Tenda D810R ADSL2+ Manuale utente

is the registered trademark of Shenzhen

Tenda Technology Co., Ltd. Other trademark or trade

name mentioned herein are the trademark or

registered trademark of the company. Copyright of the

whole product as integration, including its accessories

and software, belongs to Shenzhen Tenda Technology

Co., Ltd. Without the permission of Shenzhen Tenda

Technology Co., Ltd, individual or party is not allowed to

copy, plagiarize, imitate or translate it into other

languages.

All the photos and product specifications mentioned in

this manual are for references only, as the upgrading of

software and hardware, there will be changes. And if

there are changes, Tenda is not responsible for

informing in advance. If you want to know more about

our products information, please visit our website at

www.tenda.cn

D810R ADSL2+ Router User Guide

PTC General Warning

1 The grant of a Telepermit for any item of

terminal equipment indicates only that

Telecom has accepted that the item complies

with minimum conditions for

connection to its network. It indicates no

endorsement of the product by Telecom,

nor does it provide any sort of warranty. Above

all, it provides no assurance that

any item will work correctly in all respects with

another item of Telepermitted

equipment of a different make or model, nor

does it imply that any product is

compatible with all of Telecom's network

services.

CONTENTS

D810R ADSL2+ Router User Guide

CHAPTER 1 OVERVIEW........................................................... 1

1.1 Product Introduction.................................................. 1

1.2 Product Features......................................................... 2

1.3 Supporting Protocol ................................................... 3

1.4 Data Encapsulation ................................................... 3

CHAPTER 2 HARDWARE INSTALLATION ............................... 4

2.1 ADSL Router Connection .......................................... 4

2.2 USB Installation............................................................. 4

CHAPTER 3 BEFORE WEB MANAGEMENT CONFIGURATION

..................................................................................................5

3.1 Network Configuration of Your Computer............. 5

3.2 Verifying the Connection.......................................... 8

3.3 Logging in to the Router............................................ 9

CHAPTER 4 QUICK INSTALLATION GUIDE.......................... 10

4.1 Configure the PPPoE................................................11

4.2 Configure the PPPoA...............................................13

D810R ADSL2+ Router User Guide

4.3 Configure the MER ...................................................15

4.4 Configure the IPoA................................................... 18

CHAPTER 5 CONFIGURATION DESCRIPTION..................... 20

5.1Device Information....................................................20

5.2Advanced Settings.................................................... 23

5.2.1 WAN..................................................................23

5.2.2 LAN....................................................................48

5.2.3 NAT....................................................................50

5.2.4 Security .............................................................56

5.2.5 Routing..............................................................64

5.2.6. DNS...................................................................66

5.2.7 DSL.....................................................................71

5.3 DHCP..........................................................................72

5.4 System Tool ................................................................73

5.4.1 Settings..............................................................73

5.4.2 System Log .......................................................75

5.4.3 Internet Time.....................................................77

5.4.4 Access Control.................................................78

5.4.5 Software Update .............................................81

D810R ADSL2+ Router User Guide

5.4.6 Save/Reboot....................................................81

CHAPTER 6 APPENDIX.......................................................... 82

Appendix 1: Troubleshooting...................................82

Appendix 2: FAQ ......................................................84

CHAPTER 7 WALL-MOUNTING PLACEMENT......................85

D810R ADSL2+ Router User Guide

Chapter 1 Overview

1.1 Product Introduction

D810R ADSL2+ Router complies with ADSL, ADSL2 and

ADSL2+ standards. Supporting up to 24Mbps

downstream rate and 1Mbps upstream rate, it supports

multiple network protocols and provides NAT Router

and Bridge functions. In addition, the intelligent software,

Setup Wizard, can assist you to access the Internet fast

and easily. Powerful and exquisite, it is the best choice

for SOHO and small enterprise users to share the

Internet.

D810R ADSL2+ Router User Guide

1.2 Product Features

Provides up to 24Mbps downstream rate and

1Mbps upstream rate

Supports DHCP, NAT, IGMP, ICMP, ARP

One 10/100M Auto-Negotiation RJ-45 Ethernet

port for network adapter, Hub and switch

connectivity

One RJ-11 port and Voice Splitter included

One USB port support for connecting PC’s USB

port

Provides Web-based management and firmware

upgrade

Complies with ADSL, ADSL2 and ADSL2+ standards

Provides NAT Router and Bridge functions

Compatible with all mainstream DSLAM (CO)

Provides PPPOE, PPPOA, CLIP protocols

Supports firewall and hacker attack prevention

Supports Internet Multimedia

Provides static and dynamic routes

Up to 6.5km (telephone line) transmission distance

Setup Wizard support for fast and easy

configurations

D810R ADSL2+ Router User Guide

1.3 Supporting Protocol

Supports full-rate ADSL2+ standard

ANSI T1. 413 Issue 2

ITU-T G. 992. 1 (G. dmt)

ITU-T G. 992. 2 (G. Lite)

ITU-T G. 992. 3

ITU-T G. 992. 5

1.4 Data Encapsulation

Supports RFC 1483 Bridge, RFC 1483 Router

Supports Classical IP over ATM (RFC 1577)

Supports PPP over ATM(RFC 2364)

Supports PPP over Ethernet (RFC 2516)

D810R ADSL2+ Router User Guide

Chapter 2 Hardware Installation

2.1 ADSL Router Connection

1. Connect one end of the telephone line to the

LINE port of the D810R and the other end to the

MODEM port of the voice splitter.

2. Connect the power adapter to the PWR port of

the D810R.

3. Use an Ethernet cable to connect the LAN port

with the NIC of your computer.

2.2 USB Installation

To connect the device to the USB interface of the

computer, please follow the steps below:

1. Connect to the USB port of the D810R through a

USB cable.

2. Connect the other end of the cable to the

computer’s USB port.

3. Set up the USB driver provided by the CD-ROM.
