Refer to Manual

Symbols and Terms

P6137 10X Passive Probe Instructions iii

Service Safety Summary

Only qualified personnel should perform service procedures. Read this Service

Safety Summary and the General Safety Summary before performing any service

procedures.

Do Not Service Alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering first aid and resuscitation is

present.

To avoid electric shock, do not touch exposed connections.

Service Safety Summary

iv P6137 10X Passive Probe Instructions

P6137 10X Passive Probe Instructions 1

Operating Considerations

This manual provides the information necessary to begin making measurements

with your P6137 probe. Topics are presented in the following order:

HOperating Considerations—Information about using the probe.

HSpecifications—Characteristics of the probe.

HAdjustment/Maintenance—Instructions for cleaning the probe and

replacing major assemblies.

HReplaceable Parts—Exploded views of the probe and replaceable parts lists.

Adverse Effects of Ground Lead Inductance

Ground Lead inductance can significantly reduce the performance of a probe. As

shown in Figure 1, the ground lead inserts a series inductance into the signal path

forming a series-resonant circuit between Cin of the probe and ground lead L,

with only Rsource as damping. This forms a resonant circuit with:

f0+1B(2pLC

Ǹ)

Figure 1: Schematic representation of probe

A six-inch ground lead has [180 MHz, which is within the mid-frequency

response of the instrument. This greatly degrades rise time, bandwidth, and

transient accuracy (see Figure 2). For best results, make sure that the ground lead

inductance is at a minimum.
