USER MANUAL
STUDIO 20
TELEGRAPHER LOUDSPEAKERS
DESIGNED IN ENGLAND
YOU HAVE MADE
A GREAT DECISION!
Telegrapher Loudspeakers Studio 20 is a 3-way active near-field
monitor designed for critical mixing and mastering applications.
We take great pride in our work, and we hope these monitors allow
you to realize your audio endevours at the very highest level.
ABOUT THE STUDIO 20
SAFETY PRECAUTIONS
Your speakers operate at mains voltage and carries
hazardous voltages.
Do not expose your speakers to rain, water or
moisture to reduce the risk of fire or electric shock.
Do not place your speakers near any heat sources
such as amplifiers that produce heat.
Make sure electrical power is o before connecting
or disconnecting power and/or signal cables.
Avoid direct sunlight.
This symbol indicates that this product
should not be disposed of with your
household waste.
Improper handling of this type of waste
could have a possible negative impact on
the environment and human health due to
potentially hazardous substances.
For more information about where you can
drop o your waste equipment for
recycling, please contact your local city
oce, waste authority, or your household
waste disposal service.
Operating Voltage
Min Voltage: 100-120 Volts AC ±10%
Max Voltage: 200-240 Volts AC ±10%
Voltage Frequency: 47 - 63 Hz
Connector: 3-pin IEC 250 Volts AC, 10A male
Input power: 350W max
This symbol is intended to alert the user of
the prescence of important operating and
maintaining (servicing) instructions in the
literature accompanying the appliance.
!
This symbol is intended to alert the user to
the prescence of uninsulated “dangerous
voltage” within the product’s enclosure, that
may be of significant magnitude to constitute
a risk of electric shock to persons.
526 x 274 x 348
all dimensions are in mm (H x W x D)
Weight
22 Kg each
Dimensions Amplifiers
Tweeter 100 Wrms
Mid 125 Wrms
Woofer 125 Wrms
Load-Independent Frequency Response
Frequency-Independent THD
Meets 2013 ERP Lot 6 0.5W Requirements
Over Current / Thermal Protection
Auto Standby
LEFT RIGHT
Tweeter: 2.5 cm coated textile diaphragm
Patented Symmetrical Drive (SD-2)
Mid: 12 cm paper cone
Patented Symmetrical Drive (SD-3)
Woofer : 18 cm paper cone
Patented Sandwich Paper Cone
Patented Symmetrical Drive (SD-3)
LET’S GET STARTED!
